Standard, Codes &
Regulations
Learning Outcome 2
Compare and contrast current industry
standards, codes and regulations.
www.convergencetechnologycenter.org
DUE 402356
Regulations

Mandatory rules


Issued by official organization
FCC


Federal Communications Commission
Enforcement of codes and Laws

AHJ

Authority having jurisdiction
www.convergencetechnologycenter.org
Standards


Universally agreed guidelines
Specifications and guidelines


Not mandatory rules
Usually written by organizations in a particular industry


Make products or technologies the same
Organizations




ANSI
TIA
IEEE
HTI


Industry standards
Manufacturer standards
www.convergencetechnologycenter.org
Codes


Rules
Protect consumers


Provide minimum safety requirements
National or local enforcement

National Electrical Code - NEC
www.convergencetechnologycenter.org
Standards

Organizations

ANSI – www.ansi.org


TIA – www.tiaonline.org


American National standards Institute
Telecommunications industry Association
EIA – www.eia.org

Electronic Industries Alliance
www.convergencetechnologycenter.org
ANSI/TIA/EIA Standards

ANSI/TIA/EIA-570-A


ANSI/TIA/EIA-568-B


Residential Telecommunications Cabling standard
Commercial Building Telecommunications
ANSI/TIA/EIA-568-A

Commercial Building Telecommunications
Pathways and Spaces
www.convergencetechnologycenter.org
Product Ratings

3 Categories
 Listed


Classified


Classification by Industry
Recognized


Product has been tested
Certified for equipment use
Tests
 Mechanical
 Electrical
 Thermal
 Performance
 Hazards
 Regulation codes
www.convergencetechnologycenter.org
Implementation





New construction
Additions
Remodeling
Single Unit
MDU – Multi-dwelling unit



Townhouse
Condominium
Apartments
www.convergencetechnologycenter.org
570-A











Voice
Data
Video
Multimedia
Home Automation Systems
Environmental control
Security
Audio
TV
Sensors
Alarms
www.convergencetechnologycenter.org
570-A

Design requirements



Star topology for cable
568-A outlets & connectors
1 outlet to each major part of house




Kitchen
Master bedroom
Living room
Cable


UTP
Coax
www.convergencetechnologycenter.org
570-A Section 4

Cable Grade Systems

Grade I

Minimum requirements for telecommunications



1 Cat 5
1 Coax
Grade II

Minimum requirements for advances
telecommunications


2 Cat 5E
2 Coax
www.convergencetechnologycenter.org
570-A Sections

Section 5


Section 6


Multi-Dwelling Units
Section 7


Single Residential Unit Cabling
Residential Cabling components
Section 8

General Requirements



Annexes



Minimum bend radius
Tension on cable
Fiber-optic
Requirements to do field tests
Addenda


Security Cabling for residences
Whole-Home Audio Cabling for Residences
www.convergencetechnologycenter.org
570-A Terms

AP – Access Provider


NID – Network Interface Device


Demarcation Point
ADO – Auxiliary Disconnect Outlet


Provide telecommunications to customer
Customer can disconnect from provider
SMC – Structured Media Center

All devices connect
www.convergencetechnologycenter.org
Codes

Building codes & Fire codes

-
Inconsistent application of codes
City or County Government
-
-
City
County
State
National
Mix
Note : Consult local authority for proper code
www.convergencetechnologycenter.org
NEC

National electrical Code



3 year revision
Protection of people and property from hazards
(electrical)
Local Municipality enforces code



Local
State
National
www.convergencetechnologycenter.org
NEC - Used







HTI
Electrical Inspectors
Fire marshals
Lawyers
Insurance companies
Manufacturers
Suppliers
www.convergencetechnologycenter.org
Organizations

UL – www.ul.com

Underwriter Laboratories



Non-profit
Test devices for safety
IEEE – www.ieee.org www.standards.ieee.org

Institute of Electrical and Electronic Engineers

Publishes standards on electrical and electronic equipment



IEEE 802.3 Ethernet
IEEE 1394 FireWire
ISO - www.iso.org/iso/en/ISOOnline.frontpage

International Organization for Standardization

Develops global standards in electrical and electronic field

ISO/IEC Standard 11801 – Cabling standards
www.convergencetechnologycenter.org
Regulations

Telecommunications wiring


FCC & OSHA regulate
FCC

Federal Communications Commission

Handle equipment manufacturing





Telephone
Modems
Wireless devices
TV – check back of TV
OSHA – www.osha.gov

or www.allaboutosha.com
Occupational Safety and Health Administration


Health and Safety of workers
Federal and State program
www.convergencetechnologycenter.org
Codes


Home codes regulated by NFPA
NFPA

National Fire Protection Association



International organization
Develops fire safety codes and standards
NFPA Codes and standards

ANSI/NFPA 70 – NEC – National Electrical Code



ANSI/NFPA 71
ANSI/NFPA 72 – National Fire Alarm Code


http://www.nfpa.org/aboutthecodes/AboutTheCodes.asp?DocNum=70
http://www.nfpa.org/aboutthecodes/AboutTheCodes.asp?DocNum=72
ANSI/NFPA 75 – Protection of Information Technology Equipment

http://www.nfpa.org/aboutthecodes/AboutTheCodes.asp?DocNum=75
www.convergencetechnologycenter.org
Questions: Feel free to contact
the creators of this material


Julian Carranza, Professor, El Centro
College, jcarranza@dcccd.edu
Michael Harsh, Professor, Collin County
Community College, mharsh@ccccd.edu
www.convergencetechnologycenter.org
