Chapter 2 Fabrication of MOSFETs
2.1 Introduction
2.2 Basic Process Steps
2.3 CMOS Fabrication Process Flow
2.4 Layout Design Rules
2.1 Introduction
CMOS technologies
Planarized semiconductor process technology
Provide both NMOS and PMOS devices in one process flow
Process all devices of the same kind simultaneously
Cost is proportional to the device size rather than the number of devices
Transistors are fabricated on Si substrate followed by metal interconnections
Existing CMOS technologies:
n-well process
p-well process
Twin-well process
Triple-well process
2
2.2 Basic Process Steps
Oxidation
Formation of silicon dioxide layer on the surface of Si wafer
Dry oxidation: lower rate and higher quality
Wet oxidation: higher rate and lower quality
Deposition
Formation a thin film on the surface of Si wafer
Thin film materials: semiconductor, insulator and metal
Typical chemical vapor deposition methods: APCVD, LPCVD and PECVD
Implantation/diffusion
Process steps to specify the doping species and concentration
Ion implantation: dopants are vaporized, accelecrated and directed at a Si substrate
Diffusion: dopants diffuse from a high-concentration source into Si substrate
Etch
Removal of specific material layers on the Si substrate
Classified as dry and wet etch
3
Photolithography
Uniformly covers of the substrate with photoresist
Selectively exposes with a mask
Develops the photoresist to define the desirable patterns
Suitable for pattern definition with small feature sizes
Isolation
Isolation is required from one active area to another
Typical isolation is provided by a thick oxide layer (field oxide)
Parasitic channel should be prevented under the field oxide
Local oxideation of silicon (LOCOS) technique
4
2.3 CMOS Process Flow
Process flow of a n-well CMOS technology
5
6
7
2.4 Layout Design Rules
Layout rules
Layout rules are given for each one of the layers in creating masks
Designers have to follow the rules for circuit layout
8
Layout of MOS transistors
9
Layout of a CMOS inverter
10
