DC MACHINES & MEASUREMENTS LAB [EE-306]
LIST OF EXPERIMENTS :
1.Speed control of DC Shunt Motor by
(a) Rheostatic control method
(b) Field control method
2.Obtain the performance of a DC Shunt Motor by conducting
Swinburne‘s test.
Obtain performance characteristics by conducting Brake Test on
DC Shunt Motor
3.Obtain performance characteristics by conducting Brake Test
on DC Series Motor.
4.Obtain performance characteristics by conducting Brake Test
on DC Compound Motor.
5.Obtain OCC of a DC shunt Generator at rated speed.
6.Obtain Internal and External characteristics of DC Shunt
Generator
7.Verification of Super position theorem
8.Verification of Thevenin‘s theorem
9.Calibration of Dynamometer type of wattmeter
10.Calibration of single phase Energy meter
11.Determination of Idle & Energy components of current in a
single phase Inductive circuit
12.Measure the resistance Using Megger
(a) Earth Resistance (b). Insulation Resistance.
13.Measurement of power in 1 -Ǿ circuit by a) 3-Voltmeter
method b) 3-Ammeter method
14.Measurement of power in 3 -Ǿ balanced circuit by
2-Wattmeter method
