25.05.20052003-12-10
What do we face in the design?
25.05.20052003-12-10
Existing Tanker Fleet
25.05.20052003-12-10
World Oil Movements
25.05.20052003-12-10
Oil Tanker Categories
25.05.20052003-12-10
Principal Dimensions of Tankers I
25.05.20052003-12-10
Principal Dimensions of Tankers II
25.05.20052003-12-10
Principal Dimension Considerations
• Breadth Limitations (Panama Canal)
• Draft Limitations (Trade Route)
Suez Canal
Malacca Straits
25.05.20052003-12-10
A new type of VLCC is Born
MALACCA-MAX
T=20.5m Cargo same as a large VLCC
25.05.20052003-12-10
Double vs Single Hull Tankers
• We have come a long way !
25.05.20052003-12-10
Double vs Single Hull Tankers
• Increased Strength Requirements
• Increased Stability Requirements
• Increased Cargo Temperature
• Increased Ballast Surface
25.05.20052003-12-10
Structural Design Considerations
25.05.20052003-12-10
Structural Design Considerations
• Longitudinal Strength (Global Bending/Shear)
• Transverse Strength (Primary Support
Members)
• Buckling (In combination with above)
• Fatigue (Long Term Effect)
• Ultimate Strength (Extreme Load/Plasticity)
25.05.20052003-12-10
Longitudinal Strength (Beam Model)
• Minimum Section Modulus (IACS
Requirement)
• Static and Wave induced Bending and Shear
• Sagging and Hogging
• Sagging dominates in Full Load
• Hogging dominates in Ballast Load
25.05.20052003-12-10
Transverse Strength (Local Loads)
25.05.20052003-12-10
Typical Midship Section of a VLCC
25.05.20052003-12-10
More Mid-ship Sections
25.05.20052003-12-10
How to do it? Cavalry To the Rescue!
25.05.20052003-12-10
POSEIDON ND
Computer Supported Tanker Scantling
Assessment
• Rule Based Structural Design
• First Principle Structural Design
• Support of Plan Approval Procedure
• Condition Assessment
25.05.20052003-12-10
Midship Section of a Suezmax Tanker Created by
POSEIDON-Plating
25.05.20052003-12-10
It is not over yet!
2nd Stage of Analysis Æ FEA
25.05.20052003-12-10
Model of a Suezmax Tanker without
Deck and Shell Plating
25.05.20052003-12-10
FE Model 319,000 dwt VLCC
25.05.20052003-12-10
The bad and the ugly:
Sloshing and Slamming
25.05.20052003-12-10
Sloshing
Critical for:
Ltank>0.1L and/or Btank>0.5B
25.05.20052003-12-10
Slamming
Critical at Low Draft Fwd-High Speed
25.05.20052003-12-10
Fatigue Assessment
Critical Areas
25.05.20052003-12-10
Fatigue Input (In addition to Stresses)
Wave Scatter
25.05.20052003-12-10
Material Tolerance (S-N curves)
25.05.20052003-12-10
Detailed Stress Analysis (Zooming)
25.05.20052003-12-10
In Conclusion of Fatigue 101
• Miner Damage Accumulation Model
• North Atlantic Wave Input
• Weibull Stress Distribution
• Proper S-N curves (depend on approach)
• Satisfy Target Life (>20 years)
BUT…………
25.05.20052003-12-10
The Fatigue Doctor: Good Details
25.05.20052003-12-10
Design Proper Structural Details !
Quiz:Find what is missing below
25.05.20052003-12-10
LAST BUT NOT LEAST
Operational Considerations in Design
25.05.20052003-12-10
Ship Acoustics
• Noise prediction
• Optimisation of engine foundations
• Optimisation of structure-borne
noise
insulation index
• Noise measurements
25.05.20052003-12-10
Vibrations
• Local Vibration Analysis
• Mast Vibration Analysis
• Shaft Vibration Analysis
Overall frequencyweighted r.m.s.values
from1 to 80 Hz
A
Passenger Cabins for
instance
mm/s
mm/s2
Area Classification
B
CrewAccommo
dation for instance
mm/s2 mm/s
C
Working Areas
for instance
mm/s2 mm/s
Values above which
adverse comments
143
4
214
6
286
8
are possible
Values belowwhich
adverse comments
71.5
2
107
3
143
4
are not probable
Note: The zone between upper and lower values reflect the shipboard vibration environment
commonly experienced and accepted
• Vibration Level Prediction
• Analysis of coupled
machinery/foundation
vibrations
• Vibration measurement
25.05.20052003-12-10
The Big Enemy: Corrosion!
25.05.20052003-12-10
Coatings do not last forever!
25.05.20052003-12-10
Protection of Cargo Oil Tanks
• Pitting corrosion caused by
sulphur components in
combination with water
• Formation of hydrochloric acid
• Sulphur reducing bacteria
• Susceptible areas to be
protected by coatings
25.05.20052003-12-10
Where to Protect?
25.05.20052003-12-10
Do not Forget : Eco-friendliness
25.05.20052003-12-10
THANK YOU FOR YOUR
ATTENTION!
