How to
 Download FBF XML files, using Tortoise CVS
TCP/IP Setup
======================
(1) DNS
Need to point to Japan DNS for server name resolution. If this fails, use localhost file in Windows
directory.
First, point to FAPL DNS
 10.1.1.11
Then use any of these Japan DNS as alternates:
 10.0.50.31
 10.0.50.32
 10.75.179.2
However, the above procedure no longer works. From below, nslookup using 10.0.50.32 as dns
server, can lookup cvs.fbf.fai.fujitsu.com
However, does not work for ping
So, using the IP resolved by nslookup, set into host file any of the IP resolved for cvs.fbf.fai.fujitsu.com
e.g. 133.164.29.37 or 133.164.29.38
(2) Firewall needs to be opened for CVS and ftp
To confirm that the DNS is correct, ping the CVS server cvs.fbf.fai.fujitsu.com
As long as the hostname gets resolved to numeric IP, the DNS is okay. Don’t need to worry about any
“Request timed out” errors as the firewall might block the ping.
C:\ >ping cvs.fbf.fai.fujitsu.com
Pinging cvs.fbf.fai.fujitsu.com [133.164.29.37] with 32 bytes of data:
Request timed out.
Request timed out.
Request timed out.
Request timed out.
Ping statistics for 133.164.29.36:
Packets: Sent = 4, Received = 0, Lost = 4 (100% loss),
Approximate round trip times in milli-seconds:
Minimum = 0ms, Maximum = 0ms, Average = 0ms
Open firewall
For CVS
Firewall outgoing TCP connection to 133.164.29.37 to 38 on port 2401
To test CVS connection, telnet to port 2401 and then press Enter
C:\>telnet 133.164.29.35 2401
cvs [pserver aborted]: bad auth protocol start:
Connection to host lost.
C:\>
For FTP
Normal ftp port (21) to 133.164.29.35 to 38
Software Installation
(1) Install IE6
For Authentic on Win2000, SP4, need to install IE6 otherwise Authentic can
run but will crash when loading XML file (Win2000 default comes with IE5).
(3) Install Tortoise CVS client
TortoiseCVS-1.6.7.exe
(4) Install Authentic XML editor
AUTHENTICDeskComplete2004.exe
User Name:
Yuen Kit Mun
Company:
Fujitsu Asia Pte Ltd / MIS
E-Mail: mis@sg.fujitsu.com
Key-Code:
fsh5G0-3NBbgM-D87SMB-Cg459e-AuhzC2
(5) Optional (actually, not recommended):
Setting of XML environment for Authentic XML editor preview
http://gnd.fai.fujitsu.com/global/ click on Preview preferences
Or go directly to
http://gnd.fai.fujitsu.com/global/Preview/Aej1l0ADZF.html
CVS Download
CVS Update (from Windows Explorer, right click on empty directory, CVS Checkout)
SG CVS
=========
1. Protocol: Password Server (:pserver:)
2. Server: cvs.fbf.fai.fujitsu.com
3. Repository folder: /CVS
4. User name: sg1
5. Module Name: FBF_SG
6. Password: gxeed45u
Also used this userid and password to access web form data
https://secure.gnd.fai.fujitsu.com/reporting/FormReport/SG
PCAP CVS
========
Same as SG except
Module FBF_COMP:
username:fpcap1
password:iubjv9fy
Repository folder: /CVS
Due to large size of downloads, these are put in ftp instead of CVS
FTP ftp://downloads.ftp.fbf.fai.fujitsu.com/
Directory is /COMP
ID : fpcap1
Password - iubjv9fy
C:\>ftp downloads.ftp.fbf.fai.fujitsu.com
Connected to downloads.ftp.fbf.fai.fujitsu.com.
220 GND downloads server
User (downloads.ftp.fbf.fai.fujitsu.com:(none)): fpcap1
331 Please specify the password.
Password:
230-=============================================================
230-# You are connected to downloads.ftp.fbf.fai.fujitsu.com
230-#
230-# Please, email support@americasportals.fai.fujitsu.com if you have any ques
tions.
230-================================================================
230230230 Login successful.
ftp> cd COMP
250 Directory successfully changed.
ftp> ls
200 PORT command successful. Consider using PASV.
150 Here comes the directory listing.
fel
notebook
pda
tablet
226 Directory send OK.
ftp: 28 bytes received in 0.04Seconds 0.70Kbytes/sec.
ftp>
FMAL CVS
=========
Same as SG except
CVS Module info: FBF_MICRO
Username: fmal1
password: wnzecse0
Repository folder: /CVS
Due to large size of downloads, these are put in ftp instead of CVS
ftp://downloads.ftp.fbf.fai.fujitsu.com/ (same IP as CVS)
Changed directory to MICRO
ID: fmal1
PW: wnzecse0
MY (need to update FMAL sitemap)
================================
Module:
FBF_MY
username:
my1
password:
murmu+56
Server: cvs.fbf.fai.fujitsu.com
Repository folder: /CVS
PH (need to update FMAL sitemap)
================================
FBF_PH
Username: ph1
Password: m1nd0ro (first "0" is a zero)
Server: cvs.fbf.fai.fujitsu.com
Repository folder: /CVS
IN (need to update FMAL sitemap)
================================
Module:
FBF_IN
username:
in1
password:
dhhxiiit
Server: cvs-jp.fbf.fai.fujitsu.com
Repository folder: /CVS
Authentic
(1) Associate .xmla files to Authentic
Tools / Options
Not so important, but safer to force all saved files to Windows text file format – CR and LF at end of
line
Reference
From: Darren Gilroy [mailto:dgilroy@us.fujitsu.com]
Sent: Friday, November 12, 2004 11:01 AM
To: Paula Grabowski
Cc: 'Yuen Kit Mun'; tingmw@sg.fujitsu.com; 'Tai Hon Yen'; 'cristopherchen@fms.my.fujitsu.com';
'Bennet Lawan'; GND-Sysadmin; 'Marisheil Sikay'; 'Betty Jose'; 'Nenvi Grace Roman'; Makoto
Mizuyama
Subject: Re: CVS Issue - Mail List
All Today, we made significant improvements to our CVS services.
This involved moving the CVS service from a single box to a pair of fast servers. We are doing load
balancing
and fail-over with round-robin DNS. The service name (cvs.fbf.fai.fujitsu.com and cvsjp.fbf.fai.fujitsu.com)
did not change, but CVS now answers on TWO ip addresses.
The new IP addresses:
133.164.29.35, 133.164.29.36
the old IP address is disabled.
This transition was largely transparent do our user base.
However, it has come to our attention that some clients have hard-coded the IP address of the old
CVS server.
For these clients CVS service no longer works.
We ask that these clients to use the service name
"cvs.fbf.fai.fujitsu.com" to access CVS. If you cannot resolve this address, please work with FJNIC on
a solution.
Ideally your DNS servers would forward the request to our DNS servers and cache the result to
minimize traffic.
In the short term, switching to one of the IP addresses listed
above is possible. Either or both will work. Please be aware that we will be taking these servers down
(individually)
for upgrades over the next two to three months as we install and configure a proper cluster to replace
the round-robin DNS.
Those who use the cvs.fbf.fai.fujitsu.com name to access these servers will notice no downtime.
Those who use an IP address will.
Thank you for your understanding and please accept our apologies
for this disruption as we improve our systems.
Thanks,
Darren Gilroy.
================================================================
=======================================================
From: Diego Lagunas [mailto:dlagunas@us.fujitsu.com]
Sent: Thursday, April 01, 2004 7:15 PM
To: yuenkm@sg.fujitsu.com; 'Petar Karafezov'
Cc: eloh@sg.fujitsu.com; 'Emilia Georgieva'
Subject: RE: Request -preparation for the training April 6th & 7th
The IP address at the moment is 133.164.29.18 but we will change it in the future.
You should find out why your DNS does not resolve it.
Ping doesn't work because it's turned off on the host.
A tracert to the IP address can help determining where it gets blocked.
TCP outgoing only should be enough.
It should go through the FJWAN.
=======================================================
From: Diego Lagunas [mailto:dlagunas@us.fujitsu.com]
Sent: Thursday, April 01, 2004 2:58 PM
To: yuenkm@sg.fujitsu.com
Cc: eloh@sg.fujitsu.com; Emilia Georgieva
Subject: RE: Request -preparation for the training April 6th & 7th
Dear Yuen,
Sorry if you didn't receive the password.
Your username is "sg1" and password is "gxeed45u" (without the quotes).
Let me know if you have any trouble connecting.
Regards,
Diego
