Flange-lok
Installation
Instructions
Quick Installation Guide
00825-0200-4809 rev. DB
Drill the Hole into the Pipe Using a
Drill Bit or Hole Saw
Tag with correct drill hole
size attached to the Annubar
Clean the Area with a Grinder to
Prepare for the Surface for Welding
Mounting Should be Welded So the
Bolt Holes are Parallel to Pipe

The mounting
hardware should be
gapped 1-/16th inch
for welding
– Use weld rod to do this

It should also be
centered over the
drilled hole
Tack Weld the Mounting Hardware
with 4 Equal Length Tacks

Tack weld anywhere on
the mounting hardware

Then again directly across
from the first tack weld

Then on the other 2 sides
3
1
2
Check to See that the Mounting
Hardware is Level and Square

If it’s not, use a
rubber mallet to
lightly adjust the
hardware and
recheck
Verify that the ODF Dimension
Matches What is Listed in the QIG
The ODF is the
dimension from
outside pipe diameter
to face of flange
Complete a Continuous Weld Around
the Perimeter of the Unit
Using a Gasket, Install the Flange on
the Mounting Hardware
Tighten the Studs in Nuts in a Cross
Pattern Until Appropriately Torqued
Insert Studs into the Flange-lok Body
Mark the End of the Sensor With a
Felt Tip Marker
Do not mark if order with special cleaning
(Option Code P2, PA)
Insert the Flowmeter Until the Tip
Contacts the Opposite Side Pipe Wall
Rotate Annubar back and forth.
Remove the Flowmeter and Verify the
Sensor Tip Made Contact
Some of the marker should have been rubbed off.
Align the Flow Arrow and Insert the
Annubar
Insert a Packing Ring Underneath the
Compression Plate and the Follower
The split in the packing ring should face one of the
three studs. Use the Compression Plate and
Follower to compress the packing into the Pak-lok
Body.
Packing Goes Below the
Compression Plate and Follower
Packing
Follower
Compression Plate
Weld Ring
YES!
NO!
NO!
The Next 2 Packing Rings should be
Inserted so the Split is 120۫ Apart
The split in
each
packing ring
should face
a different
stud which
are 120
degrees
apart
Insert the Second Packing Ring with
the Split Facing a Different Stud
Compress it with the Follower and Compression
Plate
Insert the Third Packing Ring with the
Split Facing a Different Stud
Compress it with the Follower and Compression
Plate
Place the Split Ring Washers on the
Studs
Thread the Nuts onto the Studs
Tighten Each Nut ½ Turn in
Succession
Tightened the Nuts Until the SplitRing Washers are Flattened
The SplitRing
washers are
specially
designed to
be flat at the
appropriate
Torque level
for the
Annubar
