EE 422
Antenna Theory
project
1st student:
Name: Mujahid Alomri
ID # 201931130
2nd student:
Name: Hammam Hurmuz
ID # 201921850
Introduction:
Microstrip patch antennas (MPA) are a class of planar antennas. Due to their simplicity in
analysis and manufacturing, cheap cost, light weight, easy feeding, and appealing radiation
properties, they have grown to be favorites among antenna designers and have been employed in
several wireless communication applications. We are going to use two single-sided copper
FR4s and one SMA connector to implement a patch antenna.
Timeline:
End of Week
12, Strarting
the
simulation
End of week
13,
Comparing
the results
Week 13,
Starting
fabricating
week 15, Edit
on the
project
Week 14,
Presentation
End of Week
16, Project
submission
Objectives:
The objective of this project is to improve the antenna parameters, such as gain, bandwidth,
return loss, and efficiency, by designing and simulating patch antennas using the High Frequency
Structural Simulator (HFSS). The patch antenna is built at a 2.4GHz operating frequency to meet
these specifications.
Goals:
The project findings will be compared to those of a key article [1], in which we will begin by
presenting the important findings from each model of this paper and then contrast and compare
them with the findings of our project. To summarize the comparison, we will also offer any
interpretations or suggestions for the future. There will also, if applicable, be an overall
comparison of the various publications [2], [3].
References:
[1] D. Bhardwaj, S. Sancheti and D. Bhatnagar, "Design of Square Patch Antenna with a Notch
on FR4 Substrate," 2007 Asia-Pacific Microwave Conference, Bangkok, Thailand, 2007, pp. 1-3,
doi: 10.1109/APMC.2007.4554651.
[2] Y. L. Elo, F. Y. Zulkifli and E. T. Rahardjo, "Design of wideband microstrip antenna with a
parasitic element for 4G/LTE application," 2017 15th International Conference on Quality in
Research (QiR) : International Symposium on Electrical and Computer Engineering, Nusa Dua,
Bali, Indonesia, 2017, pp. 110-113, doi: 10.1109/QIR.2017.8168463.
[3] N. J. Shimu and A. Ahmed, "Design and performance analysis of rectangular microstrip patch
antenna at 2.45 GHz," 2016 5th International Conference on Informatics, Electronics and Vision
(ICIEV), Dhaka, Bangladesh, 2016, pp. 1062-1066, doi: 10.1109/ICIEV.2016.7760161.
