Explosion Protection Basic Theory 최 정 삼 LATECH. Co., Ltd Explosion Protection Triangle Explosion protection triangle ( 본질안전 방폭 의 3요소 ) Oxygen ( 산 소 ) Ignition source • air • H2O2 ( 발화원 ) • sparks • hot surfaces • hot gases Flammable material (발화제) • gas • dust • vapor Explosion Protection Primary / Secondary Primary explosion protection - Preventing the existence of hazardous area - 위험지역의 존재 예방 Secondary explosion protection - Preventing an explosion in a hazardous area - 위험지역에서의 폭발예방 Explosion Protection Primary / Secondary Primary explosion protection Avoiding a dangerous explosive atmosphere altogether. (폭발 가능한 공기를 제거한다. ) • Replacing flammable materials • (발화제를 교체한다.) • Restricting the amount of the material • (발화제의 양을 제한 한다. ) • Suitable equipment constructions • (알맞은 공사를 설계한다.) • Reduction of material concentration • ( 발화제의 밀도를 줄인다.) Secondary explosion protection Avoiding the ignition of a dangerous explosive atmosphere. (폭발 가능한 지역에서 발화를 피한다. ) • Should only be taken when the implementation of primary explosion protection methods is insufficient • ( 상기 방폭을 구성하지 못할경우에는 반드시 실행해야 한다.) • Various ignition protection methods are possible • (여러가지 폭발 방지 기법이 가능하다.) AREA CLASSIFICATION 지역별 등급 GAS GROUP / CLASS Define ZONE presence of hazardous material (위험물의 규정) / DIVISION Define presence of explosive concentration & Probability (폭발성 물질의 농도와 폭발 가능성을 규정) TEMPERATURE Maximum CATAGORY surface temperature (최대표면 온도를 규정) AREA CLASSIFICATION GAS GROUP / CLASS GAS GROUP / CLASS Typical Gas Methane Propane Ethylene Hydrogen Acetylene European Standard (IEC) ¥ ° ¥ ± A ¥ ± B ¥ ± C IEC : 국제 규정 North American Remark Standard (NEC) Flammable D Class ¥ ° gases or C vapors B A Class ¥ ± Combustible dusts Class ¥ ² Fibres or flying particles NEC : 북미 규정 휘발성 가스 또는 증발 기체 가연성 분진 섬유 또는 부유중의 먼지들 AREA CLASSIFICATION ZONE / DIVISION European Standard North American Standard (IEC) Explosive gas/air mixture present ZONE 0 continuously or for long period Explosive gas/air mixture is likely ZONE 1 to occur during normal operation Explosive gas/air mixture is not ZONE 2 likely to occur.If it does then it will exist only for a short time. (NEC) Division 1 Division 2 ZONE 0 : 폭발가스가 존재 하거나 장시간 정체되는 지역 (1년에 1000시간 이상) ZONE 1 : 정상 작동시 폭발가스가 존재하는 지역 (1년에 10~1000시간) ZONE 2 : 정상적인 사용시 폭발 가능성이 없으나, 단지 이상 상태하에서 극히 짧은시간 동안 폭발가스가 존재하는 지역 (1년에 10시간 이내) AREA CLASSIFICATION ZONE / DIVISION EXAMPLE Zone 1 Zone 0 Zone 2 Flammable liquid AREA CLASSIFICATION Temperature Classes (표면 최대 온도) M a xim u m T e m p e ra tu re 450 (국제 규정) (북미 규정) S ta n d a rd N o rth S u rfa c e E u ro p e a n S ta n d a rd (IE C ) C T1 A m e ric a n (N E C ) T1 300 T2 280 T 2A 250 T2 T 2B 230 T 2C 200 T3 180 T3 T 3A 165 T 3B 160 T 3C 135 T4 120 T4 T 4A 100 T5 T5 85 T6 T6 AREA CLASSIFICATION Temperature Classes The ignition temperature of the present substance must always be higher than the temperature type of the field device. (방폭지역의 발화 온도는 항상 field 계기의 온도등급보다 커야 한다.) Surface temperature of group II electrical apparatus: Class Temperature T1 T2 T3 T4 T5 T6 450 °C 300 °C 200 °C 135 °C 100 °C 85 °C Explosion Protection EXPLOSION LIMITS Concentration (농도) Energy (에너지) Explosion Protection FLAMMABLE RANGE ( 인화성 범위 ) Material Lower explosive limit Upper explosive limit Minimum ignition Energy Propane (프로판) 2% 9.5% 180 μJ Ethylene (에틸렌) 2.7% 34% 60 μJ Hydrogen (수소) 4% 75% 20 μJ Explosion Protection Effect of Concentration Ignition Energy Propane-air,1 atoms 1 (프로판) ( mJ ) 0.1 ( 수소 ) ...…........... MIE 0.01 0 20 40 60 80 100 Volume Connection (%) Ignition Protection Explosion Prevention Methodology Permit Ignition ( 발화 허용 ) Control Atmosphere ( 주위의 환경 제어 ) Suitable equipment construction ( 적당한 장비의 구조물로 보호한다 예 : Ex “d” ) Keep flammable material away from ignition source ( 점화원으로 부터 가연성 물질을 제거한다 예 : Ex “p” ) Eliminate Ignition Source ( 점화원을 제거 ) Limiting of electric energy and thermal effect ( 전기적 에너지와 열의 영향을 제거한다 예 : Ex “i” ) Ignition Protection EEx ‘p’ Concept : Removes any hazardous atmosphere from inside an enclosure and then maintains the interior as a "Safety area" Non-certified apparatus may be used inside with few restrictions Design stds: CENELEC : EN50016 BS5501 : Part 3 IEC 79-2 UK Code of Practice B55345 : Part 5 Pressure switch (over and P2 P1 under pressure) Main switch 점화의 원인이 될 우려가 있는 부분을 용기내에 넣고 보호기체를 용기 내부에 주입하여 내부의 압력을 유지하여 폭발성가스가 침입하지 않도록한 구조. *P1>P2 이면 외부의 폭발성 가스가 침입할 수 없다. P1>P2 Ignition Protection EEx ‘p’ Suitable for Zone 1 and 2 (Zone1 과 Zone2에 사용된다) 장점 : Sometimes the only solution (다른 방법이 없는 경우) Can protect large volumes,panels and control rooms (대형 시스템, 판넬, 제어실 보호용) Can have large margin of error before danger results ( 위험한 결과 이전에 여유가 있다) Useful for VDUs (영상 화면 장치에 유용하다) 단점 : Clean air is not free,has to be filtered, pumped etc. (공기 정화용 필터와 펌프 등을 사용해야 한다) Can be expensive (높은 비용) Live working is not permissible (보수중 작동불가) p Ignition Protection EEx ‘o’ Minimum depth: 25 mm between top of the device and surface of the oil Concept : - Prevents access of flammable atmosphere to ossible ignition sources by immersion in mineral insulating oil (Heavy current switchgear and transformers) Design Stds : CENELEC : EN50015 BS5501: Part 2 IEC 79-6 UK code of Practice BS 5345: Part 9 *스위치 기어나 트랜스포머에 사용되는 기술로 위험의 원인이 될수있는 장비를 무기질의 oil에 잠기게 함으로서 폭발 가능한 환경을 제거하도록 한 구조 Ignition Protection EEx ‘q’ Concept : Code letter "q" stands for quartz but filling medium is commonly small glass or silica beads (Telephone and Luminaires) Design stds: CENELEC: EN50017 BS5501: Part 4 IEC 79-5 UK code of pratice BS 5345 : Part 9 *점화원이 될 우려가 있는 부분을 모래나 기타 물질로 채워서 아아크나 점화에너지 이상의 잘못이 발생하더라도 자체에서 폭발이 일어나지 않도록한 구조. 그러나 오늘날에는 방폭용 전화기 외에 거의 쓰이지 않는다. Ignition Protection EEx ‘m’ Concept : A relatively new method of protection : Encapsulated apparatus was previously certified Ex"s" Design stds: CENELEC: EN 50028:1988 BS5501: Part 8 IEC: None *전기기기나 부품을 주의환경의 영향에 충분히 견디는 수지로 몰딩시켜 그수지 내부에서 발생하는 스파크나 열에 의해 점화가 일어나지 않도록 만든 구조 Ignition Protection EEx ‘e’ Concept: A construction technique relying on good quality materials, design and assembly to eliminate any spark or hot spots Installation: Zone 1 and 2 (Zone 1, Zone 2에 설치한다) *정상적인 운전중 불꽃 또는 과열이 생겨선 안될 부분에 이러한 것들의 발생을 방지하기 위해 구조와 온도상승에 대해 특히 안전도를 증가시킨 구조 no ignition source Ignition Protection EEx ‘d’ Concept : Permits gas - air mixture access to the inside of the enclosure but prevents ignition transfer to the outside Design Stds : CENELEC : EN50018 IEC : 79-1 BS5501 : Part 5 UK code of practice BS 5345 : Parts * 점화원이 s s 될 우려가 있는 부분 즉 불꽃, 아아크 또는 과열이 생길 우려가 있는 부분을 밀폐구조인 용기에 넣어 만일 외부의 폭발성 가스가 내부로 침입해서 폭발을 하였을때 용기가 그압력에 견디어 파손되지 않고 폭발한 고열가스가 용기의 접합부 틈으로 부터 외부로 유출되는 일이 있어도 그동안에 냉각되어 외부의 폭발성 가스에 점화가 파급될 우려가 없도록하는 구조 Ignition Protection EEx ‘d’ 단점 : No Live Maintence (보수시 Main power를 반드시 OFF 시켜야한다) Need More Space (많은 공간이 필요하다) More Weight (무게가 많이 실린다) Expensive (비싸다) High Maintence Cost (보수시 많은 유지비가 든다) s s Ignition Protection EEx ‘s’ Design stds CENELEC : None IEC : None BS : None Methods not covered by the other standards BASEEFASFA 3009 UK code of practice BS 5345 : Part 8 *특 수 방폭 기 기 는 그 구 조, 재 료 , 사 용장소 , 사용방법 등을 고려하여, 시험 기타에 의해 해당 전기 기기에 대한 폭발성 분위기로 점화를 분명히 방지할 수 있음을 검정 기관으로부터 증명 받은 구조를 말한다 Ignition Protection Summary on Zone of use Zone Type of Protection 0 Intrinsic Safety 'a' Special Protection certified for zone 0 1 Any type of protection suitable for Zone 0 Intrinsic Safety 'b' Flameproof Pressurised Increased Safety Special Protection 2 Any type of protection suitable for Zone 0 or Zone 1 Non-incendive Oil Filled Sand Filled Code Letter Ex "ia" Ex"s" Ex "ib" Ex"d" Ex "p" Ex"e" Ex"s" Ex"N"or "n" Ex"o" Ex"q" Intrinsic Safety The origin of I.S. (본질안전의기원 ) COAL MINING INDUSTRY (광산업) Major mine disaster in 1913 (1913년 큰 광산 사고) • • • Led to study of energy limitation in hazardous areas, especially devices that release energy in an electrical discharge Intrinsic Safety Definition What is intrinsic safety ? Limitation of electrical energy or thermal effect under normal or abnormal conditions to cause ignition of a potentially explosive atmosphere -잠재적인 폭발 환경에서의 점화를 야기시키는 정상 또는 비정상 상태하에서 전기적 에너지나 열적효과를 제한하도록한 구조. Intrinsic Safety Method of Protection Ex ’i’ Hazardous Area (위험지역) Certified hazardous area equipment (승인된 위험지역용 장비) Safe Area (안전지역) Standard industrial process control equipment Energy limiting network 에너지를 제한하는 영역 표준 산업용 공정 제어 장치 Intrinsic Safety Spark test apparatus Intrinsic Safety RESISTIVE CIRCUITS (저항 회로) Short Circuit Current (단락전류) Voltage = 30,8 V / 1.1 = 28 v Current = 139,5 / 1,5 = 93 mA 139,5mA IA = Methane (메탄) IIA = Propane (프로판) IIB = Ethylene (에틸렌) IIC = Hydrogen (수소) 30,8V Open Circuit Voltage (무 부하시 전압) Intrinsic Safety Capacitive Circuits (용량성 회로) All llC (Hydrogen) Capacitance 10000uF 3000uF 1000uF 300uF 100uF 30uF 10uF C+15ohm(Cd) C+5.6ohm(Cd) (Sn) (Cd) 3uF 1.0uF 0.3uF 0.13uF 0.1uF 0.03uF 0.01uF 42V / 1.5 = 28V 1V 3V 10V 30V 100V Open Circuit Voltage 300V 1000V Intrinsic Safety Inductive Circuits (유도성 회로) Inductance 1H 500mH l (Methane) 200mH llA (Propane) 100mH llB (Ethylene) 50mH llC (Hydrogen) 20mH 10mH 4.2mH 5mH 2mH 1mH 500uH 200uH 139.5mA / 1.5 = 93 mA 100uH 5mA 10mA 20mA 50mA 100mA 200mA 500mA 1A Short circuit current Intrinsic Safety Principal HOW IT WORKS ? Series resistor limits the current (저항은 전류를 제한) Zener diode limits fault voltage (제너 다이오드는 에러 전압을 제한) Diversion of fault path (에러를 밖으로 내보냄) Resistor Fuse + Positive Zener Diode Fault Path - Intrinsic Safety ADVANTAGES Least Expensive (최소비용) No special enclosures, No cable and No special glands fused isolators, No armoured (특수보호장치, 전열퓨우즈, 아머 케이블과 특수 그랜드를 사용할 필요없다) Allow use of Non-certify devices if they are simple Apparatus (LowCost) (단순 부품이면 인증이 필요없이 사용가능하다 - 적은 비용) Fault Tolerant (에러에 강함) - Remains safe even with cable faults or component failure. (케이블 혹은 부품에 문제가 생겨도 장비에는 영향을 미치지 않는다) Intrinsic Safety ADVANTAGES Live Maintenance (전원 “ON” 상태에도 보수가 가능 하다) Ability to work on equipment while it is live (power ON) Personnel Safety (작업자도 안전하다) Extra low voltages and currents (대단히 낮은 전압과 전류값) (No electrocution from IS wiring) (본질안전 배선으로부터 감전될 염려가 없다) Only method suitable for zone 0 (Zone 0에서의 가장 적합한 사용 방법이다) Intrinsic Safety COMPARISON Cost Comparison typical Ex”d” limit switch loop, (가격비교 : 내압 방폭 (Ex “d”)용 리미트 스위치 루프) Zone 1 or 2 * (Zone1 이나 2만 사용) Gas groups IIA or IIB Temperature Classification T6 Flameproof cable grand (내압 방폭용 특수 케이블 그랜드) Flameproof Limit Switch (내압 방폭용 스위치 사용) 100m of 2 core Armoured cable (250V 5A) (특수 아머 케이블 사용) Lockable Fused Isolater (절연퓨우즈 설치) Intrinsic Safety COMPARISON Cost Comparison Equivalent Ex “i” limit switch loop, (가격비교 : 본질안전 (Ex “i”)용 리미트 스위치 루프) Zone 0, 1 or 2 *(Zone 0, 1, 2에도 사용) Gas groups IIA or IIB or IIC Temperature Classification T6 Weather proof cable gland I.S Barrier (일반 방수 케이블 그랜드) Standard Industrial Limit Switch (일반 리미트 스위치 사용) 100m of 2 core PVC / flexible cable (250V 5A) (일반 케이블 사용) (본질안전 베리어 설치) Intrinsic Safety COMPARISON Switch Flameproof limit Switch 250V 5A 1. 내압방폭 전용 특수 스위치 400% Gland 300% Cable 200% Flameproof Barrier gland 2. 내압방폭 전용 특수 그랜드 100m of armoured 2 core cable rating 250V 5A 3. 특수 아머 케이블 Switch 100% Gland Weatherproof Cable gland 2.일반 방수 케이블 그랜드 Cable 100m PVC/PVC flexible 2 core cable Rating 250V 5A 3.일반 PVC 케이블 Interface Interface Lockable Fused Isolator 4. 절연퓨우즈 Standard Industrial micro switch 250V 5A 1.일반 스위치 0% I.S. Barrier 4. 본질안전 베리어 Intrinsic Safety Categories (본질안전의분류) Ex ia Ex ib Intrinsically safe Intrinsically safe with two faults with one faults Zone 0, 1 and 2 Zone 1 and 2 "Faults" are those in components upon which safety of the installation depends. Intrinsic safety is the only protection concept which considers failure of the field wiring * 위 험 지 역 에 서 폭 발 가 스 가 존 재 하 는 시 간 에 따 라 Zone 0,1,2 로 구 분 되 는 데 본안기기의 적용가능 여부에 따라서 Ex ia (Zone 0, 1, 2 사용)와 Ex ib ( Zone 1, 2 사용)로 구분된다. Intrinsic Safety Electrical Appararus (Associate Electrical Apparatus- 전기장치의 조합) Safe Area Hazardous Area Certified Uncertified hazardous Certified safe area area Interface apparatus apparatus Associate Electrical Apparatus Intrinsic Safety Energy Storage Apparatus Energy storage apparatus are electrical devices which have their own source or are powered from an external power source and where the electrical datas * 아래사항 이상의 에너지를 가질 수 있는 장치들은 방폭 인증을 필히 받아야 한다 예) 알람, 솔레노이드, I/P컨버터, 4~20mA트랜스미터등 exceed higher values than: - 1.2 V e.g.: P - 100mA - 20uJ - 25mW Audible Alarms Solenoid I/P Converters 4-20mA Transmitter Intrinsic Safety Simple Appararus Safe Area Hazardous Area Non-certified hazardous area Apparatus Simple Apparatus Non-certified Non-certified safe Certified interface safearea area apparatus apparatus Intrinsic Safety Simple Appararus Devices located in hazardous areas under normal or fault conditions which do not generate or store energy in excess of : 1,2 Volts e.g: 100 milliAmps 20 uJoules 25 mWatt Need not be certified *위험지역 내에서도 위의 값 만큼 전기적 에너지를 발생 하거나 저장하지 않는 간단한 장치는 인증이 필요없다. 예) RTD, 써머커플, 포텐셔미터, LED, 푸시버튼, 정션박스 Identification Certification Authorities Certification of Safety is a Legal or Quasi-legal Requirement UK ( BASEEFA )- 영국 Germany ( PTB ) USA ( UL & FM )- 미국 Australia ( SAA ) Japan ( RIIS ) China (NEPSI) Korea (KISCO) - 독일 - 호주 - 일본 - 중국 - 한국 Identification Certification Authorities WHY CERTIFICATION IS NECESSARY ? (인증이 필요한 이유) Reduces liability due to negligence (과실의 책임성을 줄일 수 있다.) Whether system is safe ? Who is responsible ? (시스템의 안전성? 책임소재 여부?) Identification Electrical Equipment Intrinsically safe electrical apparatus EEx me IIC T6 Temperature class Explosion group Protection type Equipment conforms to standard EN 50... Associated apparatus [EEx ia] IIC The square brackets show that this has to be mounted in safe area Explosion group Protection type Equipment conforms to standard EN 50... Identification Installation I.S. Must Satisfy 2 requirements : Separation of intrinsically safe and non-intrinsically safe circuits Potential difference of power system and ground is incapable of causing ignition (Potential Equalising Conductors) 2가지 요구를 만족 시켜야 한다. - 본질안전 회로와 비 본질안전 회로를 분리시킨다. - 전원 시스템의 접지간 전위차가 점화를 야기 시킬 수 없어야 한다. (모든 접지의 전위는 동등하게 유지한다) Identification Entity concept Safe Area (안전지역) Hazardous Area (위험지역) Transformer Isolated Barrier 4-20mA Transmitter (트랜스미터) Tolerable Fault Voltage (Vmax.) Tolerable Fault Current (Imax.) Internal Unprotected Capacitance (Ci) Internal Unprotected Inductance (Li) •에러전압 수용력 •에러전류 수용력 •내부 캐피시턴스 •내부 인덕턴스 Vmax Imax Ci + Cc Li + Lc Voc Isc Ca La Cc = Cable Capacitance Lc = Cable Inductance Fault Voltage (Voc.) Fault Current (Isc.) Allowable Capacitance (Ca) Allowable Inductance (La) •에러전압 •에러전류 •허용 캐피시턴스 •허용 인덕턴스 Identification Grounding Must be grounded at only ONE point Impedance of conductor from barrier ground bus to ground connection should be less than ONE ohm Ground cables should be insulated & protected of any risk of mechanical damage -접지를 한곳에 해야된다 -베리어의 접지 단자와 접지 바 사이의 저항은1Ω 이내로 한다 -접지선은 인위적인 위험으로 부터 보호되어야 한다 Identification Junction Box Requirement Used for marshalling of separate cables to Multicores 본질안전 배선과 비 본질안전 배선은 서로 분리하여 정렬한다 1) Need to avoid inadvertant grouding or shorting or cores - 잘못된 접지, 쇼트, 선의 공통사용은 피한다. 2) Terminations should be reliable ( at least IP 20) - 종결 부분은 IP가 20이상이어야 한다. - maintain creepage and clearance distance 6mm - 크리프와 크리프 사이의 거리는 6mm를 유지한다. - 4 mm clearance to grounded metal- 접지금속과의 거리는 4mm 이상의 여유를 둔다. 6mm 4 mm Safety Barrier creepag e Creepage 6mm Identification Cable Requirement Minimum insulation 0.2 mm PVC or Equivalent Mechanical Protection not necessary for safety purposes (기계적인 보호는 필요없다) User may have own standards (일반 케이블을 사용해도 된다) The cable must: - Be capable of with standing a 500V insulation test to earth for 1 minute(반드시 케이블은 500V로 1분간의 절연시험의 합격제품 사용) Minimum Conductor size : 0.017 mm - Conform to the cable parameter requirements (반드시 케이블 정격을 따른다 ) - Be suitable for the environmental conditions (반드시 주위 환경에 따라 적당한 것을 선택한다) - Be clearly identified as carrying Intrinsically Safe Circuits (반드시 본질 안전 회로라는 것을 확실하게 표시한다) Identification Cable Requirement Multicore cables are permitted in IS systems but IS and non-IS circuits must not be contained in the same multi-core [ BS5345 : Part 4: 1977, Clause 15.1.7] Multicores Outer sheaths need not necessarily be blue for IS systems but easy identification of IS cables is required -should be run where risk of mechanical damage is slightly -should be fixed throughout their length -each IS circuit to occupy adjacent cores -no voltage should exceed 60V peak -멀티코어 케이블내에 본질안전 배선과 비 본질안전 배선을 같이 사용하면 안된다 -멀티코어 케이블은 설치시 파손될 염려가 없도록 설치한다. -System 자체를 Blue Color로 할필요는 없으며, 쉽게 식별을 하기 위하여 IS Cable이라는 표시를 하여 사용해야 한다. Identification Cable Requirement -Screens in cables used for IS circuits should be earthed at one point only, usually at the point of earthing of the interface devices.They may be earthed in the field, provided that is the only point of earthing. -Screens may touch one another, provided they are all "earthed" or "grounded" to the same point. -Cable armour or metal sheaths should be "solidly earthed" to the plant structure. - 본안회로에 연결된 케이블 속 차폐선의 I.S접지는 한곳에 접지되어야 하며, 일반적으로 인터페이스 장치의 접지 포인트에 연결한다. 같은 포인트에 접지하는 조건이라면, 이 차폐선들은 현장에서 접지 되어야한다. - 같은 포인트에 접지한다면, 차폐선은 서로 접촉되어도 관계없다. - 아머 또는 금속 포장 케이블은 반드시 플랜트 구조물의 신뢰할 수 있는 곳에 접지를 해줘야 한다. Identification Safety Barrier Requirement - Barriers are normally mounted in the safe area. - May be mounted in the Zone 1 or 2 in a suitably certified enclosure, such as a Ex'd' Ex'n' or Ex'p' enclosure. - Must not exceed the ambient temperature shown on the barrier. (40o C if not shown) - Location should be permanently marked to show the correct barrier type. - 베리어는 안전지역에 설치한다. - Zone 1이나 2지역내에 설치할 경우 그 지역(Zone 1 또는 2) 사용 인증 받은 장비 즉, Ex ‘d’, Ex ‘n’, Ex ‘p’ 내에 설치가 가능하다. - 주변 온도가 배리어에 표시된 주변 온도보다 절대 높으면 안된다. 만약 표시가 없다면 40oC로 간주한다. - 배리어의 구분을 위해 인식표를 붙인다. Identification Installation - Summary -Hazardous area circuits should withstand 500V RMS test to earth and to other circuits (위험지역 회로는 접지 또는 다른 회로와 500V RMS 테스트에 견딜 수 있어야 한다) -Galvanically isolated interface is required for earthed / grounded sensors (and in some countries for all Zone 0 circuits) ( 갈바닉 절연기기는 접지된 필드 계기를 사용해야한다) -Cable Parameters should be matched (적당한 케이블의 사양을 사용해야 한다 ) Installation should be in accordance with system documentation and manufacturers' instructions (설치시 시스템 관련자료와 제조자의 지시에 따라 설치한다) -Creepage and clearance / segregation distances must be maintained ( 크리프와 틈 / 분리 거리는 일정이상을 유지해야 한다.) -Loops must be operationally correct (eg failsafe) (루프는 올바르게 운전 되어야 한다)
