Abu Dhabi University
College of Engineering and Computer Science
Mechanical Engineering Program
MEC 302 Mechanics of Material
Homework No. 3 Due date: Monday, October 23rd, 2023
Instructor: Dr. Mohammad Al-Khedher
Note: Submit your individual homework (handwritten) solution on due date.
Chapter 3
Two solid steel shafts (G 5 77.2 GPa) are connected to a coupling disk B and to fixed supports at A and C.
For the loading shown, determine (a) the reaction at each support, (b) the maximum shearing stress in
shaft AB, (c) the maximum shearing stress in shaft BC.
Problem. Two solid shafts made out of steel (G = 77 GPa) are connected by the gears shown.
Find the angle through which end A rotates when TA = 75 N·m.
Chapter 4
Chapter 5
