EDAN INSTRUMENTS, INC.
http://www.edan.com.cn/
Product Details
Highlights
Care for Health
Built on EDAN’s strong heritage in patient monitoring, iM9 and iM8 Series
patient monitors offer high-performance monitoring and highly flexible
configurations at the patient’s side.
iM8B
iM8A
iM8
iM9A
iM9
Care for Health
 We pay much attention to product research and development
------ More than 100 R&D engineers
 We focus on public platform
 We concentrate on product quality
------ 3 R&D centers distributed in China & US
------ All monitors with CE approval
Care for Health
In addition to its 26 branch offices in China, EDAN is committed to building its localized
service network in order to keep closer to customers worldwide. 4 overseas offices have
been set up while more are on their way.
Care for Health
General Information
Highlights
Care for Health
iM9 Series/iM8 Series
iM9 Series/iM8 Series
iM9 Series
iM9 Series/iM8 Series
iM9 Series/iM8 Series
Care for Health
Care for Health
iM80 & iM50 only
iM9
iM8
iM9A
iM8A
iM8B
Though there’s no touch screen, the classic “Keypad + Knob” design can still be an
alternative and familiar option for daily works, meeting your needs for sub-acute cares.
Care for Health
iM80 & iM50 only
iM9 Series
Large-Font Display
Trend Display
12-lead ECG Display
Vital Signs Display
Night Mode
At night, the doctors may activate
the night mode with dimmer screen,
backlit buttons, lower alarm volume
and no HR beeps.
iM8 Series
OxyCRG Display
Care for Health
iM80 & iM50 only
 External USB Storage Support
 Automatic data storage during unexpected power failures
USB
VGA output (optional, iM8 series only)
VGA
500
96 h
NIBP Measurements
Review
Trends Review
60
720 s
Alarms Review
Frozen Waveforms
Care for Health
Care for Health
ECG
AG/O2
(12-lead ECG
optional)
SpO2
(Nellcor
optional)
(optional)
NIBP
EtCO2
(OMRON
optional)
(optional)
C.O.
Respiration
(optional)
IBP/ICP
(optional)
Temp
Care for Health
 3/5-lead ECG Monitoring
 Unique iSEAPTM algorithm optimized for arrhythmia detection,
pacemaker detection, and HR measurement
 Arrhythmia recording and alarm review
 Pacemaker Detection
 Defibrillator Protection
 Suitable for Adult, Pediatric and Neonate patients
 Impedance method for monitoring respiration rate
Care for Health
iM9 Series
12-lead ECG Monitoring
Unique 12-lead SEMIP interpretation tested by CSE & AHA database
12-lead ST analysis
208 kinds of diagnosis results
16 kinds of arrhythmia analysis
 50 sets of 12-lead analysis result review
10 seconds of 12-lead waveform to review and print out
 Suitable for Adult, Pediatric and Neonate patients
 Impedance method for monitoring respiration rate
Care for Health
 iMATTM SpO2 algorithm with outstanding motion resistance
and low perfusion resistance performance
 Anti-motion and anti-low perfusion
 Suitable for Adult, Pediatric and Neonate patients
 Pitch Tone (Pulse-tone modulation)
 Nellcor OxiMax™ SpO2 (optional, iM9 Series only)
 Unique shield design to block the outside lights
Care for Health
 iCUFSTM NIBP algorithm optimized for cardiac patients, hypertensive
patients, and neonatal patients
 Low noise, make patient more comfortable
 Three kinds of measurement modes: Manual, Automatic and Continuous
 Suitable for Adult, Pediatric and Neonate patients
OMRON M3600Ⓡ NIBP
(optional, iM9 Series)
 Smart Inflation™ technology for comfortable
measurement experience for the patient
Dynamic Linear Deflation for faster
measurements
Dual Systems for safety
Care for Health
 2-channel TEMP measurements
 Compatible with CY and YSI temp probe
 Skin, Oral and Rectal temperature measurement
 Suitable for Adult, Pediatric and Neonate patients
Skin Temperature Probe
Rectal Oral Temperature Probe
Care for Health
 2-channel IBP
 Pressure labels: ART, PA, CVP, RAP, LAP, ICP, P1 (user-defined), P2 (user-defined)
 Compatible with BD/ Edwards/ Hospira/ Utah
Care for Health
ICP transducer with extension cable
Gaeltec ICP transducer
 One IBP channel has to be taken for monitoring intracranial pressure (ICP)
 Less invasive measurement with reusable epidural sensor ICT/B which works between
the skull and dural tissue
 Work with Gaeltec intracranial catheter tip pressure transducer and Calibration Tube
Care for Health
iM9 Series
Cardiac Output cable
 Thermal Dilution Technique
 Hemodynamic Calculation
 Suitable for Adult, Pediatric and Neonate patients
Control Syringe (Medex MA387)
In-line Injection Temperature Probe
Care for Health
 For intubated & non-intubated patients
 Compact design
 Eliminates the needs of periodic calibration
 Suitable for any traditional ventilators
 Short warm-up time
 Suitable for Adult, Pediatric and Neonate patients
Care for Health
 For intubated & non-intubated patients
 Micro sample velocity
 No water trap design
 Compact design
 Eliminates the needs of periodic calibration
 Filter tip (patent) to obstruct from the water vapor and contamination
Care for Health
iM9 Series
 Auto-compensation
 Auto-calibration
 Short response time
 Real-time EtCO2 and FiCO2 measurement
 N2O, O2 , Halothame, Isoflurane, Enflurane, Sevoflurane, Desflurane
measurement and identification
 Suitable for Adult, Pediatric and Neonate patients
Care for Health
Care for Health
HL7 HIS Server
Web Viewer
MFM-CMS Central Monitoring Station
iM9 Series
Bedside Monitoring
iM8 Series
Care for Health
Real-time Data
iM9 Series
iM8 Series
MFM-CMS central monitoring station does not only receive the
real-time data sent from the monitors, but also modifies the
patient information or takes the NIBP measuring remotely.
Care for Health
iM9 Series
iM8 Series
iM8 Series
iM9 Series
In the same network, different iM9/iM8 Series patient monitors may communicate with
each other, which makes it possible to check other beds from whichever bed in the
network.
Care for Health
General Information
Product Details
Care for Health
Features
•
•
•
•
Multi-display modes
Powerful storage
USB power-off storage
VGA output
Technologies
•iSEAP algorithm
•SEMIP algorithm
• Dual-mode anti-interference
technology
Cooperative Tech
•
•
•
•
Nellcor OximaxTM SpO2
OMRON NIBP
PHILIPS RESPIRONICS EtCO2
Artema AG/O2
IT Solutions
•
•
•
•
MFM-CMS with HL7
Web Viewer
LAN/Wi-Fi
Bi-directional communication
with CMS
• Bed-to-bed view
Care for Health
Parameters
iM9 Series
iM8 Series
3/5-lead ECG
√
√
12-lead ECG
Option
x
EDAN SpO2
√
√
Nellcor SpO2
Option
x
EDAN NIBP
√
√
OMRON NIBP
Option
x
Respiration
√
√
Temperature
2-Temp
2-Temp
IBP/ICP
Option
Option
C.O.
Option
x
Respironics EtCO2
Option
Option
Artema Multi-Gas
Option
x
Care for Health
Features
iM9 Series
iM8 Series
Keypad & Knob
√
√
USB Power-off
Storage
√
√
VGA Output
x
Option
LAN
√
√
Wi-Fi
External (Option)
External (Option)
MFM-CMS
(HL7, Web Viewer)
√
√
Bed-to-bed View
√
√
Nurse Call
√
√
Defib Synch
√
√
Care for Health
