1.
(15%)
Sketch a 3-input NOR gate with transistor widths chosen to achieve effective rise and fall resistances equal to a unit inverter. Compute the rising and falling propagation delays of the NOR gate driving h identical NOR gates using the
Elmore delay model. Assume that every source or drain has fully contacted diffusion when making your estimate of capacitance.
(20%)
An output pad contains a chain of successively larger inverters to drive the relatively enormous off-chip capacitance. If the first inverter in the chain has an input capacitance of 20 fF and the off-chip load is 10 pF, how many inverters should be used to drive the load with least delay? Estimate this delay, expressed in
FO4 inverter delays.
3.
(15%)
(a) (5%) Sometimes the substrate is connected to a voltage called the substrate bias to alter the threshold of the nMOS transistors. If the threshold of an nMOS transistor is to be raised, should a positive or negative substrate bias be used?
(b) (5%) A 90 nm long transistor has a gate oxide thickness of 16
Å
. What is its gate capacitance per micron of width?
(c) (5%) Does the body effect of a process limit the number of transistors that can be placed in series in a CMOS gate at low frequency? Why?
4. (15%)
(a) (5%) Sketch HI-skew and LO-skew 3-input NAND and NOR gates. What are the logical efforts of each gate on its critical transition?
(b) (5%) Design an asymmetric 3-input NOR gate that favors a critical input over the other two. Choose transistor sizes so the logical effort on the critical input is 1.5.
What is the logical effort of the noncritical inputs?
(c) (5%) Sketch dynamic footed and unfooted 3-input NAND and NOR gates.
Label the transistor widths. What is the logical effort of each gate?
5. (15%)
Answer the following questions.
(a) (3%) What are power rails?
(b) (3%) What does the term weak ‘ 1’ mean?
(c) (3%) Please draw a CMOS negative-edge-triggered D flip-flop using transmission gates and inverters.
(d) (3%) What is the self-aligned process?
(e) (3%) Why do we need layout design rules for IC design?
6. (20%)
Consider a 5 mm long, 4
-wide metal2 wire in a 0.6
m process. The sheet resistance is 0.08
/ □ and the capacitance is 0.2 fF/
m. A 10x unit-sized inverter drives a 2x inverter at the end of the 5 mm wire. The gate capacitance is C =2 fF/
m and the effective resistance is R =2.5 k
· m for nMOS transistors. Estimate the propagation delay using the Elmore delay model; neglect diffusion capacitance.
