B 61114 N CONNECTOR MALE FEMALE STRAIGHT SAMPLER

advertisement
REV.
DESCRIPTION
A
NEW RELEASE
REVISIONS
ECN
DATE
APPROVED
5/3/11
JJ
.81 20.6
N FEMALE CONNECTOR
N MALE CONNECTOR
FEMALE SMA CAP
SMA FEMALE CONNECTOR
.92 23.4
MAXIMUM CHARACTERISTICS
ALUMINUM CONSTRUCTION
1.00 25.4
1.61 40.8
Application:
SAMPLER PORT
NOT WEATHERIZED, INDOOR USE ONLY
Electrical Performance:
Frequency Range:
dc TO 3 GHz
Max RF Power:
1 kW @ 10 MHz
100 W @ 1 GHz
45 W @ 3 GHz
Monitor Port:
-38 dB 3 dB (700 to 900 MHz)
-30 dB 2 dB @ 2 GHz
VSWR:
dc TO 3 GHz @ ≤1.1 to 1
Insertion Loss:
dc TO 3 GHz @ ≤0.1 dB
Return Loss:
dc TO 2 GHz @ ≥30 dB
dc TO 3 GHz @ ≥27 dB
CUSTOMER APPROVAL: _______________________________________
ALL DIMENSIONS SHOWN ARE FOR REFERENCE ONLY.
UNLESS OTHERWISE SPECIFIED
LEADING DIMENSIONS ARE INCHES
DIMENSIONS IN [ ] ARE MILLIMETERS
TOLERANCES:
FRACTIONS=± 1/32
ANGLES=± 1 °
.XX=±
.XXX=±
.01
.005
DRAWN
ENG APPD
PRODUCT MGR
MARKETING APPD
MATERIAL
.
.
THESE COMMODITIES, TECHNOLOGY OR
SOFTWARE WERE EXPORTED FROM THE
UNITED STATES IN ACCORDANCE WITH THE
EXPORT ADMINISTRATION REGULATIONS.
DIVERSION CONTRARY TO U.S. LAW PROHIBITED.
© 2015 PolyPhaser. All rights reserved.
DATE: __________________
PROJECT NO.
THIRD-ANGLE PROJECTION
JJS
DATE
03/17/11
JJ
5/3/11
SJD
5/3/11
LJ
5/6/11
TITLE
.
SIZE
NOTICE: THE INFORMATION AND DESIGN
IN THIS DOCUMENT IS THE PROPERTY
OF POLYPHASER CORPORATION. ALL
SCALE
RIGHTS RESERVED.
B
N CONNECTOR MALE FEMALE
STRAIGHT SAMPLER PORT ALUMINUM
CAGE
61114
2:1
CUSTOMER SPECIFICATION
PART NUMBER
REV
A
SP-NFM-AL
DOCUMENT NAME
SP-NFM-AL -C
SHEET
1
OF
1
