THE PROJECT
National Highway No. 57 is one of the major arteries of the road network system in the State
of Bihar connecting Muzaffarpur City with Purnea. It traverses through the major district
headquarters of the state viz., Darbhanga and Forbesganj.
Nearly 10.635 Km. Project Highway section of NH-57, starts from Km. 148.550 near Tharia
village on Nirmali side and ends at 159.185 near Chandpipar village on Kishanpur side. Thus in
order to provide a better level of service to vehicular traffic it has been apprised to augment
the capacity of NH-57 by constructing Kosi Bridge and its approaches between Ring Bund
and Eastern Embankment which will not connect the two part of Mithnachal, but also two
sub-divisions of district Supaul..
In order to channelize the water of Kosi River and to protect the Bridge and its approaches,
construction of Guide Bund perpendicular to the centre line of bridge and Afflux Bund joining
the edges of Guide Bund on the upstream side with Ring Bund on Western Side and Eastern
Embankment on Eastern Side.
SCOPE OF PROJECT:
This Project has been executed on the site, which is described in Project Site chapter of the
Concession Agreement. The scope of the project shall include performance and execution
by the Concessionaire of all Design, Engineering, Financing, Procurement, Construction,
Completion, Operation and Maintenance of the Project Highway. It includes Improvement,
Operations, Maintenance, Rehabilitation and Strengthening of the existing missing link of NH57 road and widening it to a 4-lane divided carriageway including Kosi Bridge and its
approaches from Km. 148.550 to Km. 159.185 in the State of Bihar on Annuity basis.
M/s. Kosi Bridge Infrastructure Company Limited was the Concessionaire and M/s. Wilbur
Smith Associates Inc in JV with Wilbur Smith Associates Pvt. Ltd., was the Independent
Consultant for the Project. The independent Consultant has been demobilised from
08.02.2013 after spending one year period during O & M after issuance of Provisional COD.
The COD is under consideration of NHAI, HQ now.
1.2 PROJECT DETAILS
1.2.1. CONTRACT DETAILS
Project
Design, Construction, Finance, Operation and Maintenance of 4lane Bridge across River Kosi including its approaches & Guide
Bund & Afflux Bund from Km. 148.55 to Km. 159.185 on NH-57 on
Annuity Basis
State
Bihar
National Highway No.
NH – 57
Employer
National Highway Authority of India
Independent Consultant
Wilbur Smith Associates Inc in JV with Wilbur Smith Associates Pvt.
Ltd.,
Concessionaire
KOSI BRIDGE INFRASTRUCTURE COMPANY LIMITED
Section
Km. 148.55 to 159.185( Revised Ch. 145.646 to Ch.156.281)
Length of the Project
10.635 Km
Project Start Date
04.04.2007
Schedule Completion Date
04.04.2010
Project Completion Date
(Provisional)
08.02.2012
Concession Period
20 years
Construction Period
36 months
Extended Construction
Period
24 months
Length of Eastern side
Guide Bund
2.635 Km
Length of Western side
Guide Bund
2.884 Km
Length of Eastern side
Afflux Bund
7.773 Km
Length of Western side
Afflux Bund
7.925 Km
Concession Completion
Date
20 years commencing from commencement date (From 4th Apr’10
to 4th Apr’27)
1.2.2. SCOPE DETAILS
S.No
Particulars
1
Length of the Main
Bridge (4 Lane)
Details
1.878 KM and 20.70 M width
Number of
foundations
40 nos.
Span Configuration
48.175x2 + 48.15x37
Type of super
structure
Additional work executed in COS
Segmental pre cast Box
Girder
2
Length of Road
(Excluding Main
Bridge)
8.757 KM (7.25 M. x 2 widths
1.2 M Divider, 1.5 M Paved
Shoulder and 1.5 M earthen
shoulder both side of the
road)
3
Length of Guide
Bund
5.519 KM long (2.635 KM
eastern side and 2.884 KM at
western side)
4
Length of Afflux
Bund
15.698 KM long (7.773 KM at
eastern side and 7.925 at
western side)
5
Median Openings
(Recommended)
3 nos.
6
Cattle Crossings
4 nos. (9.50m x 3.50m)
7
Toll Plaza (1 No.)
At chainage: 150+390
THE PROJECT HAS BEEN COMPLETED.
195 M Missing Link of stretch between
civil package BR05 & BR04
400 M western side Guide Bund apron
along Afflux Bund
1 no.
