PL 60
COAXIAL CEILING SPEAKER
DESCRIPTION
The PL 60 is a ceiling speaker featuring elegant design that can be flushmounted in false ceilings or panels. It can also be attached to walls or
ceilings using a special accessory for surface mount installation.
The PL 60 incorporates a 160 mm (6”) dual cone loudspeaker that improves
high frequency extension, and it is equipped with a line transformer that
enables direct connection to constant voltage systems at 70 V or 100 V.
When connected to a 100 V line, its power can be selected among the values
6 W or 3 W through the selection 4 inputs wire.
Installation is quick and easy thanks to a special three-terminal system that
avoids the need for using screws or other attachment elements.
MAIN APPLICATIONS
MAIN FEATURES
•
•
•
•
•
•
•
•
•
•
•
•
•
•
High intelligibility Speech and Background music
Schools
Shopping malls
Hospital
Museums
Hotels
Office building
SPECIFICATIONS
Loudspeaker
Power (on 8 Ohm load)
Power
Sensivity
Mx. SPL (6 W / 1 m)
Frequency Response
Angle of coverage
Connector
Body colour
Main body material
Grill material
Dimensiones
Flush-mounting hole
Max ceiling thickness
Net weight
Operating temperature
Relative humidity
6” Dual-cone wide band transducer
6 / 12 W (RMS / Music power)
6 W - 3 W (100V)
91 dB (1 W / 1 m)
102 dB(A) (1 m / POWER MAX)
110 Hz – 20 kHz
150° / 110° / 70° @ 1 / 2 / 4 kHz (hor.)
5 pin terminal strip
White RAL 9003
Plastic
Steel
Ø 204 mm x 75 mm
Ø 92 mm
25 mm
0.55 kg
-25° to +55°
90% non condensing
6” Dual-Cone wide-band speaker
6 / 10 Watt (RMS/Music Power)
110 Hz ÷ 20 kHz
102 dB (1 m / POWER MAX) max. SPL
Incl. 100V transformer multitap
Easy to install
Simple power settings
PL 60
Response 1W/1m
Beamwidth vs. Frequency
110
360
330
300
100
Coverage Angle (Deg.)
270
dB SPL
90
80
240
210
180
150
120
90
70
60
60
30
20
PL60
100
1000
Frequency (Hz)
10000
0
100
1000
Frequency (Hz)
Directivity Index and Q
10000
Normalized off-axis Response
20
100
5
18
0
16
-5
Total Q
10
8
6
Directivity index Di, dB
12
10
Attenuation in dB
14
-10
-15
-20
4
2
1
100
1000
Frequency (Hz)
10000
0
-25
-30
100
±10 degrees
±20 degrees
±30 degrees
±40 degrees
±50 degrees
±60 degrees
1000
Frequency (Hz)
10000
PL 60
HORIZONTAL 1/3 POLAR PLOT
1/3 Octave Polars
315
250
200
0°
330°
30°
300°
270°
0
1/3 Octave Polars
60°
-6 -12 -18 -24 -30 -36 -42 -48
-48 -42 -36 -30 -24 -18 -12 -6
90°
270°
0
-6 -12 -18 -24 -30 -36 -42 -48
150°
2500
2000
1600
300°
270°
0
1/3 Octave Polars
-48 -42 -36 -30 -24 -18 -12 -6
240°
0
120°
150°
210°
180°
0
-6 -12 -18 -24 -30 -36 -42 -48
270°
0
240°
5000
4000
3150
30°
120°
1/3 Octave Polars
-48 -42 -36 -30 -24 -18 -12 -6
240°
0
120°
150°
210°
180°
150°
10000
8000
6300
0°
330°
30°
300°
60°
-6 -12 -18 -24 -30 -36 -42 -48
90°
0
180°
300°
90°
-48 -42 -36 -30 -24 -18 -12 -6
210°
0°
330°
60°
-6 -12 -18 -24 -30 -36 -42 -48
270°
90°
0
60°
180°
30°
30°
300°
150°
210°
0°
330°
-48 -42 -36 -30 -24 -18 -12 -6
1250
1000
800
0°
330°
120°
180°
1/3 Octave Polars
1/3 Octave Polars
60°
240°
120°
210°
30°
300°
0
240°
630
500
400
0°
330°
90°
270°
0
60°
-6 -12 -18 -24 -30 -36 -42 -48
-48 -42 -36 -30 -24 -18 -12 -6
240°
0
120°
150°
210°
180°
90°
1.0-J-E
PL 60
PART NUMBERS
POWER SELECTION
13110214
Define the colour cable to selected the chosen power value
referring to the 100 V line (among 1.5 W – 3 W – 6 W – 12 W) so
the correspondence impedance (among 6666 Ω – 3333 Ω - 1666
Ω – 833 Ω)
DimensionS (All data are in mm)
PL 60 - 23
PL80/A -24
6
130
3
180
204
244
75
100
PL 81/A - 27
PL 8X - 26
8
204
3
224
247
244
88
SCHEMATICS
112
DS 313/WT - 30
• CE comply with European Community Directive 73/23/EEC and 93768/EEC
• Environmental protection IP 40 homologation
12
• Self-Extinguishing
plastic according to UL 94V0
• Speaker data according to IEC 268-5
• Safety according to IEC EN 60065:2002
156
189
16
6 W (70 V)
INPUT
200
3 W (70 V) - 6 W (100 V)
1,5 W (70 V) - 3 W (100 V)
8 Ohm
230
WOOFER
ACCESSORIES (included)
0
• Connection
73 Terminal
• Steel Grill
DM 61 - 33
127
DM 41 - 32
ACCESSORIES
200(not included)
150
104
266
CERTIFICATIONS AND APPROVALS
PL 70BS - 29
230
266
• A1360 Adapter for surface mount installation (code 133 20 107)
289
197
INSTALLATION NOTES
Once removed the frontal grille the speaker can be simply
130 and quickly
115
installed into a hole in the ceiling cavity, secured by 3 lead-screw rotating
clamps.
The electrical connections are clearly labelled and made through screw
terminals block.
The power can be easily selected by using common wire and the positive wire
using the legend of the power available on the speaker.
Before the installation, verify that behind the false-ceiling there is enough
room for loudspeakers: with respect to the loudspeaker front flange surface
plane, an empty space at least 65 mm depth is required.
The PL 60 is intended for indoor installations only.
RCF products are continually improved. All specifications are therefore subject to change without notice.
177
216
www.rcf.it
