Processor (CPU) — Acts as the "brain" of your computer. In most builds, the CPU is usually the most expensive
component.
Motherboard — Serves as an interface between all of your computer's components and the processor.
RAM — Random Access Memory. More RAM will provide more "workspace" to increase your computer's
performance. Think about the RAM as a table: more RAM gives you more room for doing things on that table. Less
RAM is like having a smaller table!
Storage Drive — Stores data. You can buy a traditional hard disk drive (HDD), or you can opt for a more expensive
solid state drive (SSD) if you want an exceptionally fast drive.
Power supply — Powers all of your computer's individual components. The power supply is also the interface
between your computer and the wall socket into which you plug your computer.
Case — Necessary for storing and cooling your components.
Graphics card — Used to render images on your computer. While most processors have a built-in graphics processing
unit (GPU), you can buy a dedicated graphics card if you plan on gaming or using your computer for intensive editing.
Cooling system — This includes case fans and coolers for specific parts and keeps the inside of your case at a safe
temperature. Only necessary for gaming and editing PCs—regular PCs should be fine with a stock cooler.
How to Disassemble a Computer
Step 1: Detach the Power Cable
Step 2: Remove the Cover
Step 3: Remove the Adapter Cards
Step 4: Remove the Drives
Step 5: Remove the Memory Module
Step 6: Remove the Power Supply
Step 7: Remove the Motherboard
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Unplug/detach the Power Supply/Cable
Disconnect external devices (Keyboard, mouse and monitor)
Remove the system case cover
Disconnect all the internal cables (interface and power cables)
Remove the device cards from expansion slots
Remove the disk drives (CDROM, FDD and HDD)
Remove the RAM
Remove the heat sink and processor fan
Remove the processor
Remove the motherboard
Remove the case fan
Remove the power supply
ACTIVITY 1
IDENTIFYING THE PARTS OF A COMPUTER SYSTEM UNIT
Video Card
1. Power Supply-____________________________________________________________________
2. DVD Burner-_____________________________________________________________________
3. Video Card-_ _____________________________________________________________________
4. Hard Drive- ______________________________________________________________________
5. RAM/Memory- ___________________________________________________________________
6. CPU- ___________________________________________________________________________
7. Heat sink and Fan- ________________________________________________________________
8. Motherboard-____________________________________________________________________
ACTIVITY 2
DISASSEMBLE AND ASSEMBLE COMPUTER SYSTEM UNIT
INSTRUCTION:
