About Us
HH Offshore Introduction
Onshore to Offshore, Fulfilling Our Strategic Vision…
Honghua Offshore Oil & Gas (Jiangsu) Equipment Co., Ltd (hereafter referred to Honghua Offhsore)
invested by Honghua Group (HK listed Company, Code:HK0196), is a comprehensive offshore
solution provider capable of R&D, design, construction and commissioning for large offshore
products and special vessels.
Shanghai Honghua Offshore Oil & Gas Equipment Co., Ltd is R&D, Design and Marketing Center for
Honghua Offshore.
The Construction yard locates in Qidong Marine & Offshore Industrial Park, the ex-mouth of Yangzi
River to sea. With total area up to 1.4 Million m2, a coast line of 1.77km and average water depth
up to 9 m. In 1st phase, with heavy fabrication workshop up to 110,000 m2 equipped with various
advanced equipments, with slipway erection area up to 48,000 m2, and configuration of 2 sets of
400 t gantry crane and a 792m material & outfitting quay.
HH Offshore Strategic Shipyard
Facilities
Yard Size :
1.4million ㎡
Material Storage:
28008 ㎡
Coastal Line: 1770m
Plates & Profiles Shop Blasting:
1386 ㎡
Basin:
150m x 110m
Fabrication Workshop:
107038 ㎡
(Equip Crane: 2 x 11,000T )
Block Erection Workshop:
29232 ㎡
Slipway
Slips Erection Area:
47160 ㎡
46.5m x 160m
Blasting & Painting Workshop:
8944 ㎡
Quay
Gantry Crane :
Electric-Magnetic Crane
Length:
792m
1 x 400T
1 x 45T ; 2 x 25T
HH Offshore Shipyard Location
 Area: 1.5million ㎡
 Costal Line: 1770m
 Water Depth: -9m
 Basin : 150m x 110m
Core Business
HH Offshore Conceptual Design & Manufacture
Jack Up Drilling
Rig HHJ400
Semi-submersible Rig
HHS3000
Drilling Barge
HHB1
DES
Drilling Module
Offshore Drilling Package Application
Honghua Offshore
Drilling Package Application
Jack up
Semi Submersible
DES
Drillship
Tender Barge
Fixed Platform
Offshore Equipment Application
Honghua Offshore
Drilling Rig Components
Drawworks
Derrick & Mast
Mud Pump
Swivel & Hook
Manifold
Rotary Table
Top Drive
Motor
Offshore Equipment Application
Pipe
Handling
Implement
Iron Roughneck
(3-1/2”-8-1/2”)
Pipe Deck Crane
2 7/8″～30″
Power Catwalk
2 7/8″～30″
Pipe Racking Machine
(PRM-100)
Mud Bucket
3 1/2″～7″
Horizon/Vertic Arm
2 7/8″～9 5/8″
Mouse-hole
2 7/8 ″ ～10
Work Basket
(AB300x10)
Pipe
Handling
Implement
Jacking & Fixation System
Honghua Offshore technology
Center has Researched Jacking &
Locking system
which is suitable for harshenvironment jack-up rigs.
The Jacking & Locking systems are
designed and to be fabricated in
accordance with the relevant rules
and regulations of ABS and the
highest HSE standard.
Engineering & Capacity
Engineering
We have over 100 skilled engineers and
3000 production employees from all over
the world.
We will become global team of
competent and innovative people with
a strong passion for what we can do.
Engineering
Software Applications
 AutoCAD Mechanical
 GHS( Stability Analysis)
 Sacs (Strength & Fatigue Analysis)
 ETAP (Electrical Analysis)
 Tribon & PDMS (3D Arrangement)
 Aqwa (Hydrodynamic & Mooring Analysis) to be purchased
 Patran & Nastran, Ansys (Strength Analysis)
Honghai Crane
 Two(2) 11,000T combined Goliath Innovative technology
Reduces construction time
 Provides New Launching Method
Facilities
Quay
Dimension: L=792m
 Equipment:
1*45T Electric-magnetic Crane
2*25T Electric-magnetic Crane
Material Storage
Floor Area: 28,008㎡
 Equipment:
1*25T Electric-magnetic Crane
 Steel Storage area: 25,704 ㎡
Dimension: L=252m W=102m
 Scrap Storage area: 2304 ㎡
Dimension: L=96m W=24m
Facilities
Fabrication Workshop
Floor area:107,038 m2
 Dimension: L=447m W=222m
(5 sections 42m+45m+45m+42m+48m)
 Main Equipment:
2*Flame cutting machine (width≤4.5m
length≤18m)
3*N/C Plasma cutting machine
(width≤4.5m length≤18m)
1*100 ton crane (50t+50t, H=21m)
2*120 ton crane (60t+60t, H=21m)
1*200 ton crane (100t+100t, H=27m)
1*1000 ton hydraulic machine
1*300 ton hydraulic machine
1*3-roller plate roll machine
(4mx20mx42mm thick)
Facilities
Plates & Profiles Shop Blasting
Floor area: 1,386㎡
 Dimension: L=42m W=33m
 Equipment:
1* Steel plate & Profiles processing
Line (Max. width≤4.5m; SA2.5)
Block Storage Open Area
Floor area:84596㎡
1# block storage area
 Floor area: 16,064㎡
2#block storage area
 Floor area: 68,532㎡
Facilities
Slips Erection Area
Block Erection Workshop
 Floor area:47160㎡
(under construction):
 Equipment:
 Floor area:29,232㎡
1*400T Gantry Crane (W=100m, H=60m)
 Dimension: L=168m W=174m
Facilities
Blast & Paint Workshop
Floor area: 8,944㎡
 Blasting chamber (one)
Floor area:1728㎡
Painting chamber (two)
Floor area: 2,448㎡
Dimension: L=48m
