Using 3D Printing in Engineering
Design Education
Lyazzat Zhanshayeva, Mansur Zhussupbekov,
Talgat Alimbayev, Desmond Adair
School of Engineering, Nazabayev University,
53, Kabanbay batyr Ave., Astana, Kazakhstan
E-mail: dadair@nu.edu.kz
Introduction
•
Effective engineering education should incorporate, cooperative learning, promote active
learning in the classroom, balance concrete and abstract information in every course,
establish relevance of course material and teach inductively, formulate and publish clear
instructional objectives, provide a challenge and convey a sense of concern about students’
learning.
•
It is the intention here to describe the development of a hands-on, integrative, multifaceted
design course providing sound engineering skills and knowledge.
•
Essential to a good outcome of this course is the ability to manufacture the product easily
and accurately. This was accomplished using 3D printing as opposed to manufacture in a
workshop by skilled staff, which would have been time consuming and costly.
•
In the following slides, design course development, the design phase, the manufacturing
stage and the testing phase are described. What the students and thought of the course,
including their views on improvement is also reported.
Design Course Development
•
The module was designed for mechanical engineering students’ undergraduate course, who
were bright and high achievers, at the top of their high-school class. The students however
came from backgrounds with high school experiences of being passive recipients rather than
active participants in the learning process and although extremely well versed in
mathematics in particular, they had not some of the intellectual skills and abilities required
for engineering.
•
What was the main objective of this course?
o This was to give the students a flavor of what a typical process in a mechanical
engineering design office might look like, that is, to give the students a first
exposure to the full life-cycle of product development and provide a platform by
which they can exercise their engineering judgment and intuition, in a practical case
study involving the design of an impeller.
•
The module was divided into two distinct sections:
o Background teaching of skills and knowledge
o Design Project
Background Teaching
The teaching and learning of this first section is summarized on Figure:-
Figure: Design project preparation summary
Typical Drawing Practice
The computer software package CATIA was used to teach the CAD section of the
course, with exercises such as “design of an angle bracket” as shown on Figure, used
for practice.
Figure : Typical drawing practice
Design Project – Design Phase
The second section of the course starts with the Design Phase, which lasted 8 weeks.
The scenario for the project was that:
“new pumps were required for the cooling system of a large power station. To win this
contract a more efficient version of the existing pump design is needed but there was
insufficient resources to redesign and manufacture an entirely new pump. So the
decision was taken to use an existing casing and redesign only the rotor and to save
money, design and assessment will be performed on a small model. The hydrodynamic
performance of the model will be assessed on a test rig”.
Schematic of Design Process
Specifications
Table: Requirements and parameters
πœ” = 2600 - 3000 rpm
π‘Ÿ1 = 0.017 m
π‘Ÿ2 = 0.050 m
0.004 m < 𝑏1 < 0.020 m
0.004 m < 𝑏2 < 0.008 m
𝛼𝑠 =5.3°
operating speed
inner radius of blades
outer radius of blades
inlet blades height
outlet blades height
volute spiral angle
Table: System requirements
capacity
pressure gradient
𝑄 = 75 l/min
𝑃 = 0.75 bar
Table: Design parameters
optimal inlet blade height
𝑏1
optimal outlet blade height 𝑏2
optimal leading edge angle 𝛽1
optimal trailing edge angle 𝛽2
number of blades
𝑛
Typical Design produced by CAD
• Following on from the above calculations the students produced individually a
CAD drawing with a typical one shown on Figure.
• Groups of 5 students were then formed and in a committee like atmosphere
they debated and choose the best design within each group.
Design Project – Manufacturing Phase
Manufacturing was carried out using the Projet 450 from ZCorp as shown on Figure
Building the Impeller
• 3-D printer builds the impeller layer by layer from composite material powder as
shown on Figure.
• Each layer thickness was 0.1 mm and the vertical built speed was 23 mm/hr.
Processing & Chemical Curing
• First excessive powder was collected using a vacuum cleaner for recycling.
• The impeller was then cured by a special infiltrate which makes the manufactured part
stronger and more vibrant.
• The part was then dried and ready for testing.
Design Project – Testing Phase
The test rig and associated software
were capable of,
•
producing head/flow rate plots
•
measuring brake power input
•
determining the efficiency for various rpm
•
measuring the variation of capacity with speed
•
giving indication of the presence of cavitation
Design Project – Results
•
Typical results for the manufactured impellers are shown in the Table below
•
It is interesting to note that the test rig manufacturers produce an impeller with
79% and 72% at rpms of 2500 and 3000 respectively.
Pump
Setting
2500 rpm
3000 rpm
Volume Flow
Rate
2.04 l/s
2.84 l/s
Output
Pressure
45.6 kPa
67.3 kPa
Pump Efficiency
(%)
75 < πœ‚ <85
72 < πœ‚ < 80
Design Project – Comments
Three concerns regarding the manufacturing proved unfounded:
•
First, would the materials stand up to the rigorous testing, especially the pressure
differences between suction-side and pressure-side of the impeller blades.
•
Second, would the immersion in water of the impeller have any effect of the
impeller.
•
Third, would the surface roughness be small thus avoiding undue skin friction and
hence drag of the blades.
All of these concerns did not materialize, although after about 10 hours in water the
proto-type impeller did begin to show some softening and flaking.
Student Evaluation of the Course
• Generally it can be seen that the course
was positively viewed by the students
in all respects.
• There appears to have been quite a
generation of enthusiasm,
• There was good interactions between
students and faculty
• There was a creation of good work
habits.
Course Survey
5.00
Average evaluation (1-5)
Q1: How can your instructor improve to help you learn more
effectively?
Q2: My participation - I attended all lectures and participated
fully.
Q3: Which two or more specific aspects of this subject have
contributed most to your learning?
Q4: Please suggest two or more specific, practical changes
which could improve learning in this subject.
Q5: Course requirements were made clear at the start of the
course.
Q6: Assignments contributed to my learning.
Q7: Materials were helpful and well prepared.
Q8: The course stimulated my interest in the subject.
Q9: Class participation was encouraged.
Q10: Faculty were available outside of class.
Q11: Work was evaluated fairly.
Q12: Feedback on assignments was helpful.
Q13: Laboratory and other specialist facilities needed for the
course were satisfactory.
Q14: Session objectives were made clear at the start.
Q15: Concepts and ideas were explained clearly.
Q16: Materials were related to local environment.
Q17: Class time is spent on relevant issues.
Q18: I would recommend this course.
4.00
3.00
2.00
1.00
Q2
Q5
Q6
Q7
Q8
Q9 Q10 Q11 Q12 Q13 Q14 Q15 Q16 Q17 Q18
Responses of students (N = 35)
Conclusion
•
A mechanical design course was developed which actively engaged students,
provided good interaction between students and staff and between student and
student,
•
It provided a hands-on project which stimulated students’ interest and allowed
them sufficient time to develop important engineering skills.
•
Integration of mathematical and scientific knowledge and mechanical engineering
skills proved a strong combination to allow students to obtain a flavour of their
chosen future profession.
•
Without the use of 3D Printing this course would not have been possible to
conduct. The speed and versatility of rapid proto-tying was essential to the
outcomes of this course.
