Lithium-Ion
Xcellion™ Rechargeable Batteries
Greatbatch Medical’s Xcellion rechargeable batteries leverage decades of implantable battery research, development and
manufacturing expertise. Offering unparalleled performance and longevity, Xcellion rechargeables are the power source of
choice for implantable neuromodulation, orthopedic and cardiac rhythm management devices where the energy demands
of the application exceed the practical limits of primary batteries.
Xcellion rechargeable batteries are available in standard configurations to speed development timelines while minimizing investment or in custom engineered configurations to meet application specific needs. Custom options include CoreGuard™ –
a feature that enables Xcellion batteries to discharge to zero volts without performance degradation, a variety of enclosure
material options including stainless steel, commercially pure titanium and titanium alloys as well as custom terminations
options to simplify device integration.
Specifications
R38
R220
R215
Nominal Capacity Nominal Operating Voltage Retained Capacity @ 10 years* Retained Capacity @ 1000 cycles** Max. Continuous Discharge Rate Recommended Charge Rate Case Polarity A/C Impedance (1kHz) Volume Volumetric Energy Density Mass Enclosure Material 38 mAh
3.7 V
>70%
>80%
38 mA
19 mA
Negative
<2.0 W
0.85 cc
165 Wh/I 2.8 g
Stainless Steel
220 mAh
3.7 V
>80%
>80%
220 mA
110 mA
Negative
<0.2 W
3.19 cc
255 Wh/I
8.0 g
Ti-CP
215 mAh
3.7 V
>80%
>80%
215 mA
108 mA
Negative
<0.3 W
3.22 cc
247 Wh/I
8.2 g
Ti-6Al-4Va
CoreGuard
N
N
Y
* projections based on C/2 charge, C/140 discharge
** based on C/2 charge, C/10 dishcarge
Greatbatch Medical is strategically aligned to deliver unprecedented performance, reliability and critical technologies to
provide our customers the opportunity to bring their solutions to market.
