Sequential control systems and
programmable logic controllers
PLC & HMI
TRAINING CASES
The training cases integrate a programmable logic controller (SIMATIC S7-1200/
BECKHOFF CX 9020) and a HMI (SIMATIC KTP700). Devices configuring and
programming are done using the Siemens programming environment TIA PORTAL or
TwinCAT 3, installed on your PC.
SIEMENS PLC & HMI TRAINING CASE
(S7-1200 & KTP700)
Includes:
- SIEMENS SIMATIC S7-1200 PLC (CPU 1214C): 14DI/10DO/2AI;
- SIEMENS SCALANCE Switch: 4xRJ45 ports;
- SIEMENS SIMATIC HMI KTP700 Basic Color PN:
• 7” TFT display, 65536 colors, PROFINET interface,
key and touch operation.
- Power Supply 230 VAC /24 VDC, 3A;
- Testing elements:
• 8 switches (retentive and pulse) for digital inputs (simulate) and
8 x 4mm safety sockets for external digital inputs;
• 2 potentiometer for signal generation (simulate analog channel input
0...10V) and 1 pair of 4mm safety sockets for external analog input;
• 12 x 4mm safety sockets and 12 LEDs for digital output signals;
• 1 pair of 4mm safety sockets for analog output signals;
• 2 x seven-segment display for analog input/ouput;
• 1 x RJ45 Ethernet interface.
26
