German University in Cairo
Faculty of Engineering and Material Science.
Date: Jan. 2010
Dr. Mohamed Kamal Shoukry
Bar Code
Engineering Drawing & Projection, EDPT 301
Winter Semester 2009/2010
Final Exam
Instructions: Read Carefully Before Proceeding.
1- Only ruler, triangles, compass, eraser and pencils are permitted for this exam.
2- Draw on the sheets or space provided.
3- The exam consists of (4)
Questions
4- This exam booklet contains (5) pages including this cover page and two extra
papers for drawing.
5- Attempt all problems within the time limits.
6- Total time allowed for this exam is (150)minutes
Good Luck!
Question #
Max. Score
Obtained
Score
1
2
50
15
1
3
15
4
20
Total
100
EDPT 301 Engineering drawing
July 2009
Final Exam
Question # 1
For the given pictorial, it is required to draw the front view, the top view and
the side view according to the first angle projection system.
2
Question # 2
Redraw the front view in full section in the provided space.
3
Question # 3
The front, top and side views of a machine part are shown below in the first
angle projection system.
Construct the isometric projection of this part and draw it on the attached
(isometric) paper.
4
Question # 4
Draw the missing side view of the following object using the first angle
orthographic projection system. (Draw on this paper, in the provided space)
5
