GrayBar
Point Heating Presentation
Graeme J Ford
Eng.Tech. MIET. IoD
Managing Director
GrayBar Limited
UK
13/04/2015
1
Welcome








13/04/2015
GrayBar
Who are we ?
Our Customers
Railway Cable Accessories
Railway Points Heating Systems
DC Contact Rail Heating System
Design
Manufacture
Commission
2
GrayBar
Product Locations










13/04/2015
UK – Network Rail
UK – Light Rail & Tram Systems
Northern Ireland
Iarnrod Eireann
Belgium
France
Sweden
Finland
Norway
USA
3
GrayBar
Introduction
13/04/2015

Basic principles of Point Heating
Installations

Why Heat Points ?

How is Point Protection achieved ?
4
GrayBar
Efficient Point Heating


13/04/2015
Many railway switch
points suffer during
the winter months,
from snow and ice
restricting the moving
rails and point
mechanisms
The solution is
efficient and reliable
electric point heating
5
GrayBar
Types Of Point Heating





13/04/2015
High performance Self Regulating
Heaters
Traditional Constant Wattage
Heaters
Constant Wattage Pad & Cartridge
Heaters
Gas Heating
Oil Heating
6
GrayBar
Constant Wattage Heaters







13/04/2015
Disadvantages;
Traditional – Old Technology
Short Fixed Lengths
Limited life span
Constant current draw
Ridged inflexible heater
Poor low temperature performance
12 month product warranty
7
GrayBar
Self-Regulating Heaters








13/04/2015
Advantages;
High Performance polymer
Extremely reliable - no filament
Flexible elements
Long circuit lengths
Long life ( 40+ years)
Efficient power draw
Universally accepted
10 year product and system Warranty
8
GrayBar
Self – Regulating Heater Element
•Assesses ambient/rail temperature along
entire heater length
•Equivalent to millions of hot and cold rail
sensors
•Unlike ‘constant wattage’ heaters cannot
suffer ‘burnout’
•Only draws current required to heat rail at that
specific point
•Flexible heater
•Easy transportation and storage
•Long circuit lengths available
13/04/2015
9
GrayBar
Chamber Test
Self-regulating Point Heating
25
20
15
10
5
0
-5
-10
-15
-20
-25
-30
13/04/2015
1hr
2hr
3hr
4hr
5hr
6hr
7hr
8hr
Air Temp
Current
Rail Temp
10
GrayBar
Poor Heater Positioning
13/04/2015
x
x
11
GrayBar
Correct Heater Strip Positioning

13/04/2015
12
GrayBar
A
A
Rev
Date
By
Description
Ckd
Aprd
Gr a y B a r 
Tel: 01933 676700
Fax: 01933 676800



Project
Catalogue
Drawing Title
Heater Layout – 113lb 4-Way
Drawn By
Stock Rail
Section A - A
13/04/2015
Switch Rail
ALT
Date
Checked By
Date
Approved By
Date
Mar 02
Scale
NTS
Sheet size
A4
Drawing No.
DRO 144
13
This drawing is the property of Gr a y B a r and may not be reproduced
without permission.
GrayBar
13/04/2015
14
GrayBar
Insulated Self–Regulating Heaters




Spring clip fixing
Fibreglass heat
shield;
Improves heat
transfer to rail;
Compliant with
Network Rail
Specification
13/04/2015
15
GrayBar
Fitted Heater Elements

13/04/2015
Example of selfregulating
insulated heaters
and GRP
heatshield fitted
to bullhead rail
points in a DC
electrified area
(Network Rail)
16
GrayBar
Typical UIC 60 type point
heating installation
13/04/2015
17
GrayBar
Heating fitted to HPSS type
point
13/04/2015
18
GrayBar
Point Heating Design






13/04/2015
Utilise all the benefits of Self-regulating
insulated heaters,
Install combined control/transformer
cubicles with simple weather sensors,
Minimise Cabling on-track e.g. use
longer heater elements (up to 22 metres)
and remove the need for rail probes,
Use off-track junction boxes,
Reduce material and installation costs,
Keep maintenance needs to a minimum.
19
GrayBar
Controlling The Heaters




13/04/2015
Transformers to provide the correct
voltage to the heaters
Control cubicle
Associated cabling
Suitable power supply
20
GrayBar
Simple Controls
for Self-regulating Point Heating
Air temperature sensor
 Snow detector
 Set point e.g. +3°
Note
No need for Rail temperature probes
No need for complex switching of
heaters
No PLC required

13/04/2015
21
GrayBar
Basic circuit arrangement
HOT/COLD RAIL
SENSORS
TEMPERATURE
CONTROLLER
CONTACTOR
ONE
TRANSFORMERS
1 TO 3
POINT HEATING,
POINTS 1 TO 3
CONTACTOR
TWO
TRANSFORMERS
4 TO 6
POINT HEATING,
POINTS 4 TO 6
CONTACTOR
THREE
TRANSFORMERS
7 TO 9
POINT HEATING,
POINTS 7 TO 9
CONTACTOR
FOUR
TRANSFORMERS
10 TO 12
POINT HEATING,
POINTS 10 TO 12
MANUAL
OVERRIDE
CONTROL
SYSTEM
PRECIPITATION
SENSOR
REMOTE
CONDITION
MONITORING
WIRELESS
GSM LINK
CONTROL
ROOM
13/04/2015
22
GrayBar
Typical R.C.M. Cable Layout - Complex Design
Pavement
Roadway
Pavement
Supply
Cubicle
Signal
Location
Case
Network Rail
Boundary Fence
Control
Cubicle
Signal Post
Steel
Bridge
Transformer
Barrier/Handrail
Hot and Cold
Rail sensors
13/04/2015
OHL Structure
23
GrayBar
Recommended Point Heating Layout
Pavement
Roadway
Pavement
Supply
Cubicle
Signal
Location
Case
Network Rail
Boundary Fence
Control
Cubicle
Signal Post
110v 8-Core Heater
Feed/Monitoring
Cable
OHL Structure
13/04/2015
24
GrayBar
Premier Cubicle
13/04/2015

GrayBar trackside
control cubicle

All controls in the
cubicle

Can control all
forms of electric
strip point heating
25
GrayBar
Cubicle Transformers
13/04/2015

Integral
transformers
mounted inside
control cubicle

Easy maintenance
in a safe location

All cable
connections are
base entry
26
GrayBar
Channel Tunnel Rail Link

This is a Universal Back
to Back Cubicle
(St.Pancras throat).

Front houses the system
controls

The back houses the
transformers

All in the one location for
a safer and more reliable
maintenance regime
13/04/2015
27
GrayBar
13/04/2015
28
GrayBar
13/04/2015
29
GrayBar
13/04/2015
30
GrayBar
13/04/2015
31
GrayBar
13/04/2015
32
GrayBar
13/04/2015
33
GrayBar
St Pancras Station Approach

13/04/2015
Graybar designed,
manufactured and
commissioned the
point heating for
whole of the high
speed Channel
Tunnel Rail Link
(HS1) between
London and the
Channel Tunnel
34
GrayBar Kits – Clip it and go
Tools needed:
-Hammer
-Screwdriver
Tools supplied in
our heater kit:
-grease brush
-wire brush
-full installation
instructions
13/04/2015
35
GrayBar
Self-regulating heater
around chair block
13/04/2015
36
GrayBar
Off Track Junction Box



For connecting the
heater leads to the
heater feeder cable
Safe method of
working off the track
Easy access to all
cable connections
13/04/2015
37
GrayBar
Heater kit packaging

Complete Heater Kits
In Easy To Transport,
Store & Carry Boxes
13/04/2015
38
GrayBar
Transportation to site
13/04/2015
39
GrayBar
Special Installations
13/04/2015
40
GrayBar
Swingnose Heating

13/04/2015
Swingnose with
380 Watt Per
Metre double
element insulated
self-regulating
heaters with heat
shield (Network
Rail)
41
GrayBar
DC Contact Rail Heating
DRO 03
Side view
Section of rail
Illustration of general arrangement of 750 volt DC conductor rail heating.
Self-Regulating heater circuits up to 200 metres in length
13/04/2015
42
GrayBar
Light Rail & Tram Point Heating


13/04/2015
The light rail and
tram systems in
the UK have
exclusively
selected Graybar
self-regulating
heaters since
1990 e.g…
Croydon (South
London) Tram
43
GrayBar
Tram Points Heating
13/04/2015
44
GrayBar
Tram Control Cubicle

13/04/2015
Stainless steel
modular tram
control cubicle
similar to our
Network Rail
cubicles but
modified for
public street
locations
45
GrayBar
Installing Cables on a
Tram System
13/04/2015
46
GrayBar
Connection box
13/04/2015
47
GrayBar
London Underground, Metronet have recommended and installed the
Graybar self-regulating insulated heating system over many years
13/04/2015
48
GrayBar
London Underground installation
13/04/2015
49
GrayBar
Network Rail Company Line Standard and Code of Practice
RT/E/S/40045 & RT/E/C/45002
Graybar self-regulating point heating
system has product approval:
NR Certificate PA05/688
Performance Specification and Code of Practice
•Allows innovative solutions
•Mandatory Documents
13/04/2015
•Important Note: Graybar self-regulating heaters with a
heat shield have been proven to comply with the low
temperature performance requirements of the standard
50
GrayBar
13/04/2015
51
GrayBar
HPSS Applications
13/04/2015
52
GrayBar
In Action – snow melted
13/04/2015
53
Sweden
13/04/2015
GrayBar
54
GrayBar

End of our presentation

Now the start of the Points Heating Season

Plan now for optimum end results

GrayBar for all Your Points Heating
© GrayBar
13/04/2015
55
GrayBar
Cable Accessories
13/04/2015
56
