167th Theater Sustainment
Command (TSC)
VR 15 Sustainment Concept
25 APR 15
They Rely On Us!
AGENDA
• Mission
• Task Organization
• Concept Overview
• JOA Overview
• Concept of Support per Class of Supply/Service
4 MAY 15
They Rely On Us!
167th TSC Mission
167th Theater Sustainment Command (167 TSC)
deploys sustainment elements to Fort Riley, KS and
Forbes Field to conduct mission command for
theater opening and theater distribution in support
of T-10 forces responding to the NUDET in Kansas
City, MO.
Purpose: 167th TSC sustains Department of Defense T10 forces in order to restore stability within the JOA.
4 MAY 15
They Rely On Us!
UNCLASSIFIED//FOUO
Task Organization
Assigned
OPCON
USNORTHCOM
COORDINATING
PTDO
USARNORTH/
JFLCC
JFLCC
FWD
++
167
TSC
TSC
(FWD)
X
I
SUST
43
(-)
II
541
258
HR
CSSB
I
24
165
TC
MCT
I
1
4UNCLASSIFIED//FOUO
MAY 15
SMC
They Rely On Us!
EXERCISE-EXERCISE-EXERCISE
167th THEATER SUSTAINMENT COMMAND
CDRs Assessment:
167 TSC(FWD) will arrive at 1500 CST at the BSI.
Theater opening coordination and JRSOI are our
logistic priorities over the next 72 hours.
Priority of SPT Priority of Effort Sustainment
- JTF-CS HQ
- Theater Opening
- PPE / CL8
- 167 TSC
- Force Deployment - CL III (B)
SUSTAINMENT CCIRs
• Movement Delays in excess of 12hrs
• Media Event that negatively impacts CSS
• Safety of Use/Flight message which limits
operational capability
• Critical Equipment readiness rate below 85%
Mobility Assessment
•
Roads
•
Airports (Forbes Field)
•
Bridges
•
Maritime (SPODs)
N/A
Critical
Equipment
J T F - C S ( C UM ULA T IV E )
NOMENCLATURE
R Q D O H N M C F M C O R R a t e A V A IL
Suburban (IRV)
2
UH-60A/L:
UH-60A (MEDEVAC)
0
# DIV/0!
0
# DIV/0!
AGPU (Grnd Pw Unit)
0
# DIV/0!
FUEL SMTRLR: 5K GAL
0
# DIV/0!
D7 Dozers
0
# DIV/0!
FL 10K
0
# DIV/0!
M978 HEMMT FUELER
0
# DIV/0!
5 TON MTV
0
# DIV/0!
Dump TrucKs
BLOOD BANK REFER
0
# DIV/0!
0
# DIV/0!
MILVAN REFER
0
# DIV/0!
FREEZER
0
# DIV/0!
> 90%
4 MAY 15
2
89-70%
69%-50%
Per FM 100-17-3, Appendix N
2
100%
< 50 %
UNCLASSIFIED/FOUO
UNCLASSIFIED//FOUO
SUSTAINMENT
Theater Supported:
Title 10 Forces
TSC Personnel:
1,219 PAX
332 PAX
JRSOI
• 31 units, 1,062 PAX, 408 PCS
due in the next 24hrs to the BSI
OCS
• 43d SB: submitted 09/ approved
00 / in progress 09
• JTF-CS: submitted 00 / approved
00 /in progress 00
• Critical Requests: ICE, ReferVans
OPERATIONS
Current Operations
• Provided Concept of
Support Brief
• JRSOI began (1,219 PAX,
408 pieces of equip)
• Refine Concept of Support
• Coordinate and streamline
Theater Distribution efforts
• Conduct Theater
Sustainment Board 5 MAY
15 (1400 CST)
Future Operations
Next 24:
• Continue to refine Theater
Distribution
• Conduct Mission Analysis
on potential response for
second crisis event within
CONUS
Location
Bulk CL III B MRE
Water gals(JP8) Cases
Bottled
PPE
Water
(sets)
(cases)
BSI
Ft Riley
APOD
Forbes Field
• Initiate development of
redeployment and JOA
close-out plans/procedures
Next 48 - 96 HRS:
• Movement Tracking
• Theater Sustainment
• DLA begin fuel push
> 66%
They Rely On Us!
65-41%
40-21%
JOA SO = 8 DOS (GS 5 +DS 3)
DTG: 041630ZMAY15
22-0%
JOA
Worth
Atchison
Nodaway
Putnam
Mercer
Harrison
Gentry
Schuyler Scotland
Sullivan
Holt
Missouri PDD Counties
Adair
Knox
Grundy
Andrew
DeKalb
Clinton
Lewis
Kansas PDD Counties
Daviess
Linn
Macon
Livingston
Buchanan
JOA LEGEND
Clark
Kansas JOA Counties
Marion
Shelby
Caldwell
Chariton
Platte
Clay
Ray
Randolph
Carroll
Monroe
Ralls
Pike
FT Riley, BSI
Howard
Saline
Lafayette
Boone
Kansas City
APOD -KFOE
Callaway
Cooper
Johnson
APOE -KLWC
Pettis
Cass
Cole
Morgan
Henry
Osage
Benton
Bates
St. Clair
Hickory
Miller
Dallas
Polk
Franklin
Jefferson
Phelps
Iron
Laclede
St.
Francois
Perry
Cape
Girardeau
Madison
Dade
Greene
Lawrence
Webster
Christian
Barry
Wright
Reynolds
Texas
Bollinger
Shannon
Springfield
Newton
McDonald
Ste.
Genevieve
Dent
Barton
Jasper
Wayne
Carter
Douglas
Howell
Stone
Taney
Ozark
• APOD(s)
• Forbes Field - KFOE
• 60 Miles to KC
• 70 Miles to BSI
St. Louis
Crawford Washington
Pulaski
St. Louis City
Warren St. Charles
Maries
Camden
Vernon
Cedar
Lincoln
Jefferson City
Moniteau
.01 cGy/hr
Gasconade
Jackson
Montgomery
Audrain
GZ
• BSI:
• FT Riley, KS
• 130 Miles to KC
Oregon
Ripley
Scott
Stoddard
Mississippi
• APOE
• Lawrence Municipal
Airfield - KLWC
• 38 Miles to KC
• 110 Miles to BSI
Butler
New
Madrid
Pemiscot
Dunklin
4 MAY 15
They Rely On Us!
BSI FT Riley
Location: Kansas
Estimated up to 2.5k
• CL IIIB
• Storage:
• 200k JP8
• 20k MOGAS
• 50k liters bulk water
• O/H Balance:
• 63k JP8
• 20k MOGAS
• 1,000k bulk water
• CL I
• MRE: 30k cases O/H
• ICE: TBD
• Bot H2O: TBD cases
4 MAY 15
They Rely On Us!
Problem Areas
• Facilities Damage (FACDAM)
• DCRF operating in areas with excessive rubble and
debris on the roads
• Local LOC damaged in and around FOBs
• MSR/ASR congested with displaced civilians
• Possible shortage of supplies (by class)
• CL IX – concerns with tires and air filters
• CL I – concerns with refrigeration capabilities at FOBs
• CL II – PPE
• TF Log nodes have not been established yet
– TF Log units will have to pull supplies from BSI
4 MAY 15
They Rely On Us!
Sustainment Operations
• Mission:
• Theater Opening
• Sustainment of BSI & FOBs – Theater Sustainment Board
• Begin preparation for JOA closure/change of responsibility
• Mobility
• Movement control – under control of the SBDE
• Trans
• Local lift request through MCT or CSSB SPO
• JTF-J4s will coordinate directly with 43d SPO
• Cargo transfer
• Ft. Riley BSI will support cargo transfer prior to arrival of the Inland Cargo Trans Co
(ICTC)
• Distribution
• Primary – Pull from BSI by the TF Log units
• Secondary - Distribution and Thru-put (when fwd log nodes are
established)
• JFLCC is responsible for CUL to Title 10 forces in JOA
4 MAY 15
They Rely On Us!
S&S Class I (Meals)
• Source: DLA
• Delivery Method:
• Currently pull from TF
Log units
• Customers: DCRF
• Storage Capacity: Multiple
storage locations at BSI
• Consumption Rate: 1250
case/day (MREs)
4 MAY 15
They Rely On Us!
S&S Class I (Bottled Water)
• Source: DLA
• Delivery Method:
• Currently pull from TF Log
units
• Customers: DCRF
• Storage Capacity: Multiple
Storage locations available at BSI
• Consumption Rate: 3750
case/day
4 MAY 15
They Rely On Us!
S&S Class I (Ice)
• Source: DLA
• Delivery Method: Currently pull
from TF Log units
• Customers: DCRF
• Storage Capacity: 2,200 sq ft
Climate controlled storage at BSI
• Consumption Rate: 10lbs per
SM/day
4 MAY 15
They Rely On Us!
Initial VR15 DLA Footprint
DLA facilities and vendors in CONUS that would be leveraged for initial flow of MREs,
Bottled Water for DOD & FEMA (shared source of supply), and the Packaged Meal
vendors on contract to support FEMA.
MREs - ~45M (incl war reserve)
stored in CA, IN, GA, VA.
Bottled Water – 35 vendors on
contract. Delivery dependent
on quantity and sourcing
location
Cots – 34K in CONUS. Delivery
to BSI in <72hrs.
Blankets - 5200 in CONUS.
Delivery to the BSI in <72hrs.
Human Remains Pouches - 60K
in CONUS. Delivery to BSI
starts in 48hrs, closing in 96hrs.
Sand Bags - multiple varieties
available. issued in bundles of
100 bags each. 15594 bundles
in CONUS. Deliveries in <72hrs
Tents - Multiple varieties
available, primary storage in CA
DLA Depot
Brown Line
FEMA Meal Vendor
Green Line
Vendor w/ Bottled Water
(DOD & FEMA) Blue Line
S&S Class II
• BSI: Fort Riley/Forbes Field
Currently no Class II pre-position
• Source: Fort Riley, Multi-Class SSA.
Distance is 133.3 miles up I-70W
• Delivery: Currently pull from TF Log
units
• Customer: DCRF teams operating in
hot zone
• Push packet contains 2 DOS of PPE &
contains 5 DOS of DECON and detection
material
• Initial PPE push packet:
150 Class A HAZMAT suits
300 Class B HAZMAT suits
450 C2A1 Respirator filters
Will continue to resupply FOBs
directly.
• Maintain (5 DOS) of PPE at BSIs
• Consumption Rate: 48hrs for C2A1
filters
HAZMAT suits one per Soldier per day.
Item
Class 1
Class 2
Class 3
Boots
Filters
4 MAY 15
COTS PPE Availability
Total
BGAD
SIAD
538
284
254
8880
4673
4207
13539
7515
6024
22679
12100
10579
24633
11454
13179
They Rely On Us!
S&S Class IV
• Source: DLA
• Delivery: DLA Region V transport
to DCRF
• Location: vendor
• Customer: DCRF
• Storage capacity: outdoor
• Consumption: TBD
Construction:
• Nails (25 lbs)
• Lumber (10 pallets 2x4)
• Plywood (300 sheets)
• Sand bags (10 pallets)
Barriers:
• Concertina wire 50’ rolls: 240
• Metal fence post: 176
• Road-guard orange barrier
(6’x2’x3’) 150 ea
• Concrete jersey barrier (10’x10’)
100 ea
4 MAY 15
They Rely On Us!
S & S Class III (Bulk Fuel)
• Source: DLA Energy
• Delivery Method:
• Currently pull from TF Log
units
• DLA (Energy) throughput as
required
• Customers: DCRF
• Consumption Rate:
JP8: 630 gal/day
MOGAS: 4K gal/day
• Storage Capacity:
• Fort Riley
•C2CRE-A/B (TF Log tankers)
4 MAY 15
They Rely On Us!
S&S Bulk Water
• Source: BSI FT Riley
• Delivery method: 24th TC will
transport bulk water from BSI to
FOBs
• Customers:
• DCRF
• Down-trace
• Consumption rate: 69K gal/day
(JOA)
• Storage capacity:
• BSI: 11.25M
4 MAY 15
They Rely On Us!
S&S Class IX
• Source: Primary: BSI/SSA
• JTF units will arrive with critical
repair parts
• Units will initially use SSA at
FT Riley, BSI for requisitioning
repair parts
• AMC will assist in obtaining all
repair parts not filled at the SSA
• TSC LNOs will assist in the
requisition process with the
AMC
• Delivery Method: SBDE will
assist in repair part delivery
• Customer/Location: DCRF &
down-trace units at FOBs
4 MAY 15
They Rely On Us!
Mortuary Affairs
• 10 ea Army T-10 Mortuary Response Teams ;
housed at BSI Ft. McCoy. (6 Soldiers per team)
• 1 Team can process 20 remains in 24hrs
• Teams are OPCON to ARNORTH JTF-CS. (TFOperations)
• Teams augment/assist Local and Federal
authorities with the recovery and
decontamination of remains as needed.
• FEMA distributes Stafford Act funding for human
remains pouches (HRPs), refrigeration containers
and off-site temporary morgue facilities to State
agencies and commercial vendors. Some
assistance from DLA/AMC stocks (HRPs) if
requested (DLA/AMC stocks are limited; mainly
used to support OEF/ OCONUS mortuary
facilities).
• Local Medical Examiner is the legal authority for
all remains recovery operations, including final
disposition of remains. (final disposition decision
still pending)
• SECDEF- can approve NON-MA personnel to
assist with HR handling once trained
• SECDEF- Does not have an approved capability
to decontaminate civilian HR
4 MAY 15
They Rely On Us!
Mobility
AIR
• Primary APOD – Forbes Field
Airport
•APOE – Lawrence
• Air space is cleared for official
traffic
LAND
• Main highways remain congested
with displaced civilians. Anticipate
limited access over the next 24hrs.
• Currently evaluating rail capability.
• MSRs and ASRs being determined
• Current distribution will require a
pull method from the TF Log
elements
SEA
• No activity at this time.
4 MAY 15
They Rely On Us!
Mobility
Trans Companies
• 24th TRANS ( CTC Heavy )
1 PLT Heavy (HETT)
1 PLT PLS
1 PLT MTV
• 165th MCT (Movement Control)
• Line Haul uses
PLS/LHS/CROP,MTV,
Long distances > 90 miles/150
km
• Local Hauls < 20 miles/34 km
• 10 hrs driving time
(12 hrs mission time)
• Push BSI Riley to KC, MO –
2 per day
4 MAY 15
They Rely On Us!
Materiel Readiness
• JTF is responsible for Field Level
Maintenance
• 1st SMC in the 43rd SB is
specifically for area support for
the JOA
• AFSB will be deployed for
Sustainment Level Maintenance
• Class IX is “fill or kill” at BSI (SSA)
or through the AFSB
• Expected maintenance issues
are air filters and tires
4 MAY 15
They Rely On Us!
Materiel Readiness (MHE)
• FT Riley BSI:
- 4K
- CHE
- Atlas/10K
- 25K Forklift
- 36K Forklift
- 40K Forklift
4 MAY 15
They Rely On Us!
x1
x4
x10
x2
x2
x3
100%
100%
100%
100%
100%
100%
Munitions
• No current CLASS V
requirements
• The ASP is at BSI FT Riley
• No Crew Served WPNs
Authorized
• No consumption is expected
4 MAY 15
They Rely On Us!
Operational Contract Support (OCS)
ARNORTH CG Priority of effort:
1. JTF-CS
2. 43D SB
3. 167th TSC
Contracting priority of effort :
(1) Base Life Support:
- BSIs: Surge in personnel will need to
be mitigated by expanding existing
contracts/establishing new contracts.
- Responder Support Camps (RSC):
TFs establish requirements shortfalls
for black/gray water removal /
disposal, porta-potties,
showers/sinks /sleep area & servicing,
trash and waste disposal at the RSCs.
(2) Class IV: Fencing materials
/installation, barbed wire for Task
Force RSCs.
(3) Class VII: Non Tactical Vehicles
(NTV), light sets, generators, reefer
trucks/vans.
4 MAY 15
They Rely On Us!
OCSIC (FWD) Concept of Support
Operational Contract Support (OCS) Mission:
Serve as the primary point of contact for integration, coordination
and execution of planning for non-organic commercially sourced
supplies, services and associated employment of contractor
capability through contract support integration, contracting
support, and contractor management ISO the JFLCC Commander’s
guidance and support to the force.
TF 38
2)
3)
4)
5)
6)
TFs develop requirements packages for non-organic
sustainment/services; submit to OCSIC (FWD)
OCSIC (FWD) attends TSCB to validate and determine
sourcing solutions; if cannot be sourced internally and below
JRRB threshold – packages sent to 412th CSB for sourcing via
JCSB
If unable to source internally or above JRRB threshold requirements packages sent to JFLCC OCSIC for validation via
JRRB; approved packages sent to 412th CSB for sourcing via
JCSB
412th CSB contracting officers approve contract packages;
contract duplicates forwarded to TFs, OCSIC, OCSIC (FWD)
for monitoring/management
TFs monitor awarded contracts via COR involvement and
quality assurance surveillance plans; provide required
documents in support of contract closeout process
Execute contract closeout; final invoices paid and release of
claims by vendor
5
XX
XX
5
TF 76
5
TF 51
OCSIC FWD
167th
BSI
167th TSC (OCS)
43D SB (OCS)
TSC
43D SB will
execute OCS
mission/stand
up OCSIC
(FWD) in the
absence of
167th TSC
TSCB
2
43D
SB
Requirements Pks
EXCEED
JRRB Threshold
(above $250k)
4 MAY 15
412th CSB
2ea CRT
4
Requirements Pks
DO NOT EXCEED
JRRB Threshold
(below $250k)
OCSIC
ARNORTH/JFLCC
G4 Stand Up
3
JRRB
SCO
6 412th CSB
Glossary/Key Terms:
• OCSIC (Operational Contract Support Integration Cell) ARNORTH stands up this cell to prioritize contracting support
within the designated AOR/JOA(s)
• TSCB (Theater Sustainment Coordination Board) –TSC’s
mechanism to review, prioritize and validate logistics assets and
resources in theater and potential sourcing solutions WRT JRRB
threshold
• JRRB (Joint Requirements Review Board) – JFLCC’s mechanism
to review, validate, prioritize, and approve contract support
requests
• JCSB (Joint Contracting Support Board) – JFLCC’s mechanism to
coordinate and deconflict common contracting actions between
theater/external support contracting
• CLPSB (Combatant Commander Logistic Procurement Support
Board) – GCC’s primary mechanism to establish AOR-wide OCS
policies and procedures
JTF CS
1
Contracting Flow:
1)
XX
XX
Approved Contracts
issued by 412TH CSB to
the Task Forces or
Requiring Activity.
JCSB
Legend
USNORTHCOM
Contracting Flow
Command Relationship
CLPSB
Coordinate Requirements
Requirements Pks Flow
Aligned
Sustainment/Contracting Board
They Rely On Us!
Questions & Comments
4 MAY 15
They Rely On Us!
