Accessories
TSB
Apparatus cup
Color
Standard finish
1
-
Reference
-
TSB
TSB RAL 9011
Height
Width
-
-
Thickness
grey RAL 7011 / black RAL 9011
Polypropylene
Length
-
-
kg/piece Packaging
0,080
0,080
12
12
Stock
Unit
piece
piece
More technical specifications for this product can be found at the end of this chapter.
- can be clipped in the frame at different heights and in all directions.
- max. 3 apparatus cups per square build-in frame
- max. 3 apparatus cups per round build-in frame
- max. 2 apparatus cups for cover rectangular
- partition plate SSB for division of the apparatus cup in 2 or 3 compartments
- use blind plate GBP in case you do not use alle the available space for the apparatus cup.
Tested according to VDE 0634 part 1.
ADP
Coverplate for apparatus cup TSB
Color
Standard finish
1
-
Reference
-
ADP 0
ADP 0 RAL 9011
ADP 1 K
ADP 1 L
ADP 2 K
ADP 2 L
ADP 3
ADP 3*3
ADP 3*3 RAL 9011
ADP 4*4*45
ADP 4*4*45 RAL 9011
Height
-
Width
-
Thickness
-
grey RAL 7011 / black 9011
Polypropylene
Length
-
kg/piece Packaging
0,030
0,030
0,008
0,010
0,010
0,015
0,010
0,020
0,020
0,025
0,025
12
12
12
12
12
12
12
12
12
12
12
Stock
Unit
piece
piece
piece
piece
piece
piece
piece
piece
piece
piece
piece
- for module 45, order ADP 4*4*45 (A.B.S), with opening 41 mm
- in case of use in the round floor box, cut the angles away
Tested according to VDE 0634 part 1.
6-84
FLOOR INSTALLATIONS
EN - January 2011
