Chapter 5 Latch and Flip Flop
Tutorial 5
Question 1
Describe the difference between a combinational logic circuit and a sequential circuit.
Question 2
Draw the output waveform of positive triggered of the JK flip‐flop
Question 3
Draw the 𝑄 𝑎𝑛𝑑 𝑄̅ waveform of positive triggered of the SR flip‐flop
Question 4
The clock and the input waveforms shown below are applied to the D input of a positive edge
triggered D flipflop. Sketch the output waveforms.
