ARDUINO UNO
THE ARDUINO UNO IS AN
OPEN-SOURCE
MICROCONTROLLER
BOARD BASED ON THE
MICROCHIP ATMEGA328P
MICROCONTROLLER AND
DEVELOPED BY
ARDUINO.CC
THE BOARD IS EQUIPPED
WITH SETS OF DIGITAL
AND ANALOG
INPUT/OUTPUT PINS
THAT MAY BE
INTERFACED TO VARIOUS
EXPANSION BOARDS AND
OTHER CIRCUITS
THE BOARD HAS 14
DIGITAL I/O PINS , 6
ANALOG I/O PINS, AND IS
PROGRAMMABLE WITH
THE ARDUINO IDE , VIA A
TYPE B USB CABLE
T E C H N I C A L S P E C I F I C AT I O N S
Operating
Voltage: 5
Volts
Input
Voltage: 7 to
20 Volts
Digital I/O
Pins: 14
PWM Pins: 6
UART: 1
I2C: 1
SPI: 1
Analog Input
Pins: 6
DC Current
per I/O Pin:
20 mA
DC Current
for 3.3V Pin:
50 mA
The L293D is quadruple high-current half-H drivers
L293D
MOTOR
DRIVER
It is designed to provide bidirectional drive currents of up to
600-mA at voltages from 4.5 V to 36 V. Both devices are
designed to drive inductive loads such as relays, solenoids,
dc and bipolar stepping motors, as well as other highcurrent/high-voltage loads in positive-supply applications
Drivers are enabled in pairs, with drivers 1 and 2 enabled by
1,2EN and drivers 3 and 4 enabled by 3,4EN
Wide Supply-Voltage Range: 4.5 V to 36 V
Separate Input-Logic Supply
Internal ESD Protection
SPECIFICATION
Thermal Shutdown
High-Noise-Immunity Inputs
Output Current 600 mA Per Channel
Peak Output Current 1.2 A Per Channel
EM18 RFID
READER
• EM18 RFID Reader is a module
which reads the ID information
stored in RFID TAGS. This ID
information is unique for every
TAG which cannot be copied
EM-18 is used like any other
sensor module
HOW TO
USE EM-18
RFID
MODULE
Step1: Establishing a mode of
communication
Step2: The output of
MODULE bit rate is 9600bps
E M - 1 8 F E AT U R E S A N D
S P E C I F I C AT I O N S
Operating voltage of EM-18: +4.5V to +5.5V
Current consumption:50mA
Can operate on LOW power
Operating temperature: 0ºC to +80ºC
Operating frequency:125KHz
A DC motor is any of a class of rotary electrical
motors that converts direct current electrical
energy into mechanical energy
DC MOTOR
The most common types rely on the forces
produced by magnetic fields
Nearly all types of DC motors have some
internal mechanism, either electromechanical
or electronic, to periodically change the
direction of current in part of the motor
T E C H N I C A L S P E C I F I C AT I O N S
Standard 130 Type DC motor
Operating Voltage: 4.5V to 9V
Recommended/Rated Voltage: 6V
Current at No load: 70mA
No-load Speed: 9000 rpm
