ARDUINO SERVO LOCK SYSTEM
Description
The Arduino Servo Lock System is a program sketched with the help of the Arduino IDE
application using a servo motor that turns the gears from zero to ninety degrees. This
system will also include an RFID key tag that will be programmed in the events when the
system program scans the correct card, the condition given in the programming matches,
and a command given in that condition then becomes active. As a result, the servo motor
will rotate 90 degrees, the green light will be on, and the buzzer will beep for 500
microseconds. However, when the system program scans an unregistered card, then the
condition of the wrong card will match, which will beep twice for 500 microseconds, and
the red light will be on for 1 second. The "Open" and "Wrong Card" messages will show
on the LCD.
Flow Chart of the Arduino Servo Lock System
Where Soul Empowers Technology
DON BOSCO TECHNICAL INSTITUTE OF VICTORIAS,
INC.
VICMI CO, Vict orias Cit y, 6119 Negros Occidental, Philippines
Tel. 399-2777 | Fax. 399 -3631 | donbosco@dbti - victor ias.edu.ph
Application
The Arduino Servo Lock System works more efficiently on sliding doors due to their
horizontal movement, The system can be implemented to places such as hostels, offices,
and even in classrooms for security purposes.
Proponents

Arceo, Kneil Vernon

Dormitorio, Theo Angelo

Macalalag, Lian Emmanuel

Subardiaga, Jose Iago

Villasis, Ghabriele Kim Grijaldo

Yasa, Mark David Jontongco
