Osborne Reynolds Fluid Flow
Demonstration
Senior Design Project
EML 4552
Group #1
John Curry
Antoine Berret
Edmund Laryea
Michael McIntyre
Topics of Discussion
Project Proposal
Design Selection
Final Design
Results
Conclusion
Project Proposal
This project will furnish a bench-top unit that
demonstrates laminar, transitional, and turbulent
flow in a pipe using visualization technique
similar to the classic experiments of Osborne
Reynolds. The unit will be used for classroom
demonstrations for beginning (or aspiring!)
engineers. Hence, it must be safe, rugged, selfcontained, and portable. The unit must be
constructed of readily available parts (e.g., from a
hardware store) and cost less than $200.
Design Selection
Design Selection
(α-Prototype)
Design Selection
(Basic Set-up)
Final Design
(Testing)
Final Design
(Testing)
Final Design
(Testing)
Final Design
Final Design
(Engineering Drawing1)
Final Design
(Engineering Drawing2)
Final Design
(Engineering Drawing3)
Final Design
(Engineering Drawing4)
Final Design
(Design Construction)
Final Design
(Design Construction)
Final Design
(Design Construction)
Results
Theoretical Values
Flow Type
Laminar Flow (Re=1800)
Transitional Flow (Re=2300)
Turbulent Flow (Re=4200)
LPM
1.62
2.07
3.78
Testing Values
Flow Type
Laminar Flow (Re=1620)
Transitional Flow (Re=2300)
Turbulent Flow (Re=12969)
LPM
1.46
2.07
11.7
Results
Produced laminar, transitional, and
turbulent flow regimes
Flow regimes were clearly visible
Reynolds Number for each regime was
within the expect values
Recommendations
Syringe Pump
Better throttling valves
Variable output pump
Dye filtering system (closed system)
Better injection needle
Two additional flanged tubes
(1/4”, 1/2”)
