An Investigation into Interest Rate Modelling: PCA and
Vasicek
clinthoward.github.io/portfolio/2017/08/19/Rates-Simulations
An investigation into rates modelling: PCA and Vasicek models
Interest rates provide a fairly good standard for applying PCA and Vasicek stochastic
modelling, and getting a good feel for the characteristics of these models. We implement
PCA and a Vasicek short-rate model for swap rates, treasury rates and the spread between
these two.
import
import
import
import
import
import
pandas as pd
numpy as np
scipy as sp
matplotlib.pyplot as plt
seaborn as sns
quandl
quandl.ApiConfig.api_key = 'QUANDL_API_KEY'
swap_names = ['FRED/DSWP1',
'FRED/DSWP2',
'FRED/DSWP3',
'FRED/DSWP4',
'FRED/DSWP5',
'FRED/DSWP7',
'FRED/DSWP10',
'FRED/DSWP30']
swap_df = quandl.get(swap_names)
swap_df = swap_df.dropna()
swap_df.columns = ["SWAP1",
"SWAP2",
"SWAP3",
"SWAP4",
"SWAP5",
"SWAP7",
"SWAP10",
"SWAP30"]
swap_df.head()
SWAP1
SWAP2
SWAP3
SWAP4
SWAP5
SWAP7
SWAP10
SWAP
200007-03
7.10
7.16
7.17
7.17
7.17
7.20
7.24
7.24
200007-05
7.03
7.06
7.07
7.07
7.08
7.11
7.14
7.16
DATE
1/19
SWAP1
SWAP2
SWAP3
SWAP4
SWAP5
SWAP7
SWAP10
SWAP
200007-06
7.07
7.13
7.14
7.15
7.16
7.19
7.21
7.21
200007-07
7.01
7.04
7.06
7.06
7.07
7.10
7.14
7.14
200007-10
7.04
7.09
7.11
7.13
7.14
7.17
7.20
7.19
DATE
swap_df2 = swap_df.copy()
swap_df.plot(figsize=(10,5))
plt.ylabel("Rate")
plt.legend(bbox_to_anchor=(1.01, 0.9), loc=2)
plt.show()
sns.heatmap(swap_df.corr())
plt.show()
2/19
Principal Component Analysis - Covariance Method
Implementing the PCA covariance algorithm is quite straight forward.
1. Detrend the dataset by removing the mean of each column from our observations
2. Calculate the covariance/correlation matrix
3. Calculate the eigenvectors & eigenvalues which diagonalise the
covariance/correlation matrix. We are wanting to solve V−1CV=DV−1CV=D
4. Sort eigenvectors and eigenvalues based on decreasing eigenvalues (i.e. we take the
eigenvalue contributing the most variance to out dataset as the first eigenvalue and
so forth)
def PCA(df, num_reconstruct):
df -= df.mean(axis=0)
R = np.cov(df, rowvar=False)
eigenvals, eigenvecs = sp.linalg.eigh(R)
eigenvecs = eigenvecs[:, np.argsort(eigenvals)[::-1]]
eigenvals = eigenvals[np.argsort(eigenvals)[::-1]]
eigenvecs = eigenvecs[:, :num_reconstruct]
return np.dot(eigenvecs.T, df.T).T, eigenvals, eigenvecs
scores, evals, evecs = PCA(swap_df, 7)
One of the key interpretations of PCA applied to interest rates, is the components of the
yield curve. We can effectively attribute the first three principal components to:
1. Parallel shifts in yield curve (shifts across the entire yield curve)
2. Changes in short/long rates (i.e. steepening/flattening of the curve)
3. Changes in curvature of the model (twists)
evecs = pd.DataFrame(evecs)
plt.plot(evecs.ix[:, 0:2])
plt.show()
3/19
One of the key features of PCA is the ability to reconstruct the initial dataset using the
outputs of PCA. Using the simple matrix reconstruction, we can generate an
approximation/almost exact replica of the initial data.
reconst = pd.DataFrame(np.dot(scores,evecs.T), index=swap_df.index,
columns=swap_df.columns)
plt.plot(reconst)
plt.ylabel("Rate")
plt.title("Reconstructed Mean-Subtracted Dataset")
plt.show()
4/19
for cols in reconst.columns:
reconst[cols] = reconst[cols] + swap_df2.mean(axis=0)[cols]
plt.plot(reconst)
plt.xlabel("Rate")
plt.title("Reconstructed Initial Dataset")
plt.show()
scores = pd.DataFrame(np.dot(eigenvecs.T, swap_df.T).T, index=swap_df.index,
columns=swap_df.columns)
scores.plot()
plt.ylabel("Principal Component Scores")
plt.show()
5/19
We see that the first 3 principal components account for almost all of the variance in the
model, and thus we should just be able to use these three components to reconstruct our
initial dataset and retain most of the characteristics of it.
plt.plot(evals)
plt.ylabel("Contribution to Variance")
plt.xlabel("Principal Component")
plt.show()
We implemented the raw model above, but we can also use the sklearn implementation to
obtain the same results.
import sklearn.decomposition.pca as PCA
pca = PCA.PCA(n_components=3)
pca.fit(swap_df)
PCA(copy=True, iterated_power='auto', n_components=3, random_state=None,
svd_solver='auto', tol=0.0, whiten=False)
plt.plot(pca.explained_variance_ratio_)
plt.xlabel("Principal Component")
plt.ylabel("Explained Variance")
plt.show()
plt.plot(pca.components_[0:3].T)
plt.xlabel("Principal Component")
plt.show()
vals = pca.transform(swap_df)
plt.plot(vals[:,0:3])
plt.show()
6/19
7/19
Treasury Rates
We can implement the same method that we did for swaps, to constant maturity treasury
rates.
treasury = ['FRED/DGS1MO',
'FRED/DGS3MO',
'FRED/DGS6MO',
'FRED/DGS1',
'FRED/DGS2',
'FRED/DGS3',
'FRED/DGS5',
'FRED/DGS7',
'FRED/DGS10',
'FRED/DGS20',
'FRED/DGS30']
treasury_df = quandl.get(treasury)
treasury_df.columns = ['TRESY1mo',
'TRESY3mo',
'TRESY6mo',
'TRESY1y',
'TRESY2y',
'TRESY3y',
'TRESY5y',
'TRESY7y',
'TRESY10y',
'TRESY20y',
'TRESY30y']
treasury_df.plot(figsize=(10,5))
plt.ylabel("Rate")
plt.legend(bbox_to_anchor=(1.01,.9), loc=2)
plt.show()
8/19
sns.heatmap(treasury_df.corr())
plt.show()
treasury_df2 = treasury_df.ix[:, 3:-2]
treasury_df2 = treasury_df2.dropna()
comb_df = treasury_df2.merge(swap_df2, left_index=True, right_index=True)
pca_t = PCA.PCA(n_components=6)
pca_t.fit(treasury_df2)
PCA(copy=True, iterated_power='auto', n_components=6, random_state=None,
svd_solver='auto', tol=0.0, whiten=False)
9/19
plt.plot(pca_t.explained_variance_ratio_)
plt.ylabel("Explained Variance")
plt.xlabel("Principal Component")
plt.show()
plt.plot(pca_t.components_[0:3].T)
plt.xlabel("Principal Component")
plt.show()
vals_t = pca_t.transform(treasury_df2)
plt.plot(vals_t[:,0:3])
plt.show()
10/19
Spreads
We see above fairly similar PCA results between the swap rates and treasury rates.
Perhaps a more interesting investigation is the spread between these two rates. We expect
that the spread of swap over treasury should mostly be positive, given that swaps are
being priced off bank credit whilst constant treasuries should be priced off the
Government credit.
spread = [comb_df.SWAP1-comb_df.TRESY1y,
comb_df.SWAP2-comb_df.TRESY2y,
comb_df.SWAP3-comb_df.TRESY3y,
comb_df.SWAP5-comb_df.TRESY5y,
comb_df.SWAP7-comb_df.TRESY7y,
comb_df.SWAP10-comb_df.TRESY10y]
spread_df = pd.DataFrame(np.array(spread).T, index=comb_df.index,
columns = ["SPREAD1y", "SPREAD2y", "SPREAD3y",
"SPREAD5y", "SPREAD7y", "SPREAD10y"])
spread_df.plot()
plt.ylabel("Swap Spread Over Treasury")
plt.show()
11/19
pca_spread = PCA.PCA(n_components=6)
pca_spread.fit(spread_df)
PCA(copy=True, iterated_power='auto', n_components=6, random_state=None,
svd_solver='auto', tol=0.0, whiten=False)
Interestingly, we see fairly similar results between the spread PCA and swap/treasury
PCA.
plt.plot(pca_spread.explained_variance_ratio_)
plt.xlabel("Principal Component")
plt.ylabel("Explained Variance")
plt.show()
plt.plot(pca_spread.components_[0:3].T)
plt.xlabel("Principal Component")
plt.show()
vals_s = pca_spread.transform(spread_df)
plt.plot(vals_t[:,0:3])
plt.show()
12/19
13/19
Rates Simulation
Of interest in spreads is the strong mean reversion we see. We can use a pretty basic
stochastic model, the Vasicek short-rate model to simulate out spreads. The typical
implementation uses MLE to derive out the key parameters of the following model:
drt=κ(θ−rt)dt+σdWdrt=κ(θ−rt)dt+σdW where κκ represents the mean reversion
strength, θθ is the long-run mean and σσ is the volatility. The basic approach is to
calibrate kappa, theta and sigma based on a historical dataset and then use it in Monte
Carlo modelling of rate paths.
Below code is an implementation from Puppy Economics in Python.
We simulate the rates path using a closed form solution:
rti=rti−1exp(−κ(ti−ti−1))+θ(1−exp(−κ(ti−ti−1)))+Z√σ2(1−exp(−2κ(ti−ti−1)))2κ
rti=rti−1exp(−κ(ti−ti−1))+θ(1−exp(−κ(ti−ti−1)))+Zσ2(1−exp(−2κ(ti−ti−1)))2κ
where Z∼N(0,1)Z∼N(0,1)
def VasicekNextRate(r, kappa, theta, sigma, dt=1/252):
# Implements above closed form solution
val1 = np.exp(-1*kappa*dt)
val2 = (sigma**2)*(1-val1**2) / (2*kappa)
out = r*val1 + theta*(1-val1) + (np.sqrt(val2))*np.random.normal()
return out
def VasicekSim(N, r0, kappa, theta, sigma, dt = 1/252):
short_r = [0]*N # Create array to store rates
short_r[0] = r0 # Initialise rates at $r_0$
for i in range(1,N):
short_r[i] = VasicekNextRate(short_r[i-1], kappa, theta, sigma, dt)
return short_r
14/19
def VasicekMultiSim(M, N, r0, kappa, theta, sigma, dt = 1/252):
sim_arr = np.ndarray((N, M))
for i in range(0,M):
sim_arr[:, i] = VasicekSim(N, r0, kappa, theta, sigma, dt)
return sim_arr
def VasicekCalibration(rates, dt=1/252):
n = len(rates)
# Implement MLE to calibrate parameters
Sx = sum(rates[0:(n-1)])
Sy = sum(rates[1:n])
Sxx = np.dot(rates[0:(n-1)], rates[0:(n-1)])
Sxy = np.dot(rates[0:(n-1)], rates[1:n])
Syy = np.dot(rates[1:n], rates[1:n])
theta = (Sy * Sxx - Sx * Sxy) / (n * (Sxx - Sxy) - (Sx**2 - Sx*Sy))
kappa = -np.log((Sxy - theta * Sx - theta * Sy + n * theta**2) / (Sxx 2*theta*Sx + n*theta**2)) / dt
a = np.exp(-kappa * dt)
sigmah2 = (Syy - 2*a*Sxy + a**2 * Sxx - 2*theta*(1-a)*(Sy - a*Sx) + n*theta**2
* (1-a)**2) / n
sigma = np.sqrt(sigmah2*2*kappa / (1-a**2))
r0 = rates[n-1]
return [kappa, theta, sigma, r0]
params = VasicekCalibration(spread_df.ix[:, 'SPREAD10y'].dropna()/100)
kappa = params[0]
theta = params[1]
sigma = params[2]
r0 = params[3]
years = 1
N = years * 252
t = np.arange(0,N)/252
test_sim = VasicekSim(N, r0, kappa, theta, sigma, 1/252)
plt.plot(t,test_sim)
plt.show()
15/19
We can simulate starting from r0=lastobservedvaluer0=lastobservedvalue and generate a
series of paths which “forecast” out potential rate paths from today.
M = 100
rates_arr = VasicekMultiSim(M, N, r0, kappa, theta, sigma)
plt.plot(t,rates_arr)
plt.hlines(y=theta, xmin = -100, xmax=100, zorder=10, linestyles = 'dashed',
label='Theta')
plt.annotate('Theta', xy=(1.0, theta+0.0005))
plt.xlim(-0.05, 1.05)
plt.ylabel("Rate")
plt.xlabel("Time (yr)")
plt.show()
16/19
To observe the mean reverting nature of the model, we can specify r0r0 further away from
theta. We can clearly see that the rates are being pulled towards theta over time, and the
speed of this reversion is controlled by the magnitude of kappa. The larger kappa, the
quicker mean reversion we’d expect to see. The larger sigma is, the more volatility we
expect to see and the wider potential rate distributions. ***titles on below need to be
fixed.
M = 100
rates_arr = VasicekMultiSim(M, N, -0.01, kappa, theta, sigma)
plt.plot(t,rates_arr)
plt.hlines(y=theta, xmin = -100, xmax=100, zorder=10, linestyles = 'dashed',
label='Theta')
plt.annotate('Theta', xy=(1.0, theta+0.0005))
plt.xlim(-0.05, 1.05)
plt.ylabel("Rate")
plt.xlabel("Time (yr)")
plt.show()
M = 100
rates_arr = VasicekMultiSim(M, N, -0.01, kappa*5, theta, sigma)
plt.plot(t,rates_arr)
plt.hlines(y=theta, xmin = -100, xmax=100, zorder=10, linestyles = 'dashed',
label='Theta')
plt.annotate('Theta', xy=(1.0, theta+0.0005))
plt.xlim(-0.05, 1.05)
plt.ylabel("Rate")
plt.xlabel("Time (yr)")
plt.title("Kappa scaled up 5 times")
plt.show()
17/19
M = 100
rates_arr = VasicekMultiSim(M, N, -0.01, kappa, theta, sigma*5)
plt.plot(t,rates_arr)
plt.hlines(y=theta, xmin = -100, xmax=100, zorder=10, linestyles = 'dashed',
label='Theta')
plt.annotate('Theta', xy=(1.0, theta+0.0005))
plt.xlim(-0.05, 1.05)
plt.ylabel("Rate")
plt.xlabel("Time (yr)")
plt.title("Kappa scaled up 5 times")
plt.show()
← Previous Post
Next Post →
18/19
19/19
