*FM 3-7
FIELD MANUAL
NO. 3-7
HEADQUARTERS
DEPARTMENT OF THE ARMY
Washington, DC, 29 September 1994
FM 3-7
NBC FIELD
HANDBOOK
MEMORANDUM, SUBJECT: Request to Change
Chemical Proponent Field Manual Distribution
Restriction Statements, 6 October 2000, with 12
October 2000 e-mail endorsement.
Table of Contents
Preface
Chapter 1 - NBC Warning and Reporting System
Chapter 2 - Chemical
Chapter 3 - Protection and Decontamination
Chapter 4 - Nuclear Protection
Chapter 5 - Biological Protection
Chapter 6 - Smoke
Chapter 7 - Flame Field Expedients
Appendix A - Combat Orders
Appendix B - NBC Defense Equipment and Training Aids
Appendix C - NBC Signs
Appendix D - Tactical Operations
Appendix E - Conversions and Measurements
References
Glossary
Authorization Letter
DISTRIBUTION RESTRICTION: Approved for public release; distribution is
unlimited.
*This publication supersedes FM 3-7, 27 September 1990.
