Categories of software defects
See accompanying Word file
“Software defects 2”
Software warranties
• Four general categories of software defects
tend to be significant in product liability
litigation:
– Errors of commission (something is done that is wrong)
– Errors of omission (something was left out by accident)
– Errors of clarity and ambiguity, (two people reach different
interpretations of what is meant)
– Errors of speed or capacity (the application works, but not fast
enough)
Origins of defects
–
–
–
–
–
–
–
Errors in
Errors in
Errors in
Errors in
Errors due to
Errors in
Errors in
Requirements
Design
Source Code
User Documentation
"Bad Fixes"
Data and Tables
Test Cases
Requirements defects (1)
• All four categories of defect are found in requirements
• The two most common problems are errors of omission
and errors of clarity and ambiguity.
• If requirements errors are not prevented or removed, they
flow downstream into design, code, and user manuals.
• Errors which originate in requirements tend to be the most
expensive and troublesome to eliminate later.
• For reducing requirements defects, prevention is usually
more effective than defect removal.
Requirements defects (1) ...
• Can requirements for large systems can ever be complete,
given the observed rate of creeping requirements during
the development cycle.
• Since requirements grow at rates between 1% and 3% per
month during development, the initial requirements often
describe less than 50% of the features that end up in the
final version when it is delivered.
• Once deployed, applications continue to change at rates
that approximate 5% to 8% new features every year, and
perhaps 10% modification to existing features.
Formal requirements methods
• Requirements based on natural language will always be
troublesome.
• Several formal requirements methods have been developed
(but are not widely used)
• DeMarco's structured English
 IBM's HIPO diagrams (Hierarchy plus Input,
Processing, Output),
 the Problems Statement Language (M),
 WarnierOrr Diagrams,
 the Structured Analysis and Design (SADT)
technique
Design defects (2)
• Design ranks next to requirements as a source of
very troublesome, and very expensive errors.
• All four categories of defects are found in software design
and specifications, as might be expected.
• The most common forms of design defects are errors of
omission where things are left out, and of commission,
where something is stated that later turns out to be wrong.
• Errors of clarity and ambiguity are also common, and
many performance related problems originate in the design
process as well.
Design defects & omission (2)
• It is not clear if it is technically possible to specify
all of the features and functions in a large software
system.
• MS Windows 95 or IBM's MVS in the 90,000
function point size range were fully specified, the
volume would exceed 500,000 pages.
• The completeness of software specifications
declines as system size increases (over 1000fp.)
Coding defects (3)
• All four categories of defects can be found in
source code, with errors of commission being
dominant while code is under development.
• Perhaps the most surprising aspect of coding
defects when they are studied carefully is that
more than 50% of the serious bugs or errors found
in the source code did not truly originate in the
source code.
• A majority of so-called programming errors are
really due to the programmer not understanding
the design, or the design not correctly interpreting
a requirement.
• This is not a surprising situation. Software is one
of the most difficult products to visualise prior to
having to build it.
• Built-in syntax checkers and editors associated
with modern programming languages can find
many "true" programming errors (such as missed
parentheses or looping problems)
• Even poor structure and excessive branching can
now be measured and corrected automatically.
• The kinds of errors that are not easily found are
deeper problems in algorithms or those associated
with misinterpretation of design.
Language levels
• Defects in low-level Procedural Languages
• Defects in High-Level Non-Procedural Languages
– It is interesting that there is no solid empirical data that stronglytyped languages have lower defect rates than weakly-typed
languages, although there is no counter evidence either.
• Defects in Object-Oriented Programming
Languages
– Since OO analysis and design has a steep learning curve and is
difficult to absorb, some OO projects suffer from worse than
average quality levels due to problems originating in the design.
Documentation defects (4)
• User documentation in the form of both manuals
and online information can contain errors of
omission and errors of commission
• The most common kind of problem is that of
errors of clarity and ambiguity.
• Performance-related errors are seldom
encountered in user information.
Fix defects (5)
• The phrase "bad fixes" refers to attempts to repair
an error which, although the original error may be
fixed, introduce a new secondary bug into the
application.
• Bad fixes are usually errors of commission, and
they are found in every major deliverable although
most troublesome for requirements, design, and
source code.
• Bad fixes are very common and can be both
annoying and serious.
• From about 5% to more than 20% of attempts to
repair bugs may create a new secondary bug.
• For code repairs, bad fixes correlate strongly with
high complexity levels, as might be expected.
• Repairs to ageing legacy applications where the
code is poorly structured tend to achieve higher
than average bad fix injection rates.
• Often bad fixes are the result of haste or schedule
pressures which cause the developers to skimp on
things like inspecting or testing the repairs.
Bad fix examples
• when attempting to correct a loop problem such as
going through the loop one time too often, the
repair goes through the loop one time short of the
correct amount; and
• when correcting a branching problem that goes to
the wrong subroutine, the repair goes to a different
wrong subroutine.
Data defects (6)
• The topic of data quality and data defects is
usually outside the domain of software quality
assurance
• Since one of the most common business uses of
computers is specifically to hold databases,
repositories, and data warehouses the topic of data
quality is becoming a major issue.
• Data errors can be very serious and they also
interact with software errors to create many
expensive and troublesome problems.
• Many of the most frustrating problems that human
beings note with computerised applications can be
traced back to data problems.
• Errors in utility bills, financial statements, tax
errors, motor vehicle registrations, and a host of
others are often data errors.
Test-case defects (7)
• Exploratory research carried out by IBM's
software quality assurance group on regression
test libraries noted some disturbing findings:
– About 30% of the regression test cases were duplicates that could
be removed without reducing testing effectiveness.
– About 12% of the regression test cases contained errors of some
kind.
– Coverage of the regression test library ranged between about 40%
and 70% of the code; i.e., there were notable gaps which none of
the regression test cases managed to reach.
Regression testing
• For software regression means slipping backward,
and usually refers to an error made while
attempting to add new features or fix bugs in an
existing application.
• A regression test means a set of test cases that are
run after changes are made to an application.
• The test cases are intended to ensure that every
prior feature of the application still works, and that
the new materials have not caused errors in
existing portions of the application.
