Review questions
1 Data information is sent onto the network cable using which of the
following?
A Communication protocol
B Data packet
C
Media access method
D Packages
2 To which TCP/IP architecture layer do the media access methods
belong?
A Application
B Internet
C
Network Interface
D Transport
3 To which TCP/IP architecture layer do TCP and UDP belong?
A Application
B Internet
C Network Interface
D
Transport
4 To which TCP/IP architecture layer do routing protocols belong?
A Application
B
Internet
C Network Interface
D Transport
5 To which TCP/IP architecture layer do e-mail and Web browser
protocols belong?
A
Application
B Internet
C Network Interface
D Transport
6 Which IEEE standard defines the communication protocol for Ethernet?
A
802.3
B 802.5
C 802.11
D 802.15
7 Which protocol is used to convert logical IP addresses to physical MAC
addresses?
A
ARP
B DNS
C IMAP4
D RIP
8 You can use the command-line utility _______________ to retrieve a
computer’s IP configuration.
IPCONFIG
9 Which protocol is responsible for the logical addressing of each packet
created by the transport layer?
A
IP
B RIP
C TCP
D UDP
10 The ping utility is the most common use of which protocol?
A ARP
B
ICMP/ICMPv6
C IGMP
D RIP
11 SSH was designed as a replacement for ________________ and other
insecure remote shells, which sent data (including passwords) in
plaintext.
Telnet
12 Which TCP/IP architecture layer makes use of ports?
A Application
B Internet
C Network Interface
D
Transport
13 True or false? TCP is a connection-oriented protocol that creates and
verifies a connection with a remote host before sending information.
True. UDP is connectionless.
14 Which is a simple software-based protocol analyzer?
A The command-line utility ARP
B The command-line utility IPCONFIG
C
The Windows Network Monitor utility
D The Windows Network Control Panel utility
15 Which protocol do Web browsers and Web servers use most often?
A FTP
B
HTTP
C HTTP(S)
D TFTP
16 Which e-mail protocol is used to send and receive e-mail messages
between e-mail servers and used by e-mail client software to send
messages to the server, but never used to retrieve e-mail from a server?
A IMAP4
B POP3
C
SMTP
17 The Internet Assigned Numbers Authority (IANA) implemented
_____________ IPv4 addresses in order to differentiate between the
portion of the IP address that identifies a particular network and the
portion that identifies a specific host on that network.
classful
18 What is the default subnet mask for a Class C IP address?
A 255.0.0.0
B 255.255.0.0
C
255.255.255.0
D 0.255.255.255
19 Which is not a valid subnet mask?
A 255.255.0.0
B 255.247.0.0
C 255.255.255.0
D
255.0.255.0
20 IP address 227.43.76.109 is an example of which of the following
classes of IP addresses?
A Class A
B Class B
C Class C
D
Class D
21 How many octets are part of the network ID when using the subnet
mask 255.255.255.0?
A 1
B 2
C
3
D 4
22 True or false? The IP address 169.254.226.4 can be routed on the
Internet.
False
23 What was introduced to make IPv4 Internet routing more efficient?
A Subnet masks
B Switches
C DHCP
D
CIDR
24 An IPv4 packet sent to all workstations on the network is called a
__________.
A Directed packet
B Unicast
C Multicast
D
Broadcast
25 True or false? A computer will use a default gateway if the destination
IP address is on a different network.
True
26 Which of the following is another name for default gateway?
A Host
B Hub
C
Router
D Switch
27 How many octets are in an IPv4 address?
A 2
B
4
C 8
D 16
28 How many bits are in an octet?
A 2
B 4
C
8
D 16
29 How many bits is an IPv6 address?
A 8
B 32
C 64
D
128
30 Which type of address is written in the standard 4-part dotted decimal
address, followed by /N where N is a number from 0 to 32?
A APIPA
B
CIDR
C IPv4
D IPv6
31 An IPv6 subnet ID is how many bits long?
A 8
B
16
C 32
D 64
32 True or false? A WINS server is necessary for address translation
between IP addresses and network nodes’ FQDNs.
False. WINS is used for NetBIOS names.
33 After installing the DHCP Server service on a domain member server,
what must be done in Active Directory before it begins delivering
leased IP addresses?
A
Authorize it.
B Reinstall Active Directory.
C Activate it.
D Modify the firewall rules.
34 What is the default lease length used by a wired scope created in the
Windows Server 2008 DHCP Service?
A Three hours
B Three days
C
Six days
D Eight days
E 30 days
35 Which of the following are client options that can be set at the scope
level? (Choose all that apply.)
A
DNS
B
WINS
C
ROUTER
D MAC address
Independent practice activity
11 What’s reported by the ipconfig command for each connection?
On LAN 2 – PCI Card, DHCP is not enabled. A manual IPv4 address, along with a
subnet mask, default gateway, and DNS server address are reported. There is no
IPv6 information, as you disabled IPv6 on this NIC.
On Local Area Connection, DHCP is enabled. You have an IPv6 link-local address
(meaning the IPv6 address was self-configured, similar to an IPv4 APIPA address).
The IPv4 address, subnet mask, default gateway, DHCP and DNS server
addresses are reported, along with details regarding your IP lease—when it was
obtained and when it expires.
17 Which TCP/IP configuration parameters are configured for distribution
to clients with an IPv4 address lease?
Router, DNS Server, and DNS Domain Name
19 If you had added a WINS server to your network, which value would
you configure in the Server Options box?
044 WINS.NBNS Servers
