Lecture 3&4
Full Adder
Decoder
❑Digital information represented
in some binary form must be
converted into some alternate
binary form.
❑𝒏 to πŸπ’ -line decoder.
❑Only one of the πŸπ’ output lines
active at time.
Decoders with enable inputs
Encoder
❑ Encoder is a combinational
circuit which is designed to
perform the inverse operation
of the decoder
❑Only one of the πŸπ’ input
lines active at time.
