DE Act 1.1.6 Flip-flop truth table

advertisement
NAME______________________________________
PERIOD: 1 2 3 4 5 6
DE: FLIP-FLOP TRUTH TABLE
On the back are 4 pictures of the NAND gate version of a flip-flop circuit. Use them to fill in the following truth
table. Use one picture per row.
INPUT
OUTPUT
D
CLK
0
0
0
1
1
0
1
1
Q
-Q
