Technologies 1
Facility Systems
Integration
Facility Systems Integration
for
Facilities System Integration
for
Optimized
Energy, Safety, and Comfort
Optimized Energy, Safety, and Comfort
It’s Not
JustJust
Temperature
Controls Anymore!
It’s Not
Temperature Controls
Anymore!
Ed Merwin
Director VYKON Automation, Energy, Security
Tridium, Inc.
Proprietary Information Of Energy 2013
Agenda
• Automation Industry Update
– Protocols & Technologies
• Integrated Intelligent Buildings
– Definition
– Examples
• Real Projects – Real Value
Proprietary Information Of Energy 2013
INDUSTRY UPDATE
Proprietary Information Of Energy 2013
Protocols
•
•
•
•
•
•
•
•
•
•
•
BACnet
Lon Works
Modbus
OPC
SNMP
OBIX
DALI
OpenADR
ONVIF/PSIA
Haystack
Protocol Transition
– Security, Encryption
– IP
Proprietary Information Of Energy 2013
Wireless
• IEE 802.15.4
– Mesh Networking
• Zigbee
• BACnet and Wireless
– BACnet International has approved the ZigBee building automation standard
• Z-Wave
– Residential, Light Commercial
• 6LoWPan
– IPV6, Low Power, Personal Area Network
– Commercial, Industrial
• EnOcean
– Battery-less
• WiFi
– Becoming more affordable at the device level
Proprietary Information Of Energy 2013
ADJACENT& EMERGING
TECHNOLOGIES
Proprietary Information Of Energy 2013
IT Security
• Security Standards and Certification
–
–
–
–
DIACAP
Payment Card Industry Data Security Standard (PCI DSS)
Secure Sockets Layer (SSL)
Transport Layer Security (TLS)
• Encryption
Proprietary Information Of Energy 2013
Mobile Apps
Proprietary Information Of Energy 2013
Mobile
Proprietary Information Of Energy 2013
• IPV6
Emerging Technologies
– Expanding the IP address space
• IPSO Alliance
– IP for smart objects
– IT and Buildings Industry Partners
• Internet Of Things
Proprietary Information Of Energy 2013
Power Technologies
• POE
• EMerge Alliance
– An open industry association
– Adoption of safe DC power distribution in commercial
buildings
Proprietary Information Of Energy 2013
THE INTELLIGENT BUILDING
Proprietary Information Of Energy 2013
What is an Intelligent Building?
OFFICE BLDG.
GOVERNMENT
INDUSTRIAL
HOSPITALITY
HEALTHCARE
EDUCATION
RETAIL
MULTIHOUSING
MUSEUMS
Intelligent buildings apply technologies to improve the building environment and
functionality for occupants/tenants while controlling costs, improving security, comfort and
accessibility.
Efficient, Safe, Comfortable
Proprietary Information Of Energy 2013
Intelligent Building Characteristics
•
•
•
•
•
•
•
•
•
Designed around Users
Improves Security
Enhances Comfort
Provides Energy Savings
Enterprise-wide Energy Monitoring
Everything Communicates
Local Command and Control
Remote Command and Control
Accessible from Anywhere
• The right data to the right people
• Affordable
• Adds Value
Proprietary Information Of Energy 2013
Stakeholder’s Perspective
Site
Maintenance
• Multiple systems to maintain
• Need productivity tools for
day to day work
• Easy migration of legacy
systems
• Limited training time !
• Reduce operating costs
• Maintain high quality service
levels
• Department coordination
• Enterprise integration for
business processes
Energy
• Develop energy saving
strategies
− Identify/ monitor energy usage
− Reduce operating cost
• Deal with utilities, bills, rates
• Allocate costs or bill tenants
IT/ Security
• Network / Server uptime
• Data security & integrity
• Physical Security
− Access control
− Video surveillance
Consulting Eng.
• Open protocol systems
• Reliable solution
• Choice of vendors
• Easy to specify systems and
verify operation
Owner/ CFO
• Planning & Budgeting
• Control operating costs
• Need proven ROI for spending
• Peace of mind!
• Save energy consumption in
datacenters
Proprietary Information Of Energy 2013
What’s a dashboard?
• A well-engineered representation of data that fits
the mission
• Data and artwork that …
– Gets Attention
– Tells a Story
•
•
•
•
At any appropriate location
Using any appropriate technology
To the right audience
With the right metrics, KPIs
Glider
Proprietary Information Of Energy 2013
787 Dashboard
Proprietary Information Of Energy 2013
Role Based Dashboards
Commuter
Tony Stewart
Proprietary Information Of Energy 2013
Role Based Information
CFO
Sustainability Officer
Proprietary Information Of Energy 2013
Location Based Dashboards
Proprietary Information Of Energy 2013
TRADITIONAL BUILDING SYSTEMS
Proprietary Information Of Energy 2013
Disparate Systems
Buildings have many systems
Elevators
Video
Card Access
Electrical
Silos of responsibility
Lighting
Silos of systems
HVAC
No Data Sharing
Proprietary Information Of Energy 2013
Disparate Protocols
Silos of Protocols
ZigBee
LonWorks
DALI
Modbus
BACnet
Proprietary
Proprietary Information Of Energy 2013
INTELLIGENT BUILDING SYSTEMS
Proprietary Information Of Energy 2013
Interoperability of Protocols & Systems
Open Middleware Frameworks
•Normalize Device Protocols.
•Provide tools for integration
•Everything looks the same regardless of protocol or system
MIDDLEWARE
F R A M E W O R K
Access
Modbus
Lighting
LonWorks
Energy
BACnet
HVAC
Proprietary
Proprietary Information Of Energy 2013
Enterprise Integration
Web Browser
Enterprise Applications
Utility and Aggregators
Integration through Web Services
New applications and services
XML, oBIX,
HTTP
OpenADR
Local Area Network
oBIX
IP
Cameras
XML
Modbus
Access Control
Appliance
BACNet
LON
HVAC
Elevator
Control
Energy
Lighting
MODBUS®
Proprietary Information Of Energy 2013
Leverage Technology & Value
Card Access, Event
Scheduling
Weather, Leaks
Pilferage, Food
Safety
Weather, Demand Response
Vandalism, Leaks
Proprietary Information Of Energy 2013
Video for Facilities
• Integrated Video with Equipment Status and Temperature
160 Deg
Burner On
Fuel=Oil
Proprietary Information Of Energy 2013
Video Integration - Transformer Vault
• A set of “eyes” to look at a high risk area before entering
84.6 Deg
IN=13,804 V
OUT=480 V
138 Deg
IN=13,804 V
OUT=480 V
138 Deg
Proprietary Information Of Energy 2013
Re-task Video on Alarm/Event
Freeze Alarm =
Look to Ceiling
Water flow @ Night =
Look toward Restroom Door
Intruder in Frame =
Turn on All Lights,
Inside and Outside
Proprietary Information Of Energy 2013
REAL PROJECTS – REAL VALUE
Proprietary Information Of Energy 2013
C-Store, QSR
Benefits
• Energy & Operational
Savings
• Reduced Equipment
Downtime
• Reduced Risks
• Better Customer
Experience
• Higher Profits
Proprietary Information Of Energy 2013
New Kent VA Rest Area
LEED Gold
Rainwater Harvesting
Grey Water Management
Geothermal
Proprietary Information Of Energy 2013
Manitoba Hydro Place
• LEED Platinum
• Exceeded the original target of 60% energy
savings
• $15 million in annual operating costs savings
• Integrated natural ventilation, shades, blinds,
geothermal, atrium water feature
Proprietary Information Of Energy 2013
City of Raleigh
•HVAC, Lighting, Security, Video,
Metering, Car Charging
•Increased Customer Satisfaction
•Lower Operational Cost
•Energy Visibility & Reduction
Proprietary Information Of Energy 2013
MGM Grand
MGM Grand/Macau
•Yearly Savings in excess of $3.1M
•Over 25 Million kW’s saved
•Theatrical and Building Systems Interface
Proprietary Information Of Energy 2013
San Francisco Public Utilities Commission
uses 55% percent less energy
and consumes 32% less
electrical demand than the
ASHRAE baseline standard.
•
•
•
•
•
•
•
•
LEED Platinum
Exterior sun shades
Natural ventilation with the use of operable
windows
Wind turbines along the façade
Three roof top solar platforms with 684 panels
45% daylight harvesting
Living machine wastewater recycling for flushing use
Rain harvesting for irrigation
Proprietary Information Of Energy 2013
Jim Sinopoli-Realcomm Advisory
SFPUC IBMS
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
13,500 Points
450 Dashboards
Rain harvesting for irrigation
Elevator Monitoring
Waste Water Treatment System
Direct Digital Controls
Digital Network Lighting Controls
Power Monitoring and Control System
Fire Alarm and Detection System
Solar Energy Collector Metering
Wind Energy Power Generator Metering
Interior & Exterior Shade Control System
Weather Station Monitoring System
Window Washing System
Water Reclamation
•
•
•
•
Public information & Education
Demand Response
Alarm management
Building Analytics
Proprietary Information Of Energy 2013
Jim Sinopoli-Realcomm Advisory
Data Center/Telecom
Optimum Uptime
•Data Centers – Communications Huts
•Battery Power and Distribution
•Generation
•Server Racks
•Equipment Health
Proprietary Information Of Energy 2013
Daewoo
Daewoo Automotive
• Collecting data in real time from multiple
meters and various equipment systems
involved in the manufacturing and
production operation
• Processing the data and calculating energy
usage and costs for each vehicle
• Manage the energy efficiency on a per
manufactured car basis
Proprietary Information Of Energy 2013
Industrial Energy Optimization
Air Compressor Management
• Output
• Energy
• Monitoring
Boiler Optimization
•
•
•
•
Honeywell Delphi
Web Interface
PLC interface
O2 Trim
Chiller Plant Management
•
•
•
•
Optimum Energy
Optimized Chiller Selection
Pump Management
Tower Optimization
Printing Press Energy
• Quad Graphics
• Energy Monitoring
• Kw/Ton Paper
Proprietary Information Of Energy 2013
Conclusions
• Value of Integration
– Energy Savings
– Operational Savings – M & O
– Better customer service response
– Make SURE It Makes SENSE
• Energy efficiency, comfort, and safety are now a key
component of facilities planning, design, and operation
• Think about what the technology, applications, and
people can do for you.
– If you can THINK it, you can DO it!
Proprietary Information Of Energy 2013
QUESTIONS
Proprietary Information Of Energy 2013
THANKS!
Proprietary Information Of Energy 2013
