MEO Class IV - SSEP
Fire Fighting Appliances
Fire Extinction
ISC Standard Dimensions
Standard dimensions of flanges for the International Shore Connection
shall be in accordance with the following table:
Description
Dimension
Outside diameter
178mm
Inside diameter
64mm
Bolt circle diameter
132mm
Slots in flange
Four holes 19mm in diameter, spaced
equidistantly on a bolt circle of the above
diameter, slotted to the flange periphery
Flange thickness
14.5mm minimum
Bolts and nuts
Fours, each of 16mm diameter, 50mm in
length with washers
International shore connections shall be of steel or other equivalent material. A suitable gasket, four
16mm x 50mm long bolts with two suitable spanners and eight washers are required to be kept with
each International shore connection. The flange shall have a flat face on one side and, on the other
side, it shall be permanently attached to a coupling that will fit the ship’s hydrant and hose. The
connection shall be kept aboard the ship together with a gasket of any material suitable.
