edc asg 1

advertisement
question no 1.
draw the transfer characteristics of NMOS inverter with
passive load off ( rd = 4k,8k,16k) with vdd = 6v ( use
the characteristics curves of mosfet of your choice
) and also determine the noise margin for all load.?
Ans,,
QUESTION NO 2.
Draw the transfer characteristics for NMOS inverter with
saturated load, unsaturated load, depletion load also
determine the noise margin for all of the above (use
graph paper for transfer characteristics).?
Question no 3.
Comment in details on the performance of practical
gate.?
Question no 4.
Realize the following logic function by using NMOS
and CMOS technology.?
(ABC+D) (E+F)
(AB+C) (DE+F)
Question.1
Present ERA of electronics circuits designs is based
on active loads are used instead of passive loads
due to easy fabrication. The transfer characteristics
for the load as well driver MOSFET is given along
with Vt( threshold voltage) for each MOSFET. You
are required to do the following.?
Threshold voltage for driver and load MOSFET = 1.5
volts and Vdd = 6 volts
1. Draw the unsaturated load.?
2. Draw the load line for unsaturated load.?
3. Draw the transfer characteristics curve for load
line.?
4. Determine the noise margins from transfer
characteristics.?
5. How to improve above design.?
