Republic of the Philippines
BATANGAS STATE UNIVERSITY
The National Engineering University
Alangilan Campus
Laboratory Activity No.1
Lance Cedric F. Tulay
Name
ECE – 2204
Section
01/14/2023
Date
Engr. Monique A. Coliat
Republic of the Philippines
BATANGAS STATE UNIVERSITY
The National Engineering University
Alangilan Campus
TASK 1:
1. For the given circuit diagram above, and using the following values: E1= 200∠o V; E2= 200∠o V;
Z1= j2 Ω, Z2= -j2 Ω; ZL= 2-j2 Ω find the values of the current across ZL using the Mesh Analysis.
2.
Corollary to the values required on Task 1, find the same values using Kirchhoff’s Law.
Republic of the Philippines
BATANGAS STATE UNIVERSITY
The National Engineering University
Alangilan Campus
TASK2:
3. For the given circuit diagram above, and using the following values: E1= 100∠45 V;
E2= 100∠− 45 V; Z1= 10 Ω, Z2= 10 Ω ; ZL= 10+j10 Ω find the value of the current across ZL using
the Nodal Analysis.
4. Corollary to the values required on Task 2, find the same values using Kirchhoff’s Law.
