Conduit Fabrication, Level II
Lesson 3
Use for Questions 38 through 51
For the following questions you will be given a series of photos which depict a conduit installation
of the sort which you might encounter in the field. You are to look at the photos in order to determine
the various measurements which will be used, and then perform your calculations based upon what
you observe. The scenario involves a ¾ RMC with a 90° stub-up and a 30° offset in the same piece of
conduit. (The framing channel that the conduit is being supported on is 15/8" high.)
1
©NJATC
