PCIE–098–02–F–D–EMS2
F-215 (Rev 12JAN16)
PCIE–064–02–F–D–RA
(1.00 mm) .0394"
PCIE SERIES
PCIE–036–02–F–D–TH
®
PCI EXPRESS CARD SOCKETS
Polarized
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?PCIE
Insulator Material:
-TH=Black Nylon
-EMS2 & -RA=LCP
Contact: Phosphor Bronze
Plating: Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating:
2.2 A per pin
(2 adjacent pins powered)
Operating Temp:
-55 °C to +125 °C
Card Insertion Depth:
(7.65 mm) .301" nominal
RoHS Compliant: Yes
Lead–Free Solderable:
-RA & EMS2=Yes
-TH=Wave only
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
Card Mates:
(1.60 mm) .062" card
Cable Mates:
PCIEC
Accepts
1.60 mm
(.062") card
Supports one,
four, eight and
sixteen PCI
Express® links
Alignment
pins
Choice of
card–edge mount
or PCB mount
PCIE
Rated @ 3dB Insertion Loss*
11.1 mm Stack Height
Differential Pair Signaling
7.0 GHz / 14 Gbps
*Performance data includes effects of a non-optimized PCB.
Data based on simulations using Final Inch® design.
Complete test data available at www.samtec.com?PCIE
or contact sig@samtec.com
NO. OF
POSITIONS
PCIE
ALSO AVAILABLE
(MOQ Required)
Four rows on
2 mm pitch
• Other platings
Contact Samtec.
PLATING
OPTION
02
TAIL
OPTION
D
OTHER
SOLUTIONS
PCI Express® Jumpers &
Extenders call for PCIEC Series
–EMS2
–F
–036, –064, –098, –164
= Edge Mount
= Gold flash on contact,
Tin on tail
–TH
= Through-hole
B1
B2
–RA
= Right Angle
• Loop back Extender
(From one PCIe® slot to
another PCIe® slot)
• Ser-Des Physical Extender
(From one PCIe® slot to
another PCIe® Ser-Des)
• Physical Extender for easy
troubleshooting of PCIe® card
debug and analysis (PCIe®
slot to Emulator or Analyzer)
Contact Samtec.
(1.00) .03937
B
(1.78) .070
A
(8.61)
.339
(7.50)
.295
(11.00)
.433
(15.40)
.606
(7.30)
.287
(1.35) .053
C
A
B
(2.50)
.098
(10.00)
.394
(2.00)
.079
(1.80)
.071
(10.00)
.394
(6.50)
.256
(4.50)
.177
–RA
(1.50)
.059
–EMS2
POSITIONS
A
B
C
D
–036 (X1)
(25.00)
.984
(39.00)
1.535
(56.00)
2.205
(89.00)
3.504
(7.65)
.301
(21.65)
.852
(38.65)
1.522
(71.65)
2.821
(9.15)
.360
(23.15)
.911
(40.15)
1.581
(73.15)
2.880
(6.00)
.236
(20.00)
.787
(37.00)
1.457
(70.00)
2.756
–064 (X4)
(1.00)
.03937
(4.50)
.177
–TH
(9.45)
.372
D
C
(7.65)
.301
(11.05)
.435
(2.31)
.091
(2.05)
.081
DIA
PCI Express ® is a registered
trademark of PCI-SIG ®.
Note: While optimized for
50Ω applications, this
connector with alternative
signal/ground patterns may
also perform well in certain
75Ω applications. Contact
Samtec for further information.
Note: Some lengths, styles
and options are non-standard,
non-returnable.
A2
A1
(11.65)
.459
(2.50)
.098
–098 (X8)
–164 (X16)
WWW.SAMTEC.COM
Due to technical progress, all designs, specifications and components are subject to change without notice.
