BAE 401/501 Sensors and Controls
Course Introduction
January 10, 2022
Outline
- Introduction to sensors and controls
- Syllabus and schedule
- Lab introduction: Arduino, Matlab
Sensor
A sensor is a device that detects and responds to
some type of input from the physical environment;
provides a readable output signal; usually requires
calibration.
Sensor
Transducer
- Device that converts energy from one form to another.
-
Converts a signal in one form of energy to a signal in
another.
Instrumentation
Design, manufacture, and use of physical instruments for
detection, observation, measurement, automatic control,
automatic computation, communication or data processing.
Control
Control
Control
Calibration
Signal conditioning stage
Signal
path
Output
stage
Transducer
stage
Process
Control signal
Control
stage
System
Examples of
systems?
System
A system can be defined as an arrangement of parts within
some boundary which work together to provide some form
of output from a specified input or input
Course objectives
- Understand basic concepts of measurement systems;
- Become familiar with common types of sensors used in
biological and agricultural applications;
- Learn how to select basic sensing system components;
- Design and implement simple system controllers;
- Complete a semester project to design and build a sensing
and control system.
Syllabus
Lab
- Picking up the lab kits
- Video instructions on Moodle
- Lab sections for completing the lab, troubleshooting
- Review of circuits and introduction to Arduino for the first
two weeks
Calculating resistor for LED circuit
Assume red LED,
VS = 5V
What is the
resistance value that
should be used?
