LO: We’re learning to understand how logic applies to us when building applications. A logic gate is a digital circuit which either allows a signal to pass through it or to stop it. There are seven basic logic gates: AND, OR, XOR, NOT, NAND, NOR, and XNOR. A NOT gate (inverter) has only one input. It reverses the logic state. NOT GATE Input HEAT DETECTOR (ABOVE 20 C) Output NOT GATE CENTRAL HEATING Input AND GATE Input An AND gate can have two or more inputs. The output will be positive (true) Output when both inputs (the input one AND the input two) are positive (true). PERSON SENSOR AND GATE ON SWITCH c FOR ALARM BURGLAR ALARM Input An OR gate can have two or more inputs. The output will be positive (True) if at least one input is true. OR GATE Input Output FRONT DOORBELL SWITCH OR GATE BACK DOORBELL SWITCH DOORBELL • It is important to remember the rules of each gate. For example • The NOT gate has only one input and therefore only has one output. • The truth table below has been started for you, see if you can finish it… INPUT A OUTPUT X 1 1 • Using these rules, see if you can finish the other two truth tables. • The output is "true" if either or both of the inputs are "true." If both inputs are "false," then the output is "false.” – OR • The output is "true" when both inputs are "true.” Otherwise, the output is "false.“ - AND Name the logic gates. Test it by answering True or false (Yes or No) for each Input. Good dancer ? ? Good at sport ? Blue eyes Has a big nose YES, She/He is OK ? Task – Create a pattern of logic gates to find out if something is suitable. It could be the perfect video game or CD to listen to. • Now that you understand the rules, it time to apply it to TouchDevelop. • You’ve learnt about 3 different gates, you may need to compare items before making algorithms in the future. • Can you think of things you might need to compare in a game? 1. Using the lesson 10 video, create the 3 logic gates as 3 separate programmes. 2. Publish the program with your name so that your teacher can search or it. 3. Once your teacher is happy with your Logic gates, see if you can create variables and repeat the logic gates you illustrated previously. Your teacher might pass around 3 torches around the room. The teacher has one input Another student is the second input. The 3rd student will need to turn the 3rd torch, on or off based on the gate mentioned by the teacher.
