Quiz Gear Train MEMB3014
Sem 2 2023/2024
A compound in-line reverted spur gear train is to be designed as a speed increaser to provide a
total increase of speed of exactly 45 to 1 (using in line method). With a 20° pressure angle,
specify appropriate numbers of teeth to minimize the gearbox size while avoiding the
interference problem in the teeth. Assume all gears will have the same diametral pitch.
