Subject: Gate Frame Design Calculation
Date: 19‐02‐2023
I.
Aim:
To design a structural steel frame to replace the current concrete block wall, the objective of this
replacement is to increase the width of the gate.
The Frame were analyzed and designed by the STAAD Pro software. The results from the analysis
are enclosed in the STAAD output section.
II.
Frame Size:
Height = 3.7 m
Width = 6 m
III.
Design Loads:
1‐ Self‐weight (Assigned in STAAD pro)
2‐ Dead Load (weight of the concrete bricks + door sectional chase)
Approx. equal to four layers of concrete bricks
Concrete unit weigh load = 22 kN/m3
Size of the brick = 0.2 m x 0.2 m x 0.4 m
Uniform load for one layer per meter = 22 X 0.2 X 0.2 = 0.88 kN/m
Total for 4 layers = 3.52 kN/m
Design load = 1.4 x DL = 4.93 kN/m (Refer AISC‐7)
(Assigned in STAAD pro as uniform load = 5 kN/m)
IV.
MTO and weight
Item
Beam
Column
Size
HE120B
HE100A
Length (m)
6
3.7
Qty.
1
2
Total length (m)
6
7.4
Total Weight
Total weight (kg)
160.2
123.6
283.8
V. STAAD pro output
3D Rendered View
6.000m
HE120B
HE100A
HE100A
3.700m
Y
Z
X
Sections and dimensions - Elevation view
Load 1
-5.500 kN/m
Y
X
Z
Loading
Load 1
Y
X
Z
Bending Moment (Mz)
Load 1 : Bending Z
Y
X
Z
Shear Fy
Load 1 : Shear Y
Y
X
Z
Axial Force Fx
Load 1 : Axial Force
Y
X
Z
Load 1 : Displacement
Displacements 700mm:1m
Reactions
Node
L/C
Horizontal
FX
Vertical
FY
Horizontal
FZ
MX
Moment
MY
MZ
(kN)
(kN)
(kN)
(kN-m)
(kN-m)
(kN-m)
1
1:LOAD CASE
3.935
17.886
0
0
0
-4.811
2
1:LOAD CASE
-3.935
17.886
0
0
0
4.811
Utilization Ratio
Beam
Analysis
Design
Property
Property
Actual Allowable
Ratio
Ratio
Ratio
Clause
L/C
(Act./Allow.)
Ax
Iz
Iy
Ix
(cm2)
(cm4)
(cm4)
(cm4)
1
HE100A
HE100A
0.605
1.000
0.605
Cl.F2.2
1
21.200
349.000
134.000
2
HE100A
HE100A
0.605
1.000
0.605
Cl.F2.2
1
21.200
349.000
134.000
5.200
5.200
3
HE120B
HE120B
0.542
1.000
0.542
Cl.F2.2
1
34.000
864.000
318.000
13.800
Failed Members
There is no data of this type.
Steel Design (Track 2) Beam 1 Check 1
|-----------------------------------------------------------------------------|
Member No:
1
Profile:
ST
HE100A
PASS
Ratio:
Location:
3.70
Ref:
Cl.F2.2
Vy:
-3.935
Vx:
0.000
|
My:
0.000
Mx:
9.747
|
Pz:
17.28
Tz:
0.000
C
0.605
(EUROPEAN SECTI|NS)
Status:
Loadcase:
1
|
|
-----------------------------------------------------------------------------|
-----------------------------------------------------------------------------|
Member No:
2
Profile:
Status:
PASS
Ratio:
Location:
3.70
Ref:
Pz:
17.28
Tz:
0.000
C
ST
HE100A
0.605
(EUROPEAN SECTI|NS)
Loadcase:
1
Cl.F2.2
|
|
Vy:
3.935
Vx:
0.000
|
My:
0.000
Mx:
-9.747
|
-----------------------------------------------------------------------------|
-----------------------------------------------------------------------------|
Member No:
3
Profile:
Status:
PASS
Ratio:
Location:
3.00
Ref:
Pz:
3.935
Tz:
0.000
C
ST
HE120B
0.542
(EUROPEAN SECTI|NS)
Loadcase:
1
Cl.F2.2
|
|
Vy:
0.000
Vx:
0.000
|
My:
0.000
Mx:
-16.18
|
-----------------------------------------------------------------------------
