Introduction to AMOS
Introduction
Basic building block of a Managed Object Model is an MO.
Parameters associated with MO are called MO attributes. They are categorized as
PM Attributes: Info and Stats
Printing PM counters list for Utrancell class only (RNC)
Configuration Management: Stored permanently e.g. administrative state
2. Fault Management: Not stored permanently e.g. availability status
3. Performance Management: Not stored permanently e.g. pmNoReqDeniedAdm
> pmom Utrancell
MOs are organized in a hierarchical structure. Below, string at the left is known as MO Class and
at the right is MO Identity. Classes can have more than 1 subclasses.
Displaying a counter value during the last ROP
1.
Equipment=1
Class
Identity
Subrack=MS
Slot=19
Getting Started
Launching AMOS:
WRAN Explorer: Tools  AMOS
Login using RNC Name or IP address
> moshell CLMASCPQRNC
Accessing AMOS via Telnet
> Telnet <OSS IP Address>, Then launch AMOS
> moshell CLMASCPQRNC001
Loading & Unloading MOs
> lt all
> lc all
> lu all
Loading MOs of a particular class
> lt utrancell
Help
> h Help menu
> h pmr
> q Quit
Commands History
> hi
Data Storage:
By default data is not stored by AMOS.
Following command saves the logs.
> l+
> <Command>
> l-
Printing description of a particular counter
> pmom utrancell pmTotNoRrcConnectReqCsSucc
> pmx UtranCell=SCCLU02217 pmNoRrcReqDeniedAdm
Displaying counter values during last 3 hrs.
> pmx UtranCell=SCCLU02217 pmNoRrcReqDeniedAdm –m 3
Displaying accumulated counter value during last 1 hr
> pmx UtranCell=SCCLU02217 pmNoRrcReqDeniedAdm –m 1-a
Getting States of MOs
Printing state of all UtranCells in an RNC
> st UtranCell
Printing state of cells with prefix SCCLU
>st Utrancell=SCCLU
Printing state of a particular MO
> st Utrancell=SCCLU0221
Printing state of all disabled utrancell MOs
> st utrancell dis
Printing state of the channels
> lst utrancell=SCCLU02217
Printing state of RU (cell level)
> st RU (RAX, TX, FU)
Printing Modules and Iub links status (RNC)
> str
Print State and BW usage of ATM Ports
(Cell)
CM & FM Attributes
Displaying all CM & FM attributes (params)
> get UtranCell=SCCLU02217
Displaying value of a specific attribute
> get Utrancell=SCCLU02217 CPICH
Displaying more than 1 attributes
> get UtranCell=SCCLU02217 CPICH|qQualMin
Displaying value of RNC level HO params
> get handover
Displaying Operational State
>get UtranCell=SCCLU0001 OperationalState
Getting current no. of Radiolink (Cell)
> get radiolinks
> set Utrancell=SCCLU00018 PrimaryCpichPower 310
> pmr
This command produces list of available KPI reports.
Important reports include:
1) RNC Node Traffic performance
7) RNC UtranCell RRC Performance
8) RNC UntranCell Speech Performance
10) RNC UtranCell PS Data Performance
12) RNC UtranCell HSPA Performance
13) RNC UtranCell IRAT Performance
15) Worst 20 Cells for RRC Failure Rate
16) Worst 20 Cells for Speech RRC Fail Rate
17. Worst 20 Cells for PS Failure Rate
18) Worst 20 Cells for Speech RAB Setup
19) Worst 20 Cells for PS RAB Setup
20) Worst 20 UtranCells for Speech DR Contribution
33) UtranCell Availability Report
Stats during the last 3 hrs.
> pmr –m 3
Stats from 5 hrs ago and 3 hrs from there on
> pmr –m 5 -p 3
Stats during an absolute time span
>pmr –s 20080908 –e 20080909
Fault Management
Overview of active alarms
Display RBS Local Cell Parameters (Cell)
> al
> get rbslocalcell
Print active alarms chronologically
> alt
Miscellaneous
> stv
Changing Parameters
Changing CPICH of a cell
Getting KPIs
Print active alarms with info
Getting No. of T1s and error seconds
> ala
>pget t1
Print active ack and unack. alarms
separately
No. of T1s and their state
> st t1
Changing GSMThresh3a value to -93 (RNC)
Configuration of Iub Links and Subracks (RNC)
>set uemeascontrol gsmthresh3a -93
>lki
> alk
fraz.tajammul@ericsson.com
Ericsson Internal
