5.12 Flexi RFM 6T6R 2100 360 W (FRGU)
FRGU (472956A) is introduced by LTE1802/SR000698/CB005813.
Functional description
Table 298: FRGU functional specification
Property
Value
Output power
6x60 W
Output power of the cell per TX
NR: 39–47.8 dBm with 0.1 dB steps
Modulation
256 QAM (DL) with 1.3 dB power backoff
64 QAM (UL)
Number of TXRX
6T6R
Outdoor installation
Yes
Supported technologies
WCDMA, FDD-LTE, NR
TX frequency range
B1: 2110–2170 MHz
RX frequency range
B1: 1920–1980 MHz
Instantaneous bandwidth (iBW)
60 MHz
Occupied bandwidth (oBW)
40 MHz
DL filter bandwidth
60 MHz
UL filter bandwidth
60 MHz
Supported bandwidths
NR: 5, 10, 15, 20 MHz
Interfaces
268
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 51
Flexi Multiradio BTS RF Module and Remote Radio Head Description
Figure 70: FRGU interfaces
Table 299: FRGU interfaces
Interface
Label on the
hardware
Number of
interfaces
Connector type
Additional info
Power connector
DC IN
1
3-pole screw
terminal
–
Antenna
connector
ANT
6
7/16
–
RF output
connector
RxO
3
QMA
–
Remote Electrical
Tilt
RET
1
8-pin circular
–
External Alarm
Connection
EAC
1
MDR36
–
Optical interface
OPT
3
SFP
1.5 Gbps to 6
Gbps
Issue 51.
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
269
Flexi Multiradio BTS RF Module and Remote Radio Head Description
WARNING!
Risk of electric shock!
Before turning RF power on, RF ports have to be terminated by nominal 50 Ω load (for
example, feeder with antenna). If these conditions are not met, do not remove the
plastic caps that are delivered within the unused RF ports. The plastic caps isolate RF
power from the environment, and thus provide electric shock security in case RF
power is accidentally on.
Antenna line device (ALD) support
Table 300: FRGU ALD support
ALD support via antenna ports
Value
AISG
ANT1, ANT3, ANT5, RET: AISG 2.0
CWA (for non-AISG installations)
Yes
Voltage
ANT1, ANT3, ANT5: 25 V or 12 V
ANT2, ANT4, ANT6: 12 V
RET: 25 V
Power per port
30 W
Functional block diagram
270
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 51
Flexi Multiradio BTS RF Module and Remote Radio Head Description
Figure 71: FRGU functional block diagram
Electrical specifications
Table 301: FRGU electrical specifications
Property
Value
Nominal supply voltage
–48.0 V DC
Nominal input voltage range
–40.5 V DC to –57.0 V DC
Extended input voltage range
–36.0 V DC to –40.5 V DC
–57.0 V DC to –60.0 V DC
Surge protection
Class II 5 kA
Note:
The minimum start-up voltage is –40.5 V DC. If the input voltage is below or above
the extended input voltage range, the unit might shut down.
Issue 51.
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
271
Flexi Multiradio BTS RF Module and Remote Radio Head Description
Power consumption
Typical power consumption [W] for 48 V DC input, at 25°C, representative of typical product
performance under the same conditions (hardware variant, software version, configuration,
environment) with +/–10% margin. Average = (6 h low hour load, 10 h medium hour load and
8 h busy hour load) /24 h.
Table 302: FRGU power consumption
Mode
Embedded
Power
Meter
support
Configurati
on
Output
power per
carrier [W]
Power
consumpti
on [W]
ETSI
202706
average
load PRRH,
static
Power
consumpti
on [W]
ETSI
202706
busy hour
load PBH RRH,
static
Power
consumpti
on [W]
100% RF
power load
P100% RRH
WCDMA
Yes
1/1/1
20
275
309
383
2/2/2
20
340
399
540
3/3/3
20
413
499
706
1/1/1 2T2R
20+20
422
497
649
1/1/1 2T2R
40+40
552
685
967
1/1/1 2T2R
60+60
702
900
1340
WCDMA
2/2/2
LTE 1/1/1
2T2R 10
MHz
20
20+20
558
682
974
WCDMA
2/2/2
LTE 1/1/1
2T2R 10
MHz
40
20+20
697
871
1294
LTE
MSR
272
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 51
Flexi Multiradio BTS RF Module and Remote Radio Head Description
Power backoff
Table 303: Recommended FRGU power backoff in 256 QAM mode
Single carrier [dB]
Dual carrier [dB]
0.7
1.3
Installation and mechanical specifications
Table 304: FRGU installation and mechanical specifications
Property
Value
Installation options
• Floor/stack
• Pole
• Wall
• 19'' rack/cabinet
IP rating
IP65
Related optional items
Pole installation
• Flexi Mounting Kit for Floor, Wall and Pole
(FMFA)
• Flexi Pole Kit (FPKA)
• Flexi Pole Kit (FPKC)
• Flexi Module Casing (EMHH/EMHA)
Floor/Wall installation
• Flexi Mounting Kit for Floor, Wall and Pole
(FMFA)
• Flexi Module Casing (EMHH/EMHA)
Outdoor 19'' rack
• Flexi Module Casing (EMHx)
Cabinet/indoor 19''' rack
• No optional items needed
Dimensions and weight
Issue 51.
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
273
Flexi Multiradio BTS RF Module and Remote Radio Head Description
Table 305: FRGU dimensions and weight
Property
Value
Dimensions orientation
Height
Core RFM: 115 mm (4.53 in.)
Width
Core RFM: 420 mm (16.54 in.)
Without front covers: 447 mm
(17.6 in.)
With front covers: 492 mm
(19.37 in.)
Depth
Core RFM: 400 mm (15.75 in.)
Without front covers: 422 mm
(16.61 in.)
With front covers: 560 mm
(22.05 in.)
Weight
24 kg (52.9 lb)
Environmental specifications
Table 306: FRGU environmental specifications
Property
Value
Maximum operational outdoor temperature (at
constant high ambient temperature maximum
output power might be limited)
55°C (131°F)
Minimum operational temperature (including
cold start)
–35°C (–31°F)
LTE1802/SR000698/CB005813 feature interdependencies
To be deployed in NR, FRGU radio unit requires the following features:
LTE3656/SR001730/5GC000933: MDEA Fronthaul Switch outdoor DC
CB005868: MDCD Fronthaul Switch Indoor DC
