Training system
for programmable logic control (PLC)
Everything in view –
the new S7-1200 combined with a touch
panel in a single device
© Siemens AG 2013, All rights reserved
Automation technology
Training system
for programmable logic control (PLC)
Overview of the Training System
A modular training system for PLC devices in the SIMATIC S7-1200 range, the fully accessible rails can also accommodate a PROFIBUS
or AS-i master module. The KTP600 touch panel has its own Ethernet port to enable communication and programming. A four-way
Ethernet switch makes it possible to combine all the devices in a network.
Benefits to you
• SIMATIC S7-1200 with 1214C DC/DC/DC CPU
• Tough console housing with non-slip feet
• Integrated power supply: 24 V/5 A DC
• Sockets for emergency shut-down loop (to cut off voltage
to output terminals)
• Processing times: 0.1 μs for bit operations, 12 μs for word
operations, 18 μs for floating point arithmetic
• Total remanent data memory (including timers, counters
and flags): 2048 bytes
• Working memory: 50 kilobytes
• Upload memory: 4-Mbyte micro memory card
• Programming language: STEP 7 as of version 10.5
SIMATIC S7-1200 basic equipment
Lucas-Nülle
Automation technology
Adapt Your PLC System to Your Needs
Supplementary components make it possible to link all kinds of bus systems to the PLC module. The basic system is designed in such
a way that both communications modules can be fitted easily.
PROFIBUS-DP master module
AS-i master module
Equipment
• 1 Ethernet/ProfiNet port
• Integrated inputs and outputs
• 14 Digital inputs, 24 V DC, via 4-mm safety sockets
• 14 Latching push buttons for simulating digital inputs
• 2 Analog inputs, 0…10 V, via 4-mm safety sockets
• 1 Potentiometer for simulating analog input
• 10 Digital outputs, 24 V DC, via 4-mm safety sockets
• 1 Analog output, 0…10 V, via 4-mm safety sockets
• Real-time clock
SIMATIC S7-1200 basic equipment
Lucas-Nülle
Ref. no: P5162
Training system for programmable logic control (PLC) –
02/13-1GB (Printed in Germany)
Subject to technical amendments.
Lucas-Nülle GmbH
Siemensstraße 2 · D-50170 Kerpen-Sindorf
Telephone: +49 2273 567-0 · Fax: +49 2273 567-39
www.lucas-nuelle.com
