ASCO 5370 Touch Display Interface
The Touch Display Interface (TDI) is a premium user interface for your transfer switch. It increases critical
power reliability, compliance, and efficiency by providing the information as it is needed in intuitive layouts
as opposed to information overload.
Features
Alarm Buzzer
USB (for log retrieval and updates)
Configurable Alarming
Multi-User Access Levels
Downloadable Logs
Custom Maintenance Notes
NTP Time Synchronization
Intelligent
Easy
Accessible
Gives you the only information you
need... when you need it.
Extremely easy to use.
Access where you want it.
By understanding the real-time state
of the ATS controls and measurements,
the TDI is able to crunch the data and
provide you with a final result, instead
of over whelming amounts of raw
data. While the Overview Dashboards
offer the ability to see key details at a
glance, drilling down into other screens
provide in-depth data for forensic
analysis or internal control decisions
Having all the information in the world
means one cannot afford to get lost
when looking for what is needed. The
TDI offers a simple navigation system
that feels natural, much like those on
smartphones. Experienced and new
users alike will be able to quickly find
what is required even under stressful
conditions.
The ability to access data is just as
important as the data itself. The TDI
brings the value of its intuitive interface
to your fingertips by offering various
remote solutions. Not trapped within
a Transfer Switch, the TDI can be mounted remotely on a wall or incorporated
into other structures. It can even be
accessed via communications from
other ASCO devices.
A Premium User-Friendly Experience for Accessing Data Quickly, Optimizing
Reaction Time and Maximizing Efficiency.
Settings
Energy Screen
Event Log
ATS Overview
Trending
KW Detail
Global status header and alerts visible from any screen
Time stamped table
of critical equipment
and electrical activity
Dashboarded view
of key parameters
Detailed breakdown of monitored
parameters
Graphical trends,
histograms, and
diagrams based on
system details
Editable records to
store service and
maintenance records
Max Demand and
energy consumption
information
Deeper level of visibility using Power
Quality Metrics
Status and Control of
supported IO
Downloadable logs and configuration management
Specifications and Ordering Details
Ordering
Environmental
Catalog Number
5370
Operating Temperature
0° to 60° C
Catalog Name
Touch Display Interface (TDI)
Storage Temperature
-40° to 80° C
Humidity Rating
up to 90% relative humidity
Form Factors
Transfer Switch Accessory
150AT*
Bypass Switch Accessory
150BT*
Standalone
Contact Applications Engineering
Enclosure Mounted (Type 1)
Contact Applications Engineering
Power
Display
Type
Resistive Touch Color TFT LCD
Size
7"
Resolution
800 x 480
Other
Screen is hot-swappable
Connectivity
Rated Voltage
24VDC
Ethernet Ports
x2 RJ45, 10/100 Base Tx
Power
36W
USB
x2 Type A Ports
Terminal Methods
Terminal Block or Barrel Jack Connector
