1. For the transistors in this question, assume ππ·π· = 1.8V, ππ πΆππ₯ = 100 µAβπ 2 , ππ πΆππ₯ = 50 µAβπ 2 ,
πππ»,π = 0.4 V, πππ»,π = -0.5 V, ππ = ππ = 0.
a. In the inverter of Fig. 1, the output low level must remain below 100 mV. If (π/πΏ)2 = 3β0.18 µm,
determine the minimum required width of M1 in case πΏ1 = 180 nm. Find the static power
consumption of the inverter in case where πππΏ = 100 mV.
VDD
M2
Vout
Vin
M1
b. Using the device sizes found in a., find the voltage transfer characteristic of the inverter.
2. A large capacitance πΆπΏ = 3 pF is needed to be driven from a minimum size inverter with an input
capacitance πΆππ = 12 fF and propagation delay of 75 ps. In order to drive the capacitance, a twostaged buffer as shown in Fig. 2 is introduced.
a. Assuming that the input capacitance of an inverter is proportional to its size, determine the sizes of
buffer stages that minimizes the propagation delay.
b. Add any number of stages to achieve minimum delay. How many stages would you insert? What is
the resulting propagation delay?
c. Compare the two methods.
3. Using the device model for ππ·π· = 1.8V, ππ πΆππ₯ = 100 µAβπ 2 , ππ πΆππ₯ = 50 µAβπ 2 , πππ»,π = 0.4 V, πππ»,π =
-0.5 V, ππ = ππ = 0, ππ·ππ΄ππ = 0.63 π, ππ·ππ΄ππ = −1 π.
Assume πΆππ is not related to size (which is not the case for real devices) and equal to 12 fF for
simplicity.
Design the CMOS inverter that achieves the propagation delay figures in Q.2.
