A framework for auditing mobile devices
Baker Tilly refers to Baker Tilly Virchow Krause, LLP,
an independently owned and managed member of Baker Tilly International.
© 2010 Baker Tilly Virchow Krause, LLP
Learning objectives
˃ Understand different approaches for managing
mobile devices including centralized, decentralized,
and BYOD management
˃ Identify the impacts of mobile devices at
organization
˃ Critically analyze mobile device risks using a
framework focused on people, devices,
applications/websites, and data
˃ Define key mobile device controls to incorporate
into audit work plans
2
Contents
˃
˃
˃
˃
˃
˃
˃
Define mobile & BYOD
Impacts of mobile devices at organizations
Risks and internal audit considerations
Key mobile device management controls
A framework for mobile device auditing
Examples of environment
Resources
Define mobile & BYOD
Baker Tilly refers to Baker Tilly Virchow Krause, LLP,
an independently owned and managed member of Baker Tilly International
© 2010 Baker Tilly Virchow Krause, LLP
4
Why do we care?
˃ Mobile is here, no going back to being tethered to a
desk
˃ Mobile allows great productivity and flexibility to
achieve organizational objectives
˃ Mobile employees are happier (so “they” say)
˃ Mobile can save money (maybe?)
Why is mobile the future?
˃ A Cisco study says in 2014 the average number of
connected devices per knowledge worker will reach
an average of 3.3 devices, up from 2.8 in 2012
˃ Gartner predicts by 2017, half of employers will
require employees to supply their own device for
work purposes
What is a mobile device?
NIST (SP 800-124) – characteristics:
˃
˃
˃
˃
Small form factor
Wireless network interface for internet access
Local built-in (non-removable) data storage
Operating system that is not a full-fledged desktop/laptop
operating system
˃ Apps available through multiple methods
˃ Built-in features for synchronizing local data
What is a mobile device?
NIST – optional characteristics:
˃ Wireless personal area network interfaces (e.g., Bluetooth,
near-field communications)
˃ Cellular network interfaces
˃ GPS
˃ Digital camera
˃ Microphone
˃ Support for removable media
˃ Support for using the device itself as removable storage
What is a mobile device?
Any easily portable technology that allows for the
storage and transmittal of your organization’s data
Examples:
˃
˃
˃
˃
Phones
Tablets
Laptops
External hard
drives (e.g., USB
thumb drives)
˃ Cameras (e.g.,
point and shoot)
˃ Logistics devices (e.g., GPS
Tracking devices, RFID)
˃ eReaders
˃ Digital music players (e.g.,
iPods)
˃ Medical devices (e.g.,
pacemakers)
˃ Smartwatches and glasses
What is BYOD?
˃ Bring Your Own Device
˃ Supported by organization systems and
applications that allow multiple type of devices to
access those services
˃ Powered by the internet
BYOD – pros & cons
Pros:
˃ Reduced upfront costs
˃ Employee satisfaction
˃ Potentially greater functionality for users
Cons:
˃ Unmanaged devices with your organization’s data
˃ Mingling of personal and organizational data
˃ Managing legal requirements (e.g., eDiscovery)
BYOD in the Enterprise—A Holistic Approach, ISACA JOURNAL, Volume 1, 2013
Risks and internal audit considerations
Baker Tilly refers to Baker Tilly Virchow Krause, LLP,
an independently owned and managed member of Baker Tilly International
© 2010 Baker Tilly Virchow Krause, LLP
13
Major security concerns (NIST)
˃
˃
˃
˃
˃
˃
˃
Lack of physical security controls
Use of untrusted mobile devices
Use of untrusted networks
Use of apps created by unknown parties
Interaction with other systems
Use of untrusted content
Use of location services
What are the mobile device risks?
NIST characteristics
Illustrative risks
Small form factor
Loss or theft of data
Wireless network interface for internet
access
Exposure to untrusted and unsecured
networks
Local built-in (non-removable) data
storage
Loss or theft of data
Operating system that is not a fullfledged desktop/laptop operating
system
Reduced technical controls
Apps available through multiple
methods
Exposure to untrusted and malicious
apps
Built-in features for synchronizing
local data
Interactions with other untrusted and
unsecured systems
What are the mobile device risks?
NIST characteristics
Illustrative risks
Wireless personal area network
interfaces (e.g., Bluetooth, near-field
communications)
Exposure to untrusted and unsecured
networks
Cellular network interfaces
Exposure to untrusted and unsecured
networks
GPS
Exposure of private information
Digital camera
Exposure of private information
Microphone
Exposure of private information
Support for removable media
Loss or theft of data
Support for using the device itself as
removable storage
Interactions with other untrusted and
unsecured systems
IA considerations – scoping
Does your organization have a mobile device
strategy, including:
˃
˃
˃
˃
˃
Alignment with organizational strategy/objectives
Risk assessment(s) for mobility
Definition of devices
Policies governing the use of devices (with penalties)
Security standards based on data
IA considerations – scoping (cont.)
˃ Who owns these devices, organization or
employee?
˃ Who is responsible for managing and securing the
devices?
˃ Incident response procedures
˃ Antivirus / antimalware software
˃ Who is paying for devices and service plans?
˃ Does that change responsibilities?
˃ What are the legal and regulatory requirements for
your organization and the jurisdictions you operate
in?
Identifying owners and stakeholders
˃ Who is your client?
˃ Who are the stakeholders?
˃ General Counsel
˃ Chief Information Officer
˃ Chief Information Security Officer
˃ Chief Operations Officer
˃ Chief Compliance Officer
˃ Chief Privacy Officer
˃ Chief Risk Officer
˃ Other functions with a stake in privacy and security
(e.g., human resources, sales)
Understanding the organization
˃
˃
˃
˃
˃
Mission and objectives
Organization and responsibilities
Customers
Types of data
Exchanges of data
˃ Interdepartmental
˃ Third parties
˃ Interstate or international
˃ Data collection, usage, retention, and disclosure
˃ Systems (e.g., websites, apps)
Assessing risk
˃
˃
˃
˃
˃
˃
˃
Leveraging management’s risk assessments
Consultation with legal counsel
Regulatory risk
Legal/contractual risk
Industry self-regulatory initiatives
Constituency relations and perceptions
Public relations
Where’s the GRC?
Baker Tilly refers to Baker Tilly Virchow Krause, LLP,
an independently owned and managed member of Baker Tilly International
© 2010 Baker Tilly Virchow Krause, LLP
22
Old model
˃ Protect everything in my office network with
physical and logical controls over access
˃ Then we added laptops and pushed the network
out of the office using VPNs
˃ That doesn’t work any more with phones and
tablets, especially when they are owned by the
employee
Framework – benefits
˃ Flexible – audit all at once or in parts
˃ Adaptable – scope it how you want it
˃ Inclusive – make use of other
standards/frameworks (e.g., COBIT, ISO 27002,
NIST)
˃ ISACA’s Bring Your Own Device (BYOD) Security
Audit/Assurance Program
Mobile device framework
Data
Websites
& Apps
Devices
People
Mobile device framework
˃
˃
˃
˃
Data
Websites & apps
Devices
People
Mobile device framework – data
˃ Data (i.e., data generated, accessed, modified,
transmitted, stored or used electronically by the
organization) is essential to the organization's
objectives and requires protection for a variety of
reasons, including legal and regulatory
requirements.
˃ Examples:
˃
˃
˃
˃
˃
Messages (e.g., emails, text messages, instant messages)
Voice
Pictures
Files (e.g., attachments)
Hidden (e.g., GPS)
Building the framework – data types
DATA
Data
Data
Data
Data
Data
© Baker Tilly Virchow Krause, LLP
WEB & APPS
DEVICES
PEOPLE
Mobile device framework – data
˃ Classification tiers
˃ Data owners/stewards
˃ Data inventory
Mobile device framework – data –
audit considerations
˃ Determine the types of data that can be accessed
or stored on mobile devices. Assess restrictions in
place to safeguard data.
˃ Review the data classification security policy to
ensure specificity to the various types of data,
based on sensitivity.
˃ Use/create an inventory of data, identify the
applications and websites where it can be
accessed, and determine who will take ownership
of the data moving forward.
Mobile device framework – data –
audit considerations
˃ Determine if authentication and security
requirements or restrictions are or should be
established for each data type
˃ Determine if “Legal Hold” requirements are
documented and align with data classification and
then mobile device security
Building the framework – data:
classification
WEB & APPS
DATA
Data
Confidential
Data
Restricted
Data
Data
Data
© Baker Tilly Virchow Krause, LLP
Internal Use
Public
DEVICES
PEOPLE
Data – audit considerations
from ISACA’s work program
˃ 8.1.2 Data Access
˃ 8.1.4 Encryption and Data Protection
Mobile device framework – websites &
apps
˃ Websites and applications (i.e., tools used to
process electronic data) require security controls,
regardless of the device used for access, to protect
the confidentiality, integrity, and availability of data.
Mobile device framework –
websites & apps examples
Types
Business
Personal
Websites/portals
•Outlook web access
•Business intranet
•Google
•Yahoo
•ESPN
Cloud services
•Google services
•Salesforce.com
•Microsoft Office 365
•Gmail
•Flickr
•Facebook
App stores
•Apple app store
•Google marketplace
•Amazon app store
•Custom corporate
stores
•Apple app store
•Google marketplace
•Amazon app store
Custom built apps &
sites
•Business specific
•Entertainment
•Hacking/malicious
Virtual desktop
environments/remote
desktop tools
•Citrix
•VMware
•GoToMyPC
•VNC
Building the framework – web & apps
WEB & APPS
DATA
Data
Confidential
Data
App
Web
Restricted
Data
App
Internal Use
Data
Web
Public
Data
© Baker Tilly Virchow Krause, LLP
App
DEVICES
PEOPLE
Mobile device framework –
web/apps – audit considerations
˃ Determine the websites and applications that are
used on mobile devices to access data, and
determine whether they are approved. Assess how
websites and applications are secured to protect
data.
˃ Review all applications and websites accessible via
mobile devices to ensure they comply with security
policies (e.g., encryption requirements, storage
restrictions, access permissions).
Building the framework – web & apps
DATA
WEB & APPS
Data
App
Confidential
Data
Web
Restricted
Data
App
Internal Use
Data
Web
Public
Data
© Baker Tilly Virchow Krause, LLP
App
DEVICES
PEOPLE
Web/App – audit considerations
from ISACA’s work program
˃ 8.1.6 Malware Protection
˃ 9.1.3 Secure Software Distribution
Mobile device framework – devices
˃ Devices (i.e., hardware used to access websites
and applications for data processing) require an
increasing variety of security controls due to the
increased mobility, choice, functionality, and
replacement of these products.
Mobile device framework – devices
˃ Managed vs. unmanaged
˃ Business vs. employee owned
Mobile device framework – devices
˃ Encryption
˃ Data transfers (e.g., sending and syncing)
˃ Logical security (e.g., linkage to HR, passwords,
access management)
˃ Physical security
˃ Network architecture (e.g., configuration,
monitoring)
˃ Mobile device management (***more later)
Mobile device framework – devices –
audit considerations
˃ Determine the types of mobiles devices that are
used to access data, and whether each mobile
device is supported. Assess how mobile devices
are secured to protect data.
˃ Ensure that both organization managed and
personally owned mobile devices that access
confidential or high-risk data are secured with
appropriate security controls.
Building the framework – devices
DATA
WEB & APPS
DEVICES
Data
App
Phone
Web
Tablet
App
Laptop
Confidential
Data
Restricted
Data
Internal Use
Data
Web
Public
Data
© Baker Tilly Virchow Krause, LLP
App
PEOPLE
Device – audit considerations
from ISACA’s work program
˃
˃
˃
˃
˃
8.1.1 Device Access Restrictions
8.1.3 Explicit Permission to Wipe Data
8.1.4 Encryption and Data Protection
8.1.5 Remote Access
8.2.1 Network Access
Device – audit considerations
from ISACA’s work program
˃ 9.1.1 Mobile Device Management (MDM) is
Deployed
˃ 9.1.2 Central Management of BYOD Devices
˃ 9.1.4 Monitoring of BYOD Usage
˃ 9.1.5 Interfaces to Other Systems
˃ 9.1.6 Remote Management
Mobile device framework – people
˃ People (i.e., employees that process data via
websites and applications through a variety of
devices) require frequent communications and
trainings on the risks, policies, practices, and tools
for protecting the confidentiality, integrity, and
availability of data.
Mobile device framework – people
˃ Risk assessment
˃ Policies, procedures, standards
˃ Training and awareness programs with
acknowledged roles and responsibilities
˃ Monitoring
Mobile device framework – people – audit
considerations
˃ Determine if an overarching mobile device security
policy exists.
˃ Assess existing policies and procedures that guide
the procurement, use, support, and management of
mobile devices.
˃ Determine who uses mobile devices to access
data, and who supports and manages those mobile
devices that access data.
Mobile device framework – people – audit
considerations
˃ Advise departments on creating supplementary
mobile device security practices as needed.
˃ Assess formalized training and awareness
programs that inform mobile device users of the
risks involved and their personal responsibilities
when accessing information.
˃ Are employees OK with you wiping their device?
˃ What happens to personal data on the device?
Mobile device framework – people – audit
considerations
˃ Labor laws (Exempt vs. Non-exempt, union)
˃ Employment contracts
˃ OSHA
˃ Tax laws (reimbursements for devices, services)
˃ Export control laws (travel)
˃ Record management laws
˃ Fair Credit Reporting Act
˃ Local jurisdiction laws (of employee’s residence)
Mobile device framework – people –
employee agreement
˃
˃
˃
˃
˃
˃
˃
˃
Eligibility
Applicable company policies
Data storage and backup
Data and device management
Legal hold notice
Hardware support (theft, loss, damage)
Software support
Travel and physical security
Mobile device framework – people –
employee training
˃
˃
˃
˃
˃
˃
˃
˃
Define BYOD/MDM for your organization
Onboarding device process
Roles/responsibilities
Expense reimbursements/stipends
Security policies
Data ownership policies
Practical app use with organization data
Tech support
From Techrepublic.com
Building the framework – people
DATA
WEB & APPS
DEVICES
PEOPLE
Data
App
Phone
Policy
Web
Tablet
Agreement
Confidential
Data
Restricted
Data
Practices
App
Laptop
Procedures
Internal Use
Data
Web
Practices
App
Risk
Assessment
Public
Data
© Baker Tilly Virchow Krause, LLP
People – audit considerations
from ISACA’s work program
˃
˃
˃
˃
˃
˃
˃
2.1.1 BYOD Initial Risk Assessment
2.1.2 BYOD Ongoing Risk Assessment
3.1.1 Employee BYOD Agreement
3.1.2 Mobile Acceptable Use Policy (MAUP)
3.1.3 Human Resources (HR) Support for BYOD
3.1.4 Contractors
3.2.1 Exemptions from BYOD policies
People – audit considerations
from ISACA’s work program
˃ 4.1.1 Legal Involvement in BYOD Policies and
Procedures
˃ 4.1.2 Legal Hold
˃ 5.1.1 Help Desk
˃ 6.1.1 Policy Approval
˃ 6.1.2 Monitoring BYOD Execution
˃ 7.1.1 Initial Training
˃ 7.1.2 Security and Awareness Training
What is mobile device management?
˃ Process for managing mobile devices, including
policies, procedures, training, and systems
and
˃ Industry term for software tools used to centrally
administer mobile devices, specifically for security
purposes
Types of mobile device management
processes (Gartner)
˃
˃
˃
˃
Control-oriented
Choice-oriented
Innovation-oriented
Hands-off
What do MDM tools do? (Gartner)
˃
˃
˃
˃
Software management
Network service management
Hardware management
Security management
**Focus of these tools is phones and tablets; some
support laptops, but other device types are not
typically supported
MDM tools market (Gartner)
˃ MDM tools market estimated $784 million market
˃ About 128 or more firms in the market
˃ MDM tools projected to be $1.6-billion market by
2014
˃ Market penetration estimated at less than 30
percent
MDM tools prices (Gartner)
˃ Three years ago = $60 to $150 per device
˃ Today = under $30 per device
˃ Traditional endpoint protection = $10 to $15 per
seat
Mobile device management
and the framework
˃ Cuts across all four parts of the framework
˃ Data – some ability to restrict access
˃ Websites & apps – blacklisting, whitelisting,
˃
˃
deployment
Devices – implement system controls
People – use of MDM must align with policies
(especially HR and legal areas)
Key features of MDM tools
˃ Centralize device management through policy and
configuration management
˃ Control both corporate owned and personally
owned devices
˃ SaaS and on-premises delivery models
Key features of MDM tools
˃ Still require thorough testing:
˃
˃
˃
˃
˃
˃
Connectivity
Protection
Authentication
Application functionality
Logging
Performance management
Two main flavors of MDM tools
˃ Messaging server based (e.g., Microsoft Exchange)
˃ Limited control enforcement
˃ Limited support for devices
˃ Third party provided (e.g., Airwatch, Mobileiron,
Good)
˃ Additional costs and licenses required
˃ Another application to support and manage
When would you use MDM?
˃
˃
˃
˃
˃
BYOD
Data encryption
Multiple device operating systems
Security breach impact
Existing end point tools don’t work for mobile
devices
MDM – audit considerations
from ISACA’s work program (9.1.2)
˃ A secure portal for BYOD users to enroll and
provision their devices
˃ Centralized security policy enforcement
˃ Remotely lock and wipe data and installed apps
˃ Inventory devices, operating systems (OSs), patch
levels, organization and third-party apps, and
revision levels
˃ Distribution whitelists and blacklists
MDM – audit considerations
from ISACA’s work program
˃ Permission-based access controls for access to the
organization’s networks and data
˃ Selective wipe and privacy policies for organization
apps and data, i.e., sandboxing
˃ Distribution and management of digital certificates
(to encrypt and digitally sign emails and sensitive
documents)
˃ Role-based access groups with fine-grained access
control policies and enforcement
˃ Over-the-air (OTA) distribution of software (apps,
patches, updates) and policy changes
MDM – audit considerations
from ISACA’s work program
˃ Postpone automatic updates from Internet service
providers (ISPs), e.g., in cases where an automatic
OS update may cause critical apps to fail
˃ Secure logs and audit trails of all sensitive BYOD
activities
˃ Capability to locate and map lost phones for
recovery
˃ Backup and restore BYOD device data
˃ Remove or install profiles based on geographic
location, to ensure compliance with relevant foreign
legislation, e.g., data privacy and security
MDM – audit considerations
from ISACA’s work program
˃ When BYOD devices attempt to connect to the
organization’s networks, the MDM system
automatically checks:
˃ Patch levels for OSs and apps
˃ Required security software is active and current, i.e.,
˃
˃
˃
˃
antivirus, firewall, full-disk encryption, etc.
Device is not jailbroken (Apple) or rooted (Android)
Presence of unapproved devices (if any)
Presence of blacklisted apps
If any of the above login checks fail, the MDM can
automatically update the device concerned (e.g.,
patch levels) or disallow access.
MDM – audit considerations
from ISACA’s work program
˃ Don’t forget to the secure the MDM system itself
˃ 9.2.1 MDM Application Security
Building the framework – complete
DATA
WEB & APPS
DEVICES
PEOPLE
Data
App
Phone
Policy
Web
Tablet
Agreement
Confidential
Data
Restricted
Data
Practices
App
Internal Use
Data
Laptop
Procedures
MDM
Web
Practices
App
Risk
Assessment
Public
Data
MDM
© Baker Tilly Virchow Krause, LLP
Major security concerns (NIST) –
mapped to framework area
Security Concern
Data
Websites &
Apps
Device People
s
Physical security controls
X
X
Untrusted mobile devices
X
X
Untrusted networks
X
X
Untrusted apps
X
X
Interaction with other
systems
X
X
Untrusted content
X
X
Location services
X
X
X
X
X
X
X
X
Examples of environments
Baker Tilly refers to Baker Tilly Virchow Krause, LLP,
an independently owned and managed member of Baker Tilly International
© 2010 Baker Tilly Virchow Krause, LLP
74
Example – no BYOD
DATA
WEB & APPS
DEVICES
PEOPLE
HR
HR
Phone
Policy
Financial
Tablet
Agreement
Confidential
IF
Restricted
Customer
Practices
CRM
Internal Use
Other
Laptop
Procedures
MDM
Web
Training
Email
Risk
Assessment
Public
MDM - Process & Technology
© Baker Tilly Virchow Krause, LLP
Example – mixed devices, controls by type
MDM - Tech
WEB & APPS
DATA
Customer
Employee
Confidential
Restricted
CRM
Custom Built
Ops
DEVICES
Confidential
Restricted
Phone
Tablet
PEOPLE
Practices
MDM
Policy
Agreement
Internal Use
Trade Secrets
HR/FIN
Internal Use
Marketing
Phone
Public
Training
Practices
Internal Use
Email
Procedures
Public
Web
Public
© Baker Tilly Virchow Krause, LLP
Laptop
Tablet
Risk
Assessment
Example – owned & BYOD with controls
MDM - Tech
WEB & APPS
DATA
Customer
Confidential
HR
OWNED
Confidential
PEOPLE
Phone
Policy
Practices
Restricted
Employee
Restricted
FIN
Tablet
MDM
Agreement
Public
Other
Public
Document
Management
MDM - Tech
Procedures
BYOD
Confidential
Email
Phone
Practices
Training
Restricted
Public
© Baker Tilly Virchow Krause, LLP
Tablet
MDM
Risk
Assessment
Resources
Baker Tilly refers to Baker Tilly Virchow Krause, LLP,
an independently owned and managed member of Baker Tilly International
© 2010 Baker Tilly Virchow Krause, LLP
78
Resources
˃
˃
˃
˃
BankInfoSecurity, BYOD: Get Ahead of the Risk, Intel CISO:
Policy, Accountability Created Positive Results, January 2012
Digital Services Advisory Group and Federal Chief Information
Officers Council, Bring Your Own Device, A Toolkit to Support
Federal Agencies Implementing Bring Your Own Device (BYOD)
Programs, August 2012
Gartner, Magic Quadrant for Mobile Device Management, May
2012
Gartner, Gartner Says Consumerization Will Drive At Least Four
Mobile Management Styles, November 2011
Resources
˃
˃
National Institute of Standards and Technology, Special
Publication 800-124 Revision 1 (Draft), Guidelines for
Managing and Securing Mobile Devices in the Enterprise,
July 2012
National Institute of Standards and Technology, Special
Publication 800-144, Guidelines on Security and Privacy in
Public Cloud Computing, December 2011
Resources
˃
BYOD audit/assurance program
˃
˃
www.isaca.org/auditprograms
Securing mobile devices using COBIT® 5 for information
security
˃
www.isaca.org/Securing-Mobile-Devices
