Design a non-inverting tri-state buffer out of PMOS and NMOS transistors. 2. Multiple Choice a. A 6-bit 2’s complement number can represent values from _________ to _________. b. ______ is the only negative value that has the same 3-bit representation as both a signed magnitude and 2’s complement number. c. A 6-input NAND gate has ____________ minterms d. If F=∑A,B,C,D (0,2,3,4,5) then F has __________ maxterms. e. DRAM and SRAM both are volatile / are dynamic / store their data in a capacitor. 2. Multiple Choice f. Write 23.36 as a decimal number: _____________. g. When comparing a 32-bit ripple-carry adder and a 32-bit carry-lookahead adder, you would expect the carry-lookahead adder to have more / less / exactly the same delay and use more / fewer / exactly the same number of gates. h. Say you want to develop an encoding that allows you to send 2-bit messages (one of {00,01,10,11}) over a wire. Say you wish to encode that information so that one bit of error can be detected. How many bits would you need, at a minimum, to encode each of these messages allowing for one bit of detection? 3 / 4 / 5 / 6 / 10 i. If A↑B=C and B↑C=A then ↑ is the Boolean operator OR / AND / NOR / NAND/ XOR. A B C D E F A B C D X=((A*B)+(C*!B))⊕(D*E) Y=A+B+C A common task is to count the number of 1s in a string. Let X[6:0] be the input and C[2:0] be the output. C should be the number of 1s in X. So if X=”1100011” C should be “100” or 4 because there are 4 1s in X. Design a circuit which computes C given X. You may only use the following components: 1bit full adders, 2-to-4 decoders, 2-to-1 MUXes and 3-input AND gates. To get full credit, you must use as few devices as possible. Any solution that uses more than 10 devices will get zero points. Using a K-map find all the minimal sum-of-rpodcuts of F= Σ(PQRS) (1,2,4,5,6,7,8,9,10,12,13,14). Place a star (*) next to each distinguished 1 in your K-map. Using only standard gates (AND, OR, NOT, XOR), D flip-flops and bubbles as well as a single up counter with a synchronous reset, design a device which generates a clock with 12 times the period of the input clock and has a duty cycle of 1/3. The output should be glitch free and your answer should be clear and neat.
